| 1 |
1 |
1 |
6687476 (6687476)
|
3242 RON |
|
| 2 |
1 |
1 |
SPARK PLUG BPM6A FOR USA (OLD 018-11660-21) (6685085)
|
2459 RON |
|
| 3 |
1 |
1 |
CYLINDER SET (OLD 001-0650A-90) (6685480)
|
18789 RON |
|
| 4 |
1 |
2 |
HEX. HOLE BOLT M5X18/S (OLD 994-61050-184) (6684586)
|
1229 RON |
|
| 5 |
1 |
1 |
CYLINDER GASKET (OLD 017-06500-20) (6685744)
|
1229 RON |
|
| 6 |
1 |
1 |
PISTON RING (OLD 041-00601-21/ 6686117) (6686118)
|
3242 RON |
|
| 7 |
1 |
1 |
PISTON SET (OLD 030-00070-90) (6685869)
|
8164 RON |
|
| 8 |
1 |
1 |
PISTON PIN (OLD 037-06500-20) (6686015)
|
1229 RON |
|
| 9 |
1 |
2 |
PISTON PIN CIRCLIP (OLD 039-00601-20) (6684590)
|
1229 RON |
|
| 10 |
1 |
1 |
CRANK SHAFT COMP (OLD 046-06621-80) (6686208)
|
18789 RON |
|
| 12 |
1 |
1 |
6697150 (6697150)
|
15098 RON |
|
| 13 |
1 |
2 |
HEX. HOLE BOLT M4X18/WS (OLD 994-64040-184) (6684599)
|
1229 RON |
|
| 14 |
1 |
1 |
INSULATOR TUBE 50L (OLD 250-06500-20) (6684597)
|
1229 RON |
|
| 15 |
1 |
1 |
CORD 200M (OLD 178-51705-80) (6687918)
|
2460 RON |
|
| 16 |
1 |
1 |
IGNITION COIL COMP (OLD 167-21550-81/6687702/668769) (6695939)
|
17895 RON |
|
| 31 |
1 |
1 |
6686574 (6686574)
|
19684 RON |
|
| 32 |
1 |
1 |
CRANKCASE GASKET (OLD 090-06500-20) (6686720)
|
1229 RON |
|
| 33 |
1 |
2 |
OIL SEAL TB 12227 (OLD 999-66122-200/6695624) (6684607)
|
Indisponibil |
Indisponibil |
| 34 |
1 |
2 |
BALL BEARING 6001 C3 NSK (OLD 999-61600-115/6684608/6695530) (6695535)
|
3131 RON |
|
| *35 |
1 |
1 |
GEAR SHAFT SHIM 0.10 (OLD 330-00200-21) (6689177)
|
1229 RON |
|
| *35 |
1 |
1 |
GEAR SHAFT SHIM 0.15 (OLD 330-00200-22) (6689178)
|
1229 RON |
|
| *35 |
1 |
1 |
GEAR SHAFT SHIM 0.20 (OLD 330-00200-23) (6684604)
|
1229 RON |
|
| *35 |
1 |
1 |
GEAR SHAFT SHIM 0.30 (OLD 330-00200-24) (6684605)
|
1229 RON |
|
| 36 |
1 |
1 |
ANTI-VIBE RUBBER (OLD 599-00601-20) (6691822)
|
1229 RON |
|
| 37 |
1 |
3 |
HEX. SOCKET HD. BOLT M5X30 S (OLD 994-61050-304) (6684786)
|
1229 RON |
|
| 38 |
1 |
1 |
MAGNETO ROTOR COMP. (OLD 155-21549-80) (6687396)
|
10513 RON |
|
| 39 |
1 |
1 |
HEX.NUT M8 (OLD 991-01080-011) (6684612)
|
1229 RON |
|
| 40 |
1 |
2 |
STUD BOLT 6X22 (OLD 100-02100-20) (6686771)
|
1229 RON |
|
| 61 |
1 |
1 |
INTAKE PIPE GASKET (OLD 403-06500-20) (6689891)
|
1229 RON |
|
| 62 |
1 |
1 |
CARB. INSULATOR SET,SPARE (OLD 404-06500-90) (6689966)
|
4137 RON |
|
| 63 |
1 |
2 |
HEX. HOLE BOLT 5X25WS (OLD 994-64050-254) (6695515)
|
1229 RON |
|
| 64 |
1 |
1 |
CARBURETOR GASKET (OLD 402-0602K-21/6689836) (6684615)
|
1229 RON |
|
| 65 |
1 |
1 |
CLEANER BODY COMP. (OLD 423-0072Z-81) (6690091)
|
3578 RON |
|
| 66 |
1 |
2 |
COLLAR (OLD 470-00025-20) (6690801)
|
2236 RON |
|
| 67 |
1 |
1 |
CHOKE PLATE,W/1.5MM HOLE (OLD 528-0602K-20) (6691267)
|
3242 RON |
|
| 68 |
1 |
1 |
SPACER (OLD 453-0602K-20) (6684859)
|
1229 RON |
|
| 69 |
1 |
2 |
S.WASHER 5 (OLD 992-10050-012/6695214) (6684662)
|
1229 RON |
|
| 70 |
1 |
2 |
SCREW 5X65 (OLD 990-11050-652) (6694918)
|
1229 RON |
|
| 71 |
1 |
2 |
WASHER 5 (OLD 992-01050-011) (6684661)
|
1229 RON |
|
| 72 |
1 |
1 |
CLEANER ELEMENT (OLD 446-0072Z-20) (6690350)
|
4025 RON |
|
| 73 |
1 |
1 |
AIR CLEANER CAP (OLD 424-0072Z-20) (6690142)
|
3578 RON |
|
| 74 |
1 |
1 |
CARBURETOR SET WYL212 WALBRO (OLD 455-06622-90) (6690495)
|
26395 RON |
|
| 75 |
1 |
1 |
THROTTLE WIRE FIXING PLATE (OLD 878-06620-20) (6684629)
|
2236 RON |
|
| 76 |
1 |
1 |
CARBURETOR GASKET (OLD 402-06500-20) (6689839)
|
1229 RON |
|
| 77 |
1 |
1 |
CLEANER GASKET (OLD 431-06020-20) (6690184)
|
1229 RON |
|
| 78 |
1 |
1 |
6685247 (6685247)
|
2236 RON |
|
| 79 |
1 |
1 |
CLIP.6.3 DIA. (OLD 680-00731-20) (6684619)
|
1229 RON |
|
| 80 |
1 |
1 |
PUMP FILTER BODY COMP. (OLD 675-04042-80) (6684620)
|
3242 RON |
|
| 81 |
1 |
1 |
TANK WHITE (OLD 591-51604-20) (6691647)
|
5815 RON |
|
| 82 |
1 |
1 |
6691715 (6691715)
|
4025 RON |
|
| 83 |
1 |
2 |
COLLAR 5.8 (OLD 659-00801-20) (6692244)
|
1229 RON |
|
| 84 |
1 |
2 |
HEX. HOLE BOLT 5X18PS (OLD 994-63050-185) (6695505)
|
1229 RON |
|
| 85 |
1 |
1 |
CABLE ADJUSTER (OLD 614-25137-20) (6684871)
|
2236 RON |
|
| 86 |
1 |
1 |
LOCK NUT M6 (OLD 991-01060-013/6692005) (6684872)
|
1229 RON |
|
| 87 |
1 |
1 |
FUEL PIPE 3X5X70 (OLD 700-03005-07) (6692357)
|
1229 RON |
|
| 88 |
1 |
1 |
RETURN GROMMET (OLD 534-32710-20) (6684627)
|
105 RON |
|
| 89 |
1 |
1 |
SWIVEL CAP (OLD 560-07120-20) (6684628)
|
105 RON |
|
| 101 |
1 |
1 |
MUFFLER PROTECTOR (OLD 738-06500-20) (6692795)
|
4137 RON |
|
| 102 |
1 |
1 |
MUFFLER GASKET (OLD 737-06500-20) (6692744)
|
1229 RON |
|
| 103 |
1 |
1 |
HEAT SHIELD (OLD 133-06500-20) (6687252)
|
2236 RON |
|
| 104 |
1 |
1 |
MUFFLER SET (OLD 704-0651C-91) (6692483)
|
9282 RON |
|
| 105 |
1 |
2 |
WASHER 5 (OLD 992-01050-011) (6684661)
|
1229 RON |
|
| 106 |
1 |
2 |
HEX. SOCKET HD. BOLT M5X50 (OLD 990-51050-503) (6685114)
|
1229 RON |
|
| 107 |
1 |
1 |
FAN CASE COMP VERMILION (OLD 112-06500-80/6687009) (6687010)
|
8723 RON |
|
| 108 |
1 |
1 |
RECOIL SPRING (OLD 780-06097-20) (6684675)
|
3578 RON |
|
| 109 |
1 |
1 |
STARTER ROPE REEL (OLD 774-06097-20) (6693066)
|
2460 RON |
|
| 110 |
1 |
1 |
SET SCREW (OLD 839-02010-20) (6693633)
|
1229 RON |
|
| 111 |
1 |
1 |
6693405 (6693405)
|
3242 RON |
|
| 112 |
1 |
1 |
GROMMET (OLD 203-0604A-20) (6688050)
|
1229 RON |
|
| 113 |
1 |
1 |
STARTER ROPE (OLD 783-06097-20/6693174) (6693168)
|
2236 RON |
|
| 114 |
1 |
1 |
STARTER HANDLE (OLD 785-06410-20) (6693237)
|
1229 RON |
|
| 115 |
1 |
3 |
HEX. HOLE BOLT 4X15/PS (OLD 994-63040-154) (6684682)
|
1229 RON |
|
| 116 |
1 |
1 |
MUFFLER SPECIAL GASKET (OLD 751-06500-20) (6692886)
|
1229 RON |
|
| 117 |
1 |
1 |
TAIL PIPE SET (OLD 721-06500-91/6692656) (6692657)
|
5591 RON |
|
| 118 |
1 |
2 |
MACHINE SCREW (W/SP. WASHER) M4X8 (OLD 994-34040-081) NEW NO (6685109)
|
1229 RON |
|
| 119 |
1 |
1 |
6688494 (6688494)
|
5815 RON |
|
| 120 |
1 |
1 |
TAPPING SCREW D4.5X16 (OLD 990-72045-164) (6684636)
|
1229 RON |
|
| 121 |
1 |
2 |
BOLT 4X12PS (OLD 994-25040-128) (6695441)
|
1229 RON |
|
| 122 |
1 |
1 |
STARTER PAWL SPRING (OLD 790-06097-20) (6684684)
|
2236 RON |
|
| 123 |
1 |
1 |
STARTER PAWL (OLD 788-06500-20) (6693319)
|
2236 RON |
|
| 141 |
1 |
1 |
PUMP BODY COMP. (OLD 575-25157-80) (6691433)
|
16888 RON |
|
| 142 |
1 |
1 |
PRIMING PUMP COMP. (OLD 442-25151-80) (6684687)
|
5591 RON |
|
| 143 |
1 |
1 |
DIAPHRAGM COVER (OLD 476-25151-20) (6684688)
|
3242 RON |
|
| 144 |
1 |
1 |
PRIMING BODY (OLD 447-25108-20) (6684689)
|
2460 RON |
|
| 145 |
1 |
1 |
METERING DIAPHRAGM COMP. (OLD 474-25241-80) (6690830)
|
573 RON |
|
| 146 |
1 |
1 |
DIAPHRAGM GASKET (OLD 475-25153-20) (6684691)
|
3242 RON |
|
| 147 |
1 |
1 |
MAIN JET #39 (OLD 599-2000W-39) NEW (6684878)
|
3242 RON |
|
| 148 |
1 |
1 |
STOP RING (OLD 489-25100-20) (6684696)
|
1229 RON |
|
| 149 |
1 |
1 |
SWIVEL (OLD 539-25120-20) (6684697)
|
2460 RON |
|
| 150 |
1 |
1 |
THROTTLE VALVE COMP. (OLD 488-25145-80) (6684883)
|
9730 RON |
|
| 151 |
1 |
1 |
O-RING (OLD 550-25100-20) (6684695)
|
2236 RON |
|
| 152 |
1 |
1 |
PUMP GASKET (OLD 577-25100-20) (6691457)
|
4249 RON |
|
| 153 |
1 |
1 |
PUMP DIAPHRAGM (OLD 576-25100-20/6696325) (6684693)
|
3242 RON |
|
| 154 |
1 |
2 |
THROTTLE SET SCREW (OLD 548-25140-20) (6684698)
|
2236 RON |
|
| 155 |
1 |
4 |
SET SCREW (OLD 548-25151-20/6696324) (6684699)
|
1229 RON |
|
| 156 |
1 |
1 |
INLET SCREEN (OLD 578-25007-20/6691460) (6684700)
|
2236 RON |
|
| 171 |
1 |
1 |
HANDLE A (OLD 050-33150-22) NEW (6686270)
|
5480 RON |
|
| 172 |
1 |
1 |
STOP SWITCH COMP. (OLD 170-3317A-80) (6687764)
|
6374 RON |
|
| 173 |
1 |
1 |
BUTTON STOP (OLD 258-11650-20) (6688366)
|
1229 RON |
|
| 174 |
1 |
1 |
SCREW 3X10 (OLD 994-31030-101) (6684913)
|
1229 RON |
|
| 175 |
1 |
1 |
THROTTLE LEVER (OLD 230-33150-20) (6688226)
|
2236 RON |
|
| 176 |
1 |
1 |
SAFETY LEVER (OLD 231-33150-20) (6688235)
|
2236 RON |
|
| 177 |
1 |
1 |
THROTTLE LEVER SPRING (OLD 232-33150-20) (6688243)
|
2236 RON |
|
| 178 |
1 |
1 |
HANDLE B (OLD 051-33150-23) (6686307)
|
5480 RON |
|
| 179 |
1 |
1 |
CAP (OLD 765-32120-20) (6693002)
|
1229 RON |
|
| 180 |
1 |
7 |
TAPPING SCREW 4X18 (OLD 993-18041-812) NEW (6695263)
|
1229 RON |
|
| 181 |
1 |
1 |
THROTTLE WIRE COMP. (OLD 885-06620-80) (6693917)
|
2460 RON |
|
| 182 |
1 |
1 |
STOP BUTTON MARK (OLD 925-32530-20) (6694585)
|
1229 RON |
|
| 183 |
1 |
1 |
HEX. HOLE BOLT 5X45 (OLD 990-51050-453) (6695055)
|
1229 RON |
|
| 184 |
1 |
1 |
NYLON NUT M5 (OLD 991-78050-010) (305491)
|
1453 RON |
|
| 185 |
1 |
1 |
HEX. HOLE BOLT 6X18/S (OLD 994-61060-184) (6695495)
|
1229 RON |
|
| 186 |
1 |
1 |
S.WASHER 5 (OLD 992-10050-012/6695214) (6684662)
|
1229 RON |
|
| 187 |
1 |
1 |
SMALL WASHER 5 (OLD 992-00050-011) (6684864)
|
1229 RON |
|
| 188 |
1 |
1 |
WASHER 6 (OLD 992-01060-011) (6684639)
|
1229 RON |
|
| 189 |
1 |
1 |
FRONT HANDLE (OLD 210-33160-22/6688095/6688094) (6688096)
|
4697 RON |
|
| 190 |
1 |
2 |
BRAKE SHAFT WASHER (OLD 368-32057-20) (6689680)
|
1229 RON |
|
| 191 |
1 |
2 |
SPRING WASHER 5 (OLD 992-10050-062) (6684834)
|
1229 RON |
|
| 192 |
1 |
2 |
HEX. HOLE BOLT 5X40 (OLD 990-51050-403) (6695054)
|
1229 RON |
|
| 193 |
1 |
1 |
PROTECTION TUBE 10X150L (OLD 164-10015-00) NEW (6687558)
|
1229 RON |
|
| 194 |
1 |
2 |
COLLAR 5.8 (OLD 659-00801-20) (6692244)
|
1229 RON |
|
| 211 |
1 |
1 |
GEAR CASE COMP. (OLD 300-33287-81) (6688683)
|
12526 RON |
|
| 212 |
1 |
1 |
STOP RING C-15, OUTER (OLD 993-50015-002) (6695285)
|
1229 RON |
|
| 213 |
1 |
1 |
BALL BEARING 6002Z, 32MM/OD (OLD 999-61600-202) (6695538)
|
4025 RON |
|
| 214 |
1 |
1 |
BALL BEARING 6002Z, 32MM/OD (OLD 999-61600-202) (6695538)
|
4025 RON |
|
| 215 |
1 |
1 |
CLUTCH DRUM COMP. (OLD 288-33180-80) (6688570)
|
5927 RON |
|
| 216 |
1 |
1 |
GEAR SHAFT (OLD 305-33160-20) (6688960)
|
2236 RON |
|
| 217 |
1 |
1 |
GUIDE PLATE (OLD 075-33287-20) (6686614)
|
3242 RON |
|
| 218 |
1 |
1 |
GEAR 2 (OLD 307-33287-20) (6688979)
|
1232 RON |
|
| 219 |
1 |
1 |
GEAR CASE GASKET (OLD 303-33160-20) (6688909)
|
1229 RON |
|
| 220 |
1 |
1 |
GEAR CASE COVER (OLD 630-33287-20) (6692102)
|
3578 RON |
|
| 221 |
1 |
1 |
CUTTER GUIDE 590 (OLD 122-33287-80) (6687152)
|
5255 RON |
|
| 222 |
1 |
1 |
WASHER 6 (OLD 992-01060-011) (6684639)
|
1229 RON |
|
| 223 |
1 |
1 |
NUT 6 UPS-P (OLD 991-87060-001) (6695175)
|
1229 RON |
|
| 224 |
1 |
1 |
6687119
|
- |
Indisponibil |
| 225 |
1 |
2 |
GREASE SEAL A (OLD 085-33287-20) (6686658)
|
1229 RON |
|
| 226 |
1 |
4 |
WASHER 7 BLACK (OLD 129-33202-20) (6687187)
|
1229 RON |
|
| 227 |
1 |
1 |
FIXING BOLT A M6 (OLD 124-32287-20) (6687158)
|
1229 RON |
|
| 228 |
1 |
3 |
FLANGE NUT 6 (OLD 991-82060-001) (6695170)
|
1229 RON |
|
| 229 |
1 |
6 |
HEX. HOLE BOLT 4X10S (OLD 994-61040-104) (6695484)
|
1229 RON |
|
| 230 |
1 |
1 |
GREASE NIPPLE COMP. (OLD 300-32250-80) (6688643)
|
1229 RON |
|
| 231 |
1 |
2 |
HEX. HOLE BOLT 6X18/S (OLD 994-61060-184) (6695495)
|
1229 RON |
|
| 232 |
1 |
3 |
CUTTER FIXING BOLT B (OLD 125-32287-20) (6687162)
|
1229 RON |
|
| 233 |
1 |
1 |
6687095
|
- |
Indisponibil |
| 234 |
1 |
1 |
SUPPORT PLATE (OLD 462-33287-20) (6690761)
|
2460 RON |
|
| 235 |
1 |
2 |
SMALL WASHER 5 (OLD 992-00050-011) (6684864)
|
1229 RON |
|
| 236 |
1 |
2 |
NYLON NUT M5 (OLD 991-78050-010) (305491)
|
1453 RON |
|
| 237 |
1 |
1 |
HOLDING PLATE (OLD 070-33287-20) (6686468)
|
1229 RON |
|
| 238 |
1 |
1 |
CORD CLAMP COMP. (OLD 198-10246-80) NEW (6688008)
|
1229 RON |
|
| 239 |
1 |
1 |
CUTTER COVER (OLD 138-33258-20) (6687311)
|
4585 RON |
|
| 240 |
1 |
2 |
SPRING NUT 6 (OLD 994-40060-011) (6695475)
|
1229 RON |
|
| 241 |
1 |
1 |
COMBI BOX SPANNER 10X19 ,PLUS (OLD 036-29331-50) (6685997)
|
3242 RON |
|
| 242 |
1 |
1 |
HEX. BAR WRENCH 4MM (OLD 813-20000-20) (6684813)
|
105 RON |
|
In cos:
