Top » Piese de schimb » Piese Stanley » SXFPW30PE Type 1

MASINA DE SPALAT CU PRESIUNE STANLEY SXFPW30PE Type 1
[SXFPW30PE Type 1]
MASINA DE SPALAT CU PRESIUNE STANLEY SXFPW30PE Type 1
Click pentru a mari
Imagini suplimentare
MASINA DE SPALAT CU PRESIUNE STANLEY SXFPW30PE Type 1
Click pentru a mari
MASINA DE SPALAT CU PRESIUNE STANLEY SXFPW30PE Type 1
Click pentru a mari
MASINA DE SPALAT CU PRESIUNE STANLEY SXFPW30PE Type 1
Click pentru a mari
MASINA DE SPALAT CU PRESIUNE STANLEY SXFPW30PE Type 1
Click pentru a mari
MASINA DE SPALAT CU PRESIUNE STANLEY SXFPW30PE Type 1
Click pentru a mari
MASINA DE SPALAT CU PRESIUNE STANLEY SXFPW30PE Type 1
Click pentru a mari
MASINA DE SPALAT CU PRESIUNE STANLEY SXFPW30PE Type 1
Click pentru a mari
LISTA DE COMPONENTE:
Numar Versiune Buc. in schema Denumire Pret/buc
(Tva inclus)		 Cumpara
1 1 1 HANDLE UPPER (4381020) 13697 RON
2 1 1 4381120 - Indisponibil
2 1 1 KNOB (5140205-01) 2182 RON
3 1 1 GUARD (4381950) 3954 RON
4 1 1 4380970 - Indisponibil
4 1 1 CASING (5140205-03) 21676 RON
5 1 1 3080580 - Indisponibil
5 1 1 X94ND (1004455-07) 114 RON
6 1 1 KNOB (1004712-40) 3268 RON
6 1 1 KNOB (4381220) 6688 RON
7 1 2 3081650 - Indisponibil
7 1 2 FORK (5140205-32) 1630 RON
8 1 1 4101250 - Indisponibil
8 1 1 FITTING (5140205-33) 15469 RON
9 1 1 SUPPORT (4381150) 1318 RON
10 1 1 4381070 - Indisponibil
10 1 1 5140205-08 - Indisponibil
11 1 1 4381060 - Indisponibil
11 1 1 5140205-09 - Indisponibil
12 1 1 GUARD (4381940) 6688 RON
13 1 2 4381840 - Indisponibil
13 1 2 PLATE (5140205-11) 16689 RON
14 1 1 4381170 - Indisponibil
14 1 1 BRACKET (5140205-12) 1772 RON
15 1 2 FOOT (1004712-16) 3268 RON
15 1 2 Rubber foot HW151 (2180330) 105 RON
16 1 1 4381050 - Indisponibil
16 1 1 5140205-14 - Indisponibil
17 1 1 4101030 - Indisponibil
17 1 1 FITTING (5140205-35) 15469 RON
18 1 1 3082000 - Indisponibil
18 1 1 REGULATOR (1004512-37) 4137 RON
18 1 1 DETERGENT REGULATOR (5140205-16) 9012 RON
19 1 1 4381040 - Indisponibil
19 1 1 5140205-17 - Indisponibil
20 1 2 4381110 - Indisponibil
20 1 2 5140205-18 - Indisponibil
21 1 2 WHEEL (4381100) 18568 RON
22 1 1 4380960 - Indisponibil
22 1 1 5140205-20 - Indisponibil
23 1 1 4380230 - Indisponibil
23 1 1 CARRIER (5140205-21) 9012 RON
24 1 1 COUPLING SA (1004712-93) 3954 RON
24 1 1 1004700-77 - Indisponibil
24 1 1 3082130 - Indisponibil
25 1 1 4381080 - Indisponibil
25 1 1 TANK (5140205-22) 15469 RON
26 1 1 4381230 - Indisponibil
26 1 1 5140205-23 - Indisponibil
27 1 1 KNOB (4381180) 1630 RON
28 1 1 4381200 - Indisponibil
28 1 1 HUB PIN (5140205-25) 4355 RON
29 1 1 4381030 - Indisponibil
29 1 1 5140205-26 - Indisponibil
30 1 1 GUARD (4381960) 741 RON
31 1 1 GUARD (4381680) 4355 RON
32 1 1 4381240 - Indisponibil
32 1 1 HOSE SA, REINFORCED (4382140) 18568 RON
32 1 1 HIGH PRESSURE HOSE (5140205-29) 20216 RON
33 1 1 4381190 - Indisponibil
33 1 1 LEVER (5140205-30) 3954 RON
34 1 1 4381160 - Indisponibil
34 1 1 5140205-31 - Indisponibil
35 1 1 PLUG (3720730) 741 RON
35 1 2 FOOT (4381640) 1318 RON
36 1 1 HEAD (3400970) 73079 RON
37 1 3 SCREW (1004709-97) 944 RON
38 1 1 O RING (1004710-05) 668 RON
39 1 1 COUPLING (3401000) 10241 RON
40 1 4 O RING (2841520) 668 RON
41 1 1 COUPLING (3960430) 16689 RON
42 1 1 O RING (1004709-78) 668 RON
43 1 6 1004712-74 - Indisponibil
43 1 1 VALVE (2849051) 10241 RON
44 1 6 SEAL (1004712-18) 944 RON
45 1 3 O RING (1004709-93) 668 RON
46 1 3 BUSHING (1004712-69) 5370 RON
47 1 3 BUSHING (1004712-68) 1630 RON
48 1 3 SEAL (1004711-74) 114 RON
49 1 4 SCREW (1004712-82) 944 RON
50 1 1 GUIDE (1004712-76) 13697 RON
50 1 1 GUIDE (1004713-41) 12361 RON
51 1 3 SPRING (1004712-87) 1318 RON
52 1 3 PISTON (1004712-67) 5370 RON
53 1 3 LOCK (1004712-64) 668 RON
54 1 1 FORK (4240270) 3954 RON
55 1 1 O RING (1004711-50) 668 RON
56 1 3 PLUG (1004712-73) 3268 RON
57 1 1 PLUG (3960440) 12361 RON
58 1 1 O RING (1004712-92) 668 RON
59 1 1 PRESSURE GAUGE (1004730-85) 16689 RON
60 1 1 SPRING (1004711-70) 668 RON
61 1 1 BALL (1004710-50) 668 RON
62 1 1 O RING (1004709-78) 668 RON
63 1 1 COUPLING (3700240) 1933 RON
64 1 1 O RING (1004711-49) 668 RON
65 1 1 SHUTTER (1004712-85) 2556 RON
66 1 1 SPRING (1004713-55) 668 RON
67 1 2 O RING (1004710-00) 668 RON
68 1 1 VALVE (3700200) 9012 RON
69 1 1 O RING (1004710-43) 668 RON
70 1 1 O RING (1004709-81) 668 RON
71 1 1 PIN (1004712-08) 2796 RON
72 1 1 SPRING (1004712-05) 668 RON
73 1 1 WASHER (1004712-06) 668 RON
74 1 1 O RING (1004710-62) 668 RON
75 1 1 BOLT (1004711-06) 6688 RON
76 1 1 KIT (1004709-35) 15469 RON
77 1 1 SEAT (2901270) 9012 RON
78 1 1 O RING (1004709-81) 668 RON
79 1 1 PISTON (1004711-46) 5370 RON
80 1 1 PISTON (1004712-07) 741 RON
81 1 1 O RING (1004710-38) 668 RON
82 1 1 O RING (1004709-81) 668 RON
83 1 1 RING (1004710-41) 668 RON
84 1 1 O RING (1004710-05) 668 RON
85 1 1 O RING (1004709-90) 668 RON
86 1 1 GUIDE (1004711-07) 13697 RON
87 1 1 PLATE (1004710-96) 1630 RON
88 1 1 SPRING (1004711-47) 668 RON
89 1 1 PLATE (1004711-87) 668 RON
90 1 1 PIN (1004710-36) 114 RON
91 1 1 INSERT (1004711-08) 12361 RON
92 1 1 SCREW (1004711-90) 668 RON
93 1 1 NUT (1004710-34) 668 RON
94 1 1 KNOB (4240530) 4355 RON
95 1 2 O RING (1004710-49) 668 RON
96 1 1 VALVE KIT (1004730-86) 24962 RON
97 1 1 4389104 - Indisponibil
97 1 1 HEAD SA (1004759-44) 125542 RON
98 1 1 O RING (1004712-71) 668 RON
99 1 1 VALVE KIT (1004708-87) 9012 RON
100 1 1 PISTON KIT (1004708-88) 741 RON
101 1 1 SEALS KIT (1004709-23) 5370 RON
102 1 1 GASKET SET (1004730-87) 13697 RON
103 1 1 1004701-09 - Indisponibil
103 1 1 SCREW (5140205-48) 668 RON
104 1 1 PLATE (3400600) 9012 RON
105 1 1 3081750 - Indisponibil
105 1 1 WASHER (5140205-41) 668 RON
106 1 1 3441000 - Indisponibil
106 1 1 RING (5140205-51) 668 RON
107 1 4 SCREW (1004712-31) 1772 RON
108 1 1 BODY (1004714-14) 18568 RON
109 1 1 BEARING (1004711-53) 114 RON
110 1 1 COVER (1004711-45) 16689 RON
111 1 1 SEAL (1004711-54) 1318 RON
112 1 1 O RING (1004709-75) 668 RON
113 1 1 1004553-07 - Indisponibil
113 1 1 FAN (5140205-50) 944 RON
114 1 1 CONVEYOR (1004714-15) 9012 RON
115 1 2 WASHER (1004711-73) 668 RON
116 1 2 SCREW (1004711-51) 668 RON
117 1 1 O RING (1004709-87) 668 RON
118 1 1 BOX (1004712-32) 5370 RON
119 1 1 WASHER (1004710-65) 668 RON
120 1 3 SCREW (1004712-03) 668 RON
121 1 1 COVER (1004714-13) 5370 RON
122 1 1 SWITCH (1004744-81) 9012 RON
123 1 1 GLAND (1004712-04) 2182 RON
124 1 1 CORDSET (1004714-18) 18568 RON
125 1 1 O RING (1004712-35) 668 RON
126 1 1 CAPACITOR (1004711-98) 15469 RON
127 1 1 MOTOR SA (4381930) 308517 RON
128 1 1 FORK (1004712-09) 1630 RON
129 1 1 4389600 - Indisponibil
129 1 1 BOX (1004770-85) 18568 RON
130 1 2 SCREW (1004712-01) 668 RON
131 1 2 GLAND (1004712-04) 2182 RON
132 1 1 O RING (1004712-17) 1630 RON
133 1 1 O RING (1004709-71) 668 RON
134 1 1 4381910 - Indisponibil
134 1 1 GUN (5140205-53) 38463 RON
135 1 1 4382190 - Indisponibil
135 1 1 4382230 - Indisponibil
135 1 1 EXTENSION (1004775-13) 24962 RON
136 1 1 4382350 - Indisponibil
136 1 1 LANCE AND ROTOPOWER (5140205-55) 49114 RON
137 1 1 4382170 - Indisponibil
137 1 1 HIGH PRESSURE HOSE (5140205-56) 249223 RON
138 1 1 3083690 - Indisponibil
138 1 1 O-RING (5140205-57) 1318 RON
139 1 2 O RING (3083380) 668 RON
139 1 2 O-RING (5140205-58) 114 RON
140 1 1 ADAPTOR (1004512-28) 4137 RON
141 1 1 BRUSH (1004455-56) 9012 RON
142 1 1 ADAPTOR (1004553-11) 10241 RON
143 1 1 4381490 - Indisponibil
143 1 1 EXTENSION (5140205-97) 13697 RON
144 1 1 O RING (3083370) 668 RON
144 1 1 O-RING (5140206-02) 668 RON
145 1 1 BRUSH SA (3084342) 32327 RON
146 1 1 3083700 - Indisponibil
146 1 1 O-RING (5140193-41) 668 RON
147 1 1 1004553-12 - Indisponibil
800 1 1 BEARING (1004744-74) 741 RON
800 1 1 3400540 - Indisponibil
