TMC-200
[TMC-200]
TMC-200
Click pentru a mari
Imagini suplimentare
TMC-200
Click pentru a mari
LISTA DE COMPONENTE:
Numar Versiune Buc. in schema Denumire Pret/buc
(Tva inclus)		 Cumpara
1 1 2 LOCK PIN (OLD 400-39907-20) (6689818) 3242 RON
2 1 2 SNAP PIN 8 (OLD 821-32203-20) (6693558) 1229 RON
3 1 6 BOLT 6X12 (OLD 990-21060-121) (6694982) 1229 RON
4 1 6 S.WASHER 6 (OLD 992-10060-012/6695217) (6695219) 1229 RON
5 1 2 CUTTER (OLD 820-39907-20) (6693557) 1041 RON
6 1 2 CUTTER HOLDER (OLD 310-39907-20) NEW (6689035) 12526 RON
7 1 2 PROTECTION COVER (OLD 307-39907-20) NEW (6688987) 2460 RON
8 1 2 OIL SEAL UE15286 (OLD 999-66152-832) NEW (6695638) 2460 RON
9 1 3 STOP RING C-28.INNER (OLD 993-51028-002) (6684741) 1229 RON
10 1 2 BALL BEARING 6902, 28MM/OD (OLD 999-61690-200) NEW (6695583) 7828 RON
11 1 1 DRIVE SHAFT (OLD 304-39907-20) NEW (6688952) 11519 RON
12 1 1 WOOD-RUFF KEY 5X22X7X14 (OLD 120-32201-20) NEW (6687078) 2236 RON
13 1 1 GEAR CASE CAP (OLD 322-39907-20) NEW (6689152) 1229 RON
14 1 1 BALL BEARING 6001ZZ, 28MM/OD (OLD 999-61600-101) NEW (6695531) 4249 RON
15 1 1 WORM SHAFT (OLD 002-33130-20) NEW (6685586) 21586 RON
16 1 1 THRUST WASHER 1226 (OLD 999-62122-669) NEW (6695614) 2460 RON
17 1 1 THRUST NEEDLE BRG 2X4.5 (OLD 999-62122-668) (6695613) 9730 RON
18 1 1 STEP WASHER (OLD 321-39907-20) NEW (6689151) 488 RON
19 1 1 BALL BEARING 6901ZZ/OD (OLD 999-61690-101/6695581) (6695582) 5815 RON
20 1 1 BOLT 6X12 (OLD 990-21060-121) (6694982) 1229 RON
21 1 1 DRAIN GASKET (OLD 727-01040-20) NEW (6692685) 1229 RON
22 1 1 GEAR CASE (OLD 300-39909-20) NEW (6688824) 12526 RON
23 1 1 BOLT 6X12 (OLD 990-21060-121) (6694982) 1229 RON
24 1 2 S.WASHER 6 (OLD 992-10060-012/6695217) (6695219) 1229 RON
25 1 1 BOLT 6X25 (OLD 990-21060-251) NEW (6694988) 1229 RON
26 1 1 SPACER (OLD 249-0630G-20) NEW (6688309) 1229 RON
27 1 1 GEAR WHEEL (OLD 301-39909-20) NEW (6688886) 27178 RON
28 1 1 GEAR CASE GASKET (OLD 318-39907-20) NEW (6689116) 2236 RON
29 1 1 GEAR CASE COVER (OLD 323-39907-20) NEW (6689153) 382 RON
30 1 4 SCREW 5X10/S (OLD 994-14050-101) (6695333) 1229 RON
31 1 2 PLUS BOLT 6X18 (OLD 990-23060-181) (6695020) 1229 RON
32 1 1 COVER BRACKET, 26 DIA. (OLD 442-37325-20/6690293) (6690303) 1229 RON
33A 1 1 COVER HOLDER (OLD 445-33140-20) (6690337) 2460 RON
34 1 2 SMALL WASHER 6 (OLD 992-00060-011) (6695183) 1229 RON
35 1 2 S.WASHER 6 (OLD 992-10060-012/6695217) (6695219) 1229 RON
36 1 2 6684792 - Indisponibil
37A 1 1 SAFETY COVER (OLD 441-39907-20) NEW (6690279) 5815 RON
38 1 4 SCREW 5X14/PS (OLD 994-15050-141) (6695384) 1229 RON
39 1 1 NAME PLATE, TMC200 (OLD 906-39909-20) NEW (6694329) 2236 RON
40 1 1 COLLAR B (OLD 348-33130-20) (6689530) 3242 RON
41 1 1 COLLAR (OLD 294-39909-20) (6688629) 1229 RON
