| 1 |
1 |
1 |
Screw compl. (316034800)
|
3689 RON |
|
| 2 |
1 |
1 |
Clamping flange (341031790)
|
2459 RON |
|
| 3 |
1 |
1 |
Clamping flange (341031780)
|
2459 RON |
|
| 4 |
1 |
1 |
Retaining ring (141180390)
|
781 RON |
|
| 5 |
1 |
1 |
Toothed segment (339131510)
|
105 RON |
|
| 6 |
1 |
1 |
Safety guard compl. (316043360)
|
49212 RON |
|
| 7 |
1 |
1 |
Cap (343378080)
|
781 RON |
|
| 8 |
1 |
2 |
Clamping lever (343377640)
|
781 RON |
|
| 9 |
1 |
1 |
Washer (141150110)
|
446 RON |
|
| 10 |
1 |
1 |
Self-tap. fill. h. screw (141118730)
|
446 RON |
|
| 11 |
1 |
1 |
Tension spring (342010260)
|
446 RON |
|
| 12 |
1 |
1 |
Cylinder head screw (141122830)
|
781 RON |
|
| 13 |
1 |
2 |
Truss head screw (341703660)
|
446 RON |
|
| 14 |
1 |
1 |
Riv.knife guide (339131520)
|
488 RON |
|
| 15 |
1 |
1 |
Saw spindle cpl. (316034590)
|
26730 RON |
|
| 16 |
1 |
1 |
Saw axle (341057010)
|
7157 RON |
|
| 17 |
1 |
1 |
Ball bearing, 15x35x11 (143114870)
|
5926 RON |
|
| 18 |
1 |
1 |
Gear flange (315415670)
|
955 RON |
|
| 19 |
1 |
1 |
Spur gear (341057020)
|
3018 RON |
|
| 20 |
1 |
1 |
geargasket (339210870)
|
446 RON |
|
| 21 |
1 |
1 |
M-Label,08 52x22 (338122160)
|
446 RON |
|
| 22 |
1 |
1 |
Exhaust nozzle (343377760)
|
1340 RON |
|
| 23 |
1 |
1 |
O-ring (143194270)
|
446 RON |
|
| 24 |
1 |
1 |
Saw housing (316034640)
|
4442 RON |
|
| 25 |
1 |
4 |
Fill. head screw(DIN 7985) (141121640)
|
446 RON |
|
| 26 |
1 |
1 |
Butting plate (339011410)
|
2459 RON |
|
| 27 |
1 |
1 |
GUIDER (339131540)
|
3018 RON |
|
| 28 |
1 |
1 |
Riving knife (339131570)
|
3018 RON |
|
| 29 |
1 |
1 |
Washer (141154070)
|
781 RON |
|
| 30 |
1 |
1 |
Sheet Cover (339131580)
|
105 RON |
|
| 31 |
1 |
1 |
Sheet Cover (339131670)
|
781 RON |
|
| 32 |
1 |
2 |
Countersunk screw (141123040)
|
446 RON |
|
| 33 |
1 |
1 |
Needle bushing (143111180)
|
3689 RON |
|
| 34 |
1 |
1 |
Rubber buffer (344096260)
|
446 RON |
|
| 35 |
1 |
1 |
Washer ZN5BK (141153390)
|
446 RON |
|
| 36 |
1 |
1 |
Countersunk screw (141123190)
|
446 RON |
|
| 37 |
1 |
1 |
Cover cpl. (316034580)
|
21361 RON |
|
| 38 |
1 |
4 |
Tight-fit screw (341701490)
|
446 RON |
|
| 39 |
1 |
1 |
Spindle lock (316043330)
|
7157 RON |
|
| 40 |
1 |
1 |
Pressure spring (342007800)
|
781 RON |
|
| 41 |
1 |
1 |
Felt (344070600)
|
446 RON |
|
| 42 |
1 |
1 |
Pressure spring (342003020)
|
446 RON |
|
| 43 |
1 |
1 |
Cable sleeve (344100970)
|
781 RON |
|
| 44 |
1 |
1 |
Cable without plug (344495270)
|
13756 RON |
|
| 45 |
1 |
1 |
Handle w.cover (343393730)
|
8275 RON |
|
| 46 |
1 |
1 |
Handle element (343393720)
|
2459 RON |
|
| 47 |
1 |
1 |
Handle compl. (316041860)
|
15993 RON |
|
| 48 |
1 |
1 |
Switch lock red (343394510)
|
2459 RON |
|
| 49 |
1 |
1 |
Switch trigger (343394500)
|
1340 RON |
|
| 50 |
1 |
1 |
Switch (343406260)
|
Indisponibil |
Indisponibil |
| 51 |
1 |
2 |
Fillister head screw (141116970)
|
781 RON |
|
| 52 |
1 |
1 |
Pressure spring (342003140)
|
446 RON |
|
| 53 |
1 |
8 |
Self-tap. fill. h. screw (141116020)
|
781 RON |
|
| 54 |
1 |
1 |
Washer (339004350)
|
3018 RON |
|
| 55 |
1 |
1 |
Spacing element (341056960)
|
2124 RON |
|
| 56 |
1 |
1 |
Cap screw (141113840)
|
781 RON |
|
| 57 |
1 |
1 |
Ball bearing,10x26x8 (143114840)
|
488 RON |
|
| 58 |
1 |
1 |
Armature cpl.,120V (310008560)
|
59166 RON |
|
| 59 |
1 |
1 |
Ball bearing, 8x22x7 (143113400)
|
488 RON |
|
| 60 |
1 |
1 |
O-ring (143192130)
|
781 RON |
|
| 61 |
1 |
2 |
Washer (141151320)
|
781 RON |
|
| 62 |
1 |
1 |
Field coil (311010130)
|
30980 RON |
|
| 63 |
1 |
1 |
Motor housing (343377710)
|
955 RON |
|
| 64 |
1 |
3 |
Insert (344098520)
|
446 RON |
|
| 65 |
1 |
1 |
Rating plate (338051560)
|
446 RON |
|
| 66 |
1 |
1 |
Sleeve (343377790)
|
446 RON |
|
| 67 |
1 |
1 |
Washer (141153220)
|
446 RON |
|
| 68 |
1 |
1 |
Rubber plug (344097580)
|
446 RON |
|
| 69 |
1 |
1 |
Baffle (343377740)
|
1564 RON |
|
| 70 |
1 |
1 |
Temperature sensor (343077490)
|
4249 RON |
|
| 71 |
1 |
1 |
Electronic unit,120V/50-60 Hz (343078710)
|
30980 RON |
|
| 72 |
1 |
1 |
Twin lead (344495060)
|
1340 RON |
|
| 73 |
1 |
2 |
316035910
|
- |
Indisponibil |
| 74 |
1 |
1 |
Brush set 120V (316034690)
|
7157 RON |
|
| 75 |
1 |
1 |
Speed transmitter (343078690)
|
5926 RON |
|
| 76 |
1 |
1 |
Shift sheet (339131550)
|
2124 RON |
|
| 77 |
1 |
1 |
Cylindrical pin (141163230)
|
446 RON |
|
| 78 |
1 |
1 |
Cranked wrench key (344161520)
|
781 RON |
|
| 79 |
1 |
1 |
Motor cover (343377730)
|
3018 RON |
|
| 80 |
1 |
1 |
Truss head screw (141116050)
|
781 RON |
|
| 81 |
1 |
2 |
Washer Washer cod vechi 86300016365 (141151940)
|
446 RON |
|
| 82 |
1 |
1 |
Thumb-nut,M6 (341112670)
|
1340 RON |
|
| 83 |
1 |
1 |
Setting angle compl. (316043270)
|
19236 RON |
|
| 84 |
1 |
4 |
Fillister head screw (141123650)
|
669 RON |
|
| 85 |
1 |
1 |
Fillister head screw (141116780)
|
446 RON |
|
| 86 |
1 |
1 |
Hexagonal nut (141130090)
|
446 RON |
|
| 87 |
1 |
2 |
Square nut (141130660)
|
446 RON |
|
| 88 |
1 |
2 |
Thumbscrew (341111920)
|
105 RON |
|
| 89 |
1 |
2 |
Washer (141150020)
|
446 RON |
|
| 90 |
1 |
2 |
Sliding piece (343393790)
|
781 RON |
|
| 91 |
1 |
2 |
Champing claw (339133030)
|
669 RON |
|
| 92 |
1 |
2 |
Thumbscrew compl. (341112650)
|
781 RON |
|
| 93 |
1 |
2 |
Pressure spring (342001070)
|
446 RON |
|
| 94 |
1 |
2 |
Self-tap. fill. h. screw (141116800)
|
446 RON |
|
| 95 |
1 |
1 |
Console (343394560)
|
2124 RON |
|
| 96 |
1 |
1 |
Parallel guide compl. (316042930)
|
30980 RON |
|
| 97 |
1 |
1 |
Guide plate compl. silver (316042940)
|
24046 RON |
|
| 98 |
1 |
1 |
Swivelling segment compl. (316043280)
|
18341 RON |
|
| 99 |
1 |
1 |
Thumb-nut (341111870)
|
105 RON |
|
| 100 |
1 |
1 |
Insert (344098540)
|
446 RON |
|
| 880 |
1 |
1 |
Grease 100G (344130920)
|
5926 RON |
|
| 881 |
1 |
1 |
Grease SF 011 50Gr 1,8oz (344130560)
|
5926 RON |
|
| 1001 |
1 |
1 |
338503970
|
- |
Indisponibil |
