| 1 |
1 |
1 |
Rubber cap (344097970)
|
488 RON |
|
| 2 |
1 |
1 |
Sleeve (343394280)
|
8275 RON |
|
| 3 |
1 |
1 |
Circlip (141155450)
|
446 RON |
|
| 4 |
1 |
1 |
Ring (341012850)
|
11519 RON |
|
| 5 |
1 |
1 |
Damping ring (344097980)
|
7157 RON |
|
| 6 |
1 |
1 |
Sleeve (341058650)
|
26730 RON |
|
| 7 |
1 |
2 |
Carrier (339007080)
|
11519 RON |
|
| 8 |
1 |
1 |
Intermediate plate (339133170)
|
18341 RON |
|
| 9 |
1 |
1 |
Pressure spring (342003480)
|
1340 RON |
|
| 10 |
1 |
1 |
Washer,53x39x1,5 (341012920)
|
190 RON |
|
| 11 |
1 |
8 |
Cap screw (141114040)
|
446 RON |
|
| 12 |
1 |
1 |
Retaining ring (339132760)
|
3018 RON |
|
| 13 |
1 |
2 |
O-ring (344098140)
|
446 RON |
|
| 14 |
1 |
1 |
Shaft sealing ring (339011620)
|
2124 RON |
|
| 15 |
1 |
1 |
Retaining ring (141180450)
|
781 RON |
|
| 16 |
1 |
1 |
Control knob (343394250)
|
488 RON |
|
| 17 |
1 |
1 |
O-ring (344098090)
|
446 RON |
|
| 18 |
1 |
9 |
Cap screw (141123570)
|
669 RON |
|
| 19 |
1 |
6 |
Washer (141150020)
|
446 RON |
|
| 20 |
1 |
1 |
Gear-box cover (315415900)
|
3698 RON |
|
| 21 |
1 |
1 |
Seal (344098050)
|
3689 RON |
|
| 22 |
1 |
1 |
Shift fork (339133150)
|
24046 RON |
|
| 23 |
1 |
1 |
Retaining sheet (339133160)
|
18341 RON |
|
| 24 |
1 |
1 |
Setting ring (343394270)
|
1564 RON |
|
| 25 |
1 |
1 |
Piston compl. (316042440)
|
18341 RON |
|
| 26 |
1 |
2 |
O-ring (344098180)
|
446 RON |
|
| 27 |
1 |
1 |
316042400
|
- |
Indisponibil |
| 28 |
1 |
1 |
Bearing (320050630)
|
488 RON |
|
| 30 |
1 |
1 |
Maintenance kit (316042470)
|
49212 RON |
|
| 31 |
1 |
1 |
Gear housing compl. (315104700)
|
137236 RON |
|
| 32 |
1 |
1 |
Side support handle compl. (316042080)
|
19236 RON |
|
| 33 |
1 |
1 |
Circlip (342022080)
|
669 RON |
|
| 34 |
1 |
1 |
Ring (341070580)
|
10288 RON |
|
| 35 |
1 |
1 |
Ring (341012840)
|
955 RON |
|
| 36 |
1 |
1 |
Supporting disc (341070570)
|
2459 RON |
|
| 37 |
1 |
2 |
O-ring (344098190)
|
5479 RON |
|
| 38 |
1 |
1 |
Stop ring (339006940)
|
2124 RON |
|
| 39 |
1 |
1 |
Drill driving sleeve (341058630)
|
54357 RON |
|
| 40 |
1 |
1 |
O-ring (344098150)
|
446 RON |
|
| 41 |
1 |
1 |
Piston compl. (316042420)
|
24046 RON |
|
| 42 |
1 |
1 |
Stop ring (341012820)
|
5926 RON |
|
| 43 |
1 |
1 |
Ring,NBR (344098040)
|
190 RON |
|
| 44 |
1 |
1 |
Stop ring (341012830)
|
8275 RON |
|
| 45 |
1 |
4 |
Pin (341058640)
|
105 RON |
|
| 46 |
1 |
1 |
Sleeve (341058620)
|
93951 RON |
|
| 47 |
1 |
1 |
Striker compl. (316042430)
|
21361 RON |
|
| 48 |
1 |
1 |
Spindle compl.,SDS-M (316042410)
|
245282 RON |
|
| 49 |
1 |
1 |
Felt seal (344098060)
|
446 RON |
|
| 50 |
1 |
1 |
O-ring (344098110)
|
446 RON |
|
| 51 |
1 |
1 |
Housing cover compl. (343392340)
|
8275 RON |
|
| 52 |
1 |
1 |
Baffle (339151090)
|
4249 RON |
|
| 53 |
1 |
1 |
Pressure plate (343394230)
|
1564 RON |
|
| 54 |
1 |
1 |
Pressure spring (342003470)
|
1340 RON |
|
| 55 |
1 |
1 |
Bevel gear (343394240)
|
1340 RON |
|
| 56 |
1 |
1 |
Rating plate (338049430)
|
446 RON |
|
| 57 |
1 |
1 |
Carbon brush set (316042480)
|
18341 RON |
|
| 58 |
1 |
4 |
Screw, (341704240)
|
446 RON |
|
| 59 |
1 |
3 |
O-ring (344098160)
|
446 RON |
|
| 60 |
1 |
2 |
Brush holder (343000920)
|
3018 RON |
|
| 61 |
1 |
2 |
Lead Wire (Switch) (344497400)
|
781 RON |
|
| 62 |
1 |
1 |
Cover (339132750)
|
21361 RON |
|
| 63 |
1 |
4 |
Screw,C-K6x16 T25 (341704230)
|
669 RON |
|
| 64 |
1 |
2 |
Screw, (341704250)
|
446 RON |
|
| 66 |
1 |
1 |
Handle 2 part (343394220)
|
18341 RON |
|
| 69 |
1 |
1 |
On-off switch (343407670)
|
19236 RON |
|
| 71 |
1 |
1 |
Fan (330001860)
|
955 RON |
|
| 72 |
1 |
1 |
Ball bearing (320050650)
|
488 RON |
|
| 73 |
1 |
1 |
Armature compl.,110-120 V (310009290)
|
108379 RON |
|
| 74 |
1 |
1 |
Sealing ring (344098030)
|
5926 RON |
|
| 75 |
1 |
1 |
Retaining ring (342022070)
|
669 RON |
|
| 76 |
1 |
1 |
Ball bearing (320050670)
|
7157 RON |
|
| 77 |
1 |
1 |
Gear cover (315300620)
|
21361 RON |
|
| 78 |
1 |
1 |
Armature w.flange,110-120 V (316042460)
|
108379 RON |
|
| 79 |
1 |
1 |
Indication label,KHE 96 (338121200)
|
1564 RON |
|
| 80 |
1 |
1 |
Blank faceplate (343394260)
|
5926 RON |
|
| 81 |
1 |
2 |
Fillister head screw (141123580)
|
446 RON |
|
| 82 |
1 |
1 |
Anti-vibration handle compl. (314001050)
|
5926 RON |
|
| 83 |
1 |
1 |
Rubber bushing (344098020)
|
669 RON |
|
| 84 |
1 |
1 |
Field coil w.field coil,110-120 V (311010840)
|
30980 RON |
|
| 85 |
1 |
2 |
Screw,4x64 (341704210)
|
446 RON |
|
| 86 |
1 |
5 |
Screw,K5x45 T20 (341704220)
|
446 RON |
|
| 87 |
1 |
1 |
Metabo label (338121110)
|
1564 RON |
|
| 88 |
1 |
4 |
O-ring (344098120)
|
446 RON |
|
| 89 |
1 |
1 |
Electronic unit,110-120 V (343081320)
|
33553 RON |
|
| 90 |
1 |
1 |
Cable clip (343394210)
|
446 RON |
|
| 91 |
1 |
1 |
Cable sleeve (344098010)
|
190 RON |
|
| 92 |
1 |
1 |
Cable,m.Brit.Stecker (344497450)
|
33553 RON |
|
| 93 |
1 |
1 |
399999990
|
- |
Indisponibil |
| 94 |
1 |
1 |
Bevel gear (340032790)
|
49212 RON |
|
| 95 |
1 |
1 |
Clutch (316042390)
|
68673 RON |
|
| 96 |
1 |
2 |
Needle roller and cage (320050640)
|
2459 RON |
|
| 97 |
1 |
1 |
Motor housing compl. (316042090)
|
34448 RON |
|
| 98 |
1 |
1 |
Washers set (316043160)
|
488 RON |
|
| 880 |
1 |
1 |
Tube Grease,45 g Urethyn (344131170)
|
955 RON |
|
| 885 |
1 |
1 |
Tube Grease,100 g Darina (344131160)
|
955 RON |
|
| 1001 |
1 |
1 |
338504730
|
- |
Indisponibil |
