Top » Piese de schimb » PIESE METABO » 0010000700 11

750/11-15 - 0010000700 11 - EU 230V
[0010000700 11]
750/11-15 - 0010000700 11 - EU 230V
Click pentru a mari
Imagini suplimentare
750/11-15 - 0010000700 11 - EU 230V
Click pentru a mari
750/11-15 - 0010000700 11 - EU 230V
Click pentru a mari
LISTA DE COMPONENTE:
Numar Versiune Buc. in schema Denumire Pret/buc
(Tva inclus)		 Cumpara
10 1 1 MOUNTING BRACKET AB 750 L B6000/B7000 (81001004901) 9821 RON
20 1 1 PROTECTIVE GRATING NS 45/50/59 B6000/B70 (81001010693) 127394 RON
40 1 1 SLIDING RAIL 400 (81310086173) 18341 RON
60 1 1 COMPRESSOR PUMP B 6000 (81313030462) 688984 RON
100 1 1 V-BELT SPA 13X2083 (87230051970) 10288 RON
110 1 1 7240041990 - Indisponibil
300 1 1 SOLENOID VALVE (341148420) 78180 RON
400 1 1 ELECTRIC MOTOR 400/3/50 3000UPM B3 (88013021890) 392698 RON
1003 1 1 CYLINDER HEAD ET (81319156263) 14839 RON
1004 1 1 1315164733 - Indisponibil
1006 1 1 VALVE ASSEMBLY ET (81319156271) 171574 RON
1007 1 1 CONROD BEARING SHELL ET (81319166722) 13756 RON
1008 1 1 CONNECTING ROD ET (81319165653) 68673 RON
1010 1 1 HEXAGON NUT, PREV. TORQUE TYPE (86202002305) Indisponibil Indisponibil
1011 1 1 PISTON, HP RD 60 ET (81319163820) 39481 RON
1012 1 1 PISTON, LP RD 110 ET (81319163839) 9821 RON
1013 1 1 GUDGEON PIN RD 20X50 ET (81315163940) 18341 RON
1015 1 1 Retaining ring (141181040) 446 RON
1016 1 1 PISTON RING RD 60X2 ET (81319164100) 13756 RON
1017 1 1 PISTON RING RD 60X2 ET (81319164118) 15993 RON
1018 1 1 OIL WIPING RING RD 60X4 ET (81319164401) 18341 RON
1022 1 1 OIL SPLASH NEEDLE ET (81319164789) 190 RON
1023 1 1 AIR FILTER ET (87825156318) 18341 RON
1024 1 1 AFTERCOOLER ET (81313631792) 73930 RON
1029 1 1 FLYWHEEL RD 430 ET (81319155852) 88582 RON
1032 1 1 OIL SIGHT GLASS 1" ET (81319155879) 7157 RON
1033 1 1 CRANKCASE BREATHER 3/8" ET (81319155909) 10288 RON
1034 1 1 ROTARY SHAFT SEAL 30x42x7 ET (87635638910) 7157 RON
1060 1 1 CRANKCASE PACKING ET (81319164479) 19236 RON
1061 1 1 CYLINDER FOOT GASKET ET (81319162018) 955 RON
1062 1 1 CYLINDER GASKET ET (81319156298) 13756 RON
1064 1 1 CYLINDER HEAD GASKET ET (81319156301) 15993 RON
1065 1 1 PACKING, BEARING CAP ET (81319164525) 1564 RON
1066 1 1 PACKING, AFTERCOOLER ET (81319161747) 8275 RON
2024 1 1 PISTON RING SET, HP ET (81319166897) 15993 RON
