Top » Piese de schimb » PIESE METABO » 0910014382 10

SD 6/1000 - 0910014382 10 - EU 230V
[0910014382 10]
SD 6/1000 - 0910014382 10 - EU 230V
Click pentru a mari
Imagini suplimentare
SD 6/1000 - 0910014382 10 - EU 230V
Click pentru a mari
SD 6/1000 - 0910014382 10 - EU 230V
Click pentru a mari
SD 6/1000 - 0910014382 10 - EU 230V
Click pentru a mari
SD 6/1000 - 0910014382 10 - EU 230V
Click pentru a mari
LISTA DE COMPONENTE:
Numar Versiune Buc. in schema Denumire Pret/buc
(Tva inclus)		 Cumpara
2 1 1 TELESCOPING TUBE ET (81382606694) 171574 RON
3 1 1 INNER SHOE ET (81388606629) 7157 RON
4 1 1 1382606686 - Indisponibil
7 1 1 SPRING LOCK WASHER B 20 VERZ. (86301047329) 446 RON
8 1 1 HEXAGON THIN NUT (86205052753) 781 RON
9 1 1 PLUG ET (81381606607) 8275 RON
11 1 1 RAISED CHEESE HEAD SCREW (86123002049) 446 RON
12 1 1 Washer (86300016357) 446 RON
14 1 1 THREADED PLUG 1/4" (86109069173) 2124 RON
15 1 1 7631606517 - Indisponibil
16 1 1 1382606643 - Indisponibil
17 1 1 1382606589 - Indisponibil
18 1 1 1482606667 - Indisponibil
19 1 1 MEDIUM WASHER (86300016349) 446 RON
20 1 1 HEXAGON NUT, PREV. TORQUE TYPE (86202002313) 446 RON
21 1 1 GUIDE ET (81388606637) 21361 RON
22 1 1 Retaining ring (141180120) 781 RON
23 1 1 WHEEL SD6/1000 /ET (87270606657) 19236 RON
25 1 1 SPACER TUBE ET (81382606562) 2459 RON
26 1 1 Washer (86300016713) 446 RON
27 1 1 HEXAGON THIN NUT (86205032396) 446 RON
29 1 1 HEXAGON SOCKET HEAD CAP SCREW M 10X16 VE (86127043580) Indisponibil Indisponibil
30 1 1 THUMB SCREW RED M 8X18 (86150421509) 105 RON
31 1 1 OIL FILLER PLUG ET (81381606542) 13756 RON
32 1 1 0910007815 - Indisponibil
33 1 1 1381606534 - Indisponibil
36 1 1 Washer (86300016322) Indisponibil Indisponibil
37 1 1 HEXAGON NUT, PREV. TORQUE TYPE (86202002305) Indisponibil Indisponibil
41 1 1 GASKET KIT ET (81388606971) 54357 RON
42 1 1 CYLINDER ET (81382606961) 108379 RON
44 1 1 1388606947 - Indisponibil
46 1 1 1388606904 - Indisponibil
47 1 1 1388606939 - Indisponibil
48 1 1 1388606920 - Indisponibil
50 1 1 HYDRAULIC CYLINDER ASSEMBLY ET (81010606914) 220451 RON
59 1 1 STARKNOB NUT (87000017730) 781 RON
62 1 1 ROD, HEIGHT ADJUSTMENT ET (81382606805) 11519 RON
64 1 1 GUIDE BAR ET (81388606785) 3698 RON
65 1 1 ARTICULATED LEVER ET (81382606775) 41718 RON
72 1 1 RETAINING RING FOR SHAFTS (86400009935) 446 RON
73 1 1 Washer (86300016705) Indisponibil Indisponibil
74 1 1 HEXAGON SOCKET HEAD CAP SCREW M 8X25 VER (86121000820) 446 RON
76 1 1 SPRING LOCK WASHER B 12 VERZ. (86301000306) 446 RON
77 1 1 RETAINING RING FOR SHAFTS 8X0,8 (86400047330) 446 RON
78 1 1 SPRING LOCK WASHER B 10 VERZ. (86301002554) 446 RON
79 1 1 HEXAGON SOCKET HEAD CAP SCREW M 10X16 VE (86127043580) Indisponibil Indisponibil
80 1 1 RETAINING RING FOR SHAFTS 10X1 VERZ. (86400047349) 446 RON
81 1 1 HEXAGON THIN NUT (86205029131) 446 RON
82 1 1 STARKNOB SCREW RD40/M8X33 (DIN 933) VERZ (87001005922) 105 RON
83 1 1 CONTROL VALVE ET (87730607002) 14839 RON
86 1 1 GASKET, OIL FILTER ET (81388628614) 5479 RON
87 1 1 1388607021 - Indisponibil
89 1 1 SUPPLY HOSE ET (81388607013) 49212 RON
90 1 1 ENTRY PRESSURE HOSE ET (81388607030) 3698 RON
92 1 1 ELECTRIC MOTOR 3X400V 50HZ ET (88012607190) 220451 RON
93 1 1 Switch On/Of 400V (88112607170) 117663 RON
94 1 1 MOTOR FLANGE ET (81385607047) 19236 RON
95 1 1 Serrated lock washer (86304001745) 446 RON
96 1 1 CLUTCH, MOTOR/PUMP ET (81388607099) 30980 RON
97 1 1 PUMP, HYDRAULIC FLUID ET (87780607054) 245282 RON
100 1 1 SUCTION LINE ET (81388607064) 18341 RON
101 1 1 OIL FILTER ET (81388607072) 2848 RON
103 1 1 Cap screw (86121016638) 446 RON
