Top » Piese de schimb » PIESE HITACHI » TEA-500 TEA-500 [TEA-500] Click pentru a mari Imagini suplimentare Click pentru a mari Click pentru a mari Click pentru a mari Click pentru a mari Click pentru a mari Click pentru a mari Click pentru a mari Click pentru a mari Click pentru a mari LISTA DE COMPONENTE: Numar Versiune Buc. in schema Denumire Pret/buc (Tva inclus) Cumpara 1 1 1 6687468 (6687468) 2236 RON 2 1 1 SPARK PLUG BM6A (OLD 018-00502-21/6685764) (6685765) 5927 RON 3 1 4 SCREW 5X10/P (OLD 994-13050-101) (6695319) 1229 RON 4 1 1 CORD CLAMP L (OLD 198-11109-20) NEW (6688009) 1229 RON 5 1 1 CYLINDER COVER (OLD 016-10244-20) NEW (6685695) 6486 RON 7 1 1 CYLINDER SET (OLD 001-10267-90) (6685498) 40711 RON 8 1 2 STUD BOLT 6X22 (OLD 100-02100-20) (6686771) 1229 RON 10 1 4 HEX. HOLE BOLT 6X18/S (OLD 994-61060-184) (6695495) 1229 RON 12 1 1 CYLINDER GASKET (OLD 017-10200-21/6685751) (6685752) 1229 RON 13 1 1 PISTON RING (OLD 040-10100-20) (6686051) 4249 RON 14 1 1 PISTON RING (OLD 041-10100-20) (6686133) 3242 RON 15 1 1 PISTON SET PN (OLD 030-10266-90) (6685904) 15993 RON 16 1 1 PISTON PIN 10X35 (OLD 037-10100-20/6686012) (6686019) 2236 RON 17 1 2 PISTON PIN CIRCLIP (OLD 039-02000-20) (6686029) 1229 RON 18 1 1 CRANK SHAFT COMP. (OLD 046-10244-81) (6686224) 4166 RON 19 1 1 NEEDLE BEARINGF1010B 1.4X8.6 (OLD 999-62101-004) (6695596) 3578 RON 20 1 1 WOODRUFF KEY 3X13X4.5 (OLD 068-10100-20) (6684899) 1229 RON 21 1 1 WOOD-RUFF KEY 3X13X5 (OLD 068-02000-20) (6686457) 1229 RON *41 1 1 CRANK SHAFT SHIM 0.10 (OLD 071-02007-21) (6686470) 1229 RON *41 1 1 CRANK SHAFT SHIM 0.15 (OLD 071-02007-22) (6686471) 1229 RON *41 1 1 CRANK SHAFT SHIM 0.20 (OLD 071-02007-23) (6686472) 1229 RON *41 1 1 CRANK SHAFT SHIM 0.30 (OLD 071-02007-24) (6686473) 1229 RON 42 1 1 SMALL NUT 10 (OLD 991-11100-013/6695138) (6695139) 1229 RON 43 1 1 PULLEY WASHER (OLD 801-10205-20) (6684820) 1229 RON 44 1 1 STARTER PULLEY (OLD 798-10205-20) (6693409) 4137 RON 47 1 1 6686595 (6686595) 28072 RON 49 1 1 CRANK CASE GASKET (OLD 090-10200-21) (6686727) 1229 RON 50 1 1 OIL SEAL 15307 (OLD 999-66153-000) (6695641) 2236 RON 51 1 1 6695557 - Indisponibil 52 1 1 BALL BEARING #6203, 40MM/OD (OLD 999-61620-300) (6695562) 4585 RON 53 1 1 OIL SEAL UE17307 (OLD 999-66173-066/6695647) (6695648) 2460 RON 54 1 4 HEX.HOLE BOLT 6X30/S (OLD 994-61060-304) (6695499) 1229 RON 55 1 1 DRAIN GASKET (OLD 727-01040-20) NEW (6692685) 1229 RON 56 1 1 SCREW 6X10 (OLD 990-11060-102) NEW (6694926) 1229 RON 57 1 1 GOVERNOR SHAFT (OLD 369-10250-20) (6689682) 4585 RON 59 1 1 GOVERNOR SHAFT ARM (OLD 367-10250-21) (6689679) 2236 RON 60 1 2 SCREW 3X6 (OLD 990-11030-061) (6694855) 1229 RON 61 1 1 OIL PARTITION (OLD 329-10250-21/6689174) (6689175) 1229 RON 62 1 2 SCREW 4X8 (OLD 990-11040-081) (6694861) 1229 RON 63 1 1 6687057 (6687057) 11519 RON 65 1 1 GOVERNOR PLATE (OLD 388-10250-21) (6689780) 2236 RON 67 1 1 GOVERNOR SLEEVE (OLD 389-10250-21) (6689782) 6039 RON 68 1 1 STOP RING C-15, OUTER (OLD 993-50015-002) (6695285) 1229 RON 81 1 1 GOVERNOR COVER GASKET (OLD 385-10250-20) (6689775) 1229 RON 82 1 1 6689771 (6689771) 4361 RON 83 1 1 OIL SEAL UD15257 (OLD 999-66152-564/6695635) (6695637) 2460 RON 84 1 3 SCREW 4X10 (OLD 990-11040-101) (6694863) 1229 RON 85 1 1 MAGNETO ROTOR COMP. (OLD 155-21715-80) (6687405) 14092 RON 86 1 1 WASHER 10 x 22 x 1.6 (OLD 992-01100-011) (6695198) 1229 RON 87 1 1 NUT 10 (L.H. THREAD) (OLD 991-09100-001) (6695134) 1229 RON 89 1 2 SCREW 4X22/WS (OLD 994-16040-226) (6695410) 1229 RON 93 1 1 IBNITION COIL 255 (OLD 167-21954-81/6687710) (6695942) 19684 RON 95 1 1 FAN CASE (OLD 112-10244-21) (6687046) 1232 RON 96 1 1 GROMMET (OLD 202-10200-20) NEW (6688040) 1229 RON 97 1 1 CORD CLAMP COMP. (OLD 198-05015-80) (6688004) 1229 RON 98 1 4 SCREW 6X25/S (OLD 994-14060-251) NEW (6695363) 1229 RON 103 1 4 STUD BOLT 6X36 (OLD 100-04001-20) NEW (6686772) 1229 RON *104 1 1 STOP CORD COMP. (OLD 178-0136M-80) NEW JAN (6687826) 2236 RON *104 1 1 CORD B 135M (OLD 178-10269-80) NEW (6696371) 2460 RON 121 1 1 INLET MANIFOLD GASKET (OLD 403-10244-20) (6689899) 1229 RON 122 1 1 CARBURETOR INSULATOR SET (OLD 404-10262-90) (6689980) 5368 RON 123 1 1 CARBURETOR GASKET (OLD 402-01740-20/6689844) (6689826) 1229 RON 124 1 2 SCREW 5X24WS (OLD 994-16050-241) (6695423) 1229 RON 125 1 1 CHOKE LEVER (OLD 495-04200-20) (6691004) 1229 RON 126 1 1 CLEANER BODY BLK (OLD 423-1024A-20/6690128) (6696027) 2460 RON 127 1 2 COLLAR 5.8 (OLD 659-00801-20) (6692244) 1229 RON 128 1 2 SCREW 5X55S (OLD 994-14050-551) NEW (6695352) 1229 RON 130 1 2 SMALL WASHER 5 (OLD 992-00050-011) (6684864) 1229 RON 131 1 1 SPONGE (OLD 446-10244-20) (6690366) 2236 RON 132 1 1 CLEANER CAP (OLD 424-10244-21) (6690158) 2460 RON 133 1 1 CARBURETOR SET HDA178 (OLD 455-10253-90) (6690523) 24717 RON 134 1 1 THROTTLE ROD (OLD 490-10244-20) (6690964) 1229 RON 135 1 1 GOVERNOR ROD SPRING (OLD 376-12121-20) (6689714) 1229 RON 136 1 1 GOVERNOR OUTER LEVER (OLD 377-10244-20) (6689719) 2236 RON 137 1 1 GOVERNOR SPRING LEVER (OLD 372-10250-20) (6689687) 1229 RON 138 1 1 S.WASHER 6 (OLD 992-10060-012/6695217) (6695219) 1229 RON 139 1 1 LOCK NUT M6 (OLD 991-01060-013/6692005) (6684872) 1229 RON 140 1 1 SCREW 4X8/PS (OLD 994-15040-081) (6695368) 1229 RON 141 1 1 GOVERNOR SPRING (OLD 374-10244-20) (6689697) 1229 RON 142 1 1 6693590 (6693590) 4025 RON 143 1 2 SCREW 5X10 WS (OLD 994-16050-101) NEW (6695413) 1229 RON 144 1 1 WIRE RETURN SPRING (OLD 902-10244-20) (6694056) 1229 RON 145 1 1 THROTTLE SHAFT GUIDE (OLD 891-10244-20) (6694037) 2460 RON 146 1 1 STEP BOLT (OLD 357-00601-20) (6689627) 1229 RON 147 1 1 WIRE CLAMP (OLD 903-10244-20) (6694057) 1229 RON 148 1 1 SCREW 5X10 WS (OLD 994-16050-101) NEW (6695413) 1229 RON 149 1 1 U-NUT 6 (OLD 991-74060-010) (6695159) 1229 RON 161 1 2 SCREW 6X8/S (OLD 994-14060-081) (6695356) 1229 RON 162 1 2 WASHER 6 (OLD 992-01060-011) (6684639) 1229 RON 163 1 1 MUFFLER PROTECTOR (OLD 738-10244-20) (6692820) 15098 RON 164 1 1 MUFFLER STAY (OLD 733-10244-20) (6692706) 2236 RON 165 1 1 SCREW 6X12/PS (OLD 994-15060-121) NEW JAN (6695399) 1229 RON 166 1 1 6697637 - Indisponibil 167 1 2 6684792 - Indisponibil 168 1 2 S.WASHER 6 (OLD 992-10060-012/6695217) (6695219) 1229 RON 169 1 1 MUFFLER GASKET 1.5T (OLD 737-10100-20) (6692746) 1229 RON 170 1 4 SCREW 5X18/PS (OLD 994-15050-181) (6695388) 1229 RON 171 1 2 FUEL TANK BAND COMP. (OLD 603-02101-80) (6691926) 3242 RON 172 1 1 TANK WHT (OLD 591-10267-20) (6696381) 4249 RON 174 1 1 PUMP FILTER BODY COMP. (OLD 675-04042-80) (6684620) 3242 RON 175 1 1 6692316 (6692316) 2460 RON 176 1 1 STOP RING E-6 (OLD 993-55060-000) (6695310) 1229 RON 177 1 1 SMALL WASHER 8 (OLD 992-00080-011) (6695184) 1229 RON 178 1 1 PET-COCK HOLDING RUBBER (OLD 558-06020-20) (6691333) 1229 RON 179 1 1 6691653 (6691653) 5480 RON 180 1 1 FUEL PIPE 3X5X230 (OLD 700-03005-23) (6692366) 1229 RON 181 1 2 CLIP 7 (OLD 680-04019-21) (6692312) 1229 RON 182 1 1 RUBBER PIPE (OLD 678-06020-20) (6692297) 3242 RON 183 1 2 CUSHION RUBBER (OLD 655-10244-20) (6692232) 2236 RON 184 1 1 TANK HOLDING METAL COMP. (OLD 607-10244-80) (6691985) 11519 RON 185 1 4 SCREW 6X12/PS (OLD 994-15060-121) NEW JAN (6695399) 1229 RON 186 1 1 6691736 (6691736) 4697 RON 187 1 1 6684625 - Indisponibil 188 1 3 CLUTCH WASHER B (OLD 359-10112-20) (6689645) 1229 RON 189 1 3 CLUTCH ARM COMP. (OLD 290-10112-80) (6688617) 4920 RON 190 1 3 CLUTCH WASHER A (OLD 358-10112-20) (6689638) 1229 RON 191 1 3 CLUTCH STEP BOLT (OLD 357-10112-20) (6689633) 2236 RON 192 1 3 CLUTCH SPRING (OLD 342-10205-22/6689432) (6689434) 1229 RON 193 1 1 SPARK ARRESTER COMP. (OLD 732-04001-80) NEW (6692693) 3578 RON 211 1 1 6692995 (6692995) 14092 RON 212 1 1 RECOIL STARTER BODY (OLD 772-10244-20) (6693044) 8388 RON 213 1 1 RECOIL SPRING (OLD 779-10205-20) (6693123) 6933 RON 214 1 1 STARTER ROPE REEL COMP. (OLD 774-10246-80/6693009) (6693085) 5256 RON 215 1 1 STARTER ROPE (OLD 783-10205-20) (6693176) 3242 RON 216 1 1 STARTER PAWL (OLD 788-10205-20) (6693322) 2460 RON 217 1 1 FRICTION SPRING (OLD 836-10205-20) (6693617) 2236 RON 218 1 1 FRICTION PLATE (OLD 837-10205-20) NEW (6693630) 3578 RON 219 1 1 BOLT 6X12 (OLD 990-21060-121) (6694982) 1229 RON 220 1 1 STARTER HANDLE CAP (OLD 835-10246-20/6693603) (6693610) 1229 RON 221 1 1 ROPE STOPPER (OLD 795-10243-20) NEW (6693383) 1229 RON 222 1 1 STARTER HANDLE (OLD 785-10118-20/6693242) (6693241) 2460 RON 223 1 1 ROPE GUIDE (OLD 780-10108-20) (6693140) 2460 RON 241 1 1 6690590 (6690590) 44961 RON 242 1 1 SCREW (OLD 514-25001-20) (6685210) 1229 RON 243 1 1 PUMP BODY (OLD 575-25012-20) NEW (6691420) 4920 RON 244 1 1 PUMP GASKET (OLD 577-25012-20) (6691455) 2236 RON 245 1 1 PUMP DIAPHRAGM (OLD 576-25012-20) (6691446) 382 RON 246 1 1 INLET SCREEN (OLD 578-25007-20/6691460) (6684700) 2236 RON 247 1 1 IDLE ADJUST SCREW (OLD 462-25006-20) (6690736) 2460 RON 248 1 1 IDLE ADJUST SPRING (OLD 463-25012-20) (6690766) 2236 RON 249 1 1 LOW ADJUST SCREW (OLD 461-25032-20) NEW (6690715) 3690 RON 250 1 2 HIGH/LOW ADJUST SPRING (OLD 623-25032-20) (6692048) 2236 RON 251 1 1 HIGH ADJUST SCREW (OLD 460-25032-20) NEW (6690692) 3690 RON 252 1 1 VALVE SPRING (OLD 477-25003-20) NEW (6690867) 2236 RON 253 1 1 CONTROL LEVER (OLD 473-25012-20) (6690819) 3242 RON 254 1 1 HINGE PIN (OLD 605-25001-20) (6685219) 1229 RON 255 1 1 HINGE PIN SET SCREW (OLD 546-25001-20) (6685218) 2236 RON 256 1 1 NEEDLE VALVE (OLD 603-25012-20) (6685215) 382 RON 257 1 1 DIAPHRAGM GASKET (OLD 475-25012-20) (6690838) 2236 RON 258 1 1 METERRING DIAPHRAGM COMP. (OLD 474-25012-80) (6690828) 573 RON 259 1 1 DIAPHRAGM COVER (OLD 476-25012-20) (6690858) 4137 RON 260 1 4 SET SCREW (OLD 548-25012-20) (6685223) 1229 RON 281 1 1 SCREW (OLD 514-25001-20) (6685210) 1229 RON 282 1 1 PUMP BODY (OLD 575-25012-20) NEW (6691420) 4920 RON 283 1 1 PUMP GASKET (OLD 577-25012-20) (6691455) 2236 RON 284 1 1 PUMP DIAPHRAGM (OLD 576-25012-20) (6691446) 382 RON 285 1 1 INLET SCREEN (OLD 578-25007-20/6691460) (6684700) 2236 RON 286 1 1 IDLE ADJUST SCREW (OLD 462-25006-20) (6690736) 2460 RON 287 1 1 IDLE ADJUST SPRING (OLD 463-25012-20) (6690766) 2236 RON 288 1 1 VALVE SPRING (OLD 477-25088-20) NEW (6690873) 3242 RON 289 1 1 CONTROL LEVER (OLD 473-25012-20) (6690819) 3242 RON 290 1 1 HINGE PIN (OLD 605-25001-20) (6685219) 1229 RON 291 1 1 HINGE PIN SET SCREW (OLD 546-25001-20) (6685218) 2236 RON 292 1 1 NEEDLE VALVE (OLD 603-25012-20) (6685215) 382 RON 293 1 1 DIAPHRAGM GASKET (OLD 475-25012-20) (6690838) 2236 RON 294 1 1 METERRING DIAPHRAGM COMP. (OLD 474-25012-80) (6690828) 573 RON 295 1 1 DIAPHRAGM COVER (OLD 476-25012-20) (6690858) 4137 RON 296 1 4 SET SCREW (OLD 548-25012-20) (6685223) 1229 RON 311 1 1 CLUTCH SHAFT COMP. (OLD 030-32203-80) (6685911) 16888 RON 312 1 1 WOODRUFF KEY 3X13X4.5 (OLD 068-10100-20) (6684899) 1229 RON 313 1 1 GEAR CASE C (OLD 008-32250-20) NEW (6685596) 15993 RON 314 1 4 SPRING NUT 6 (OLD 994-40060-011) (6695475) 1229 RON 315 1 1 STOP RING C-32, INNER (OLD 993-51032-002) (6695295) 1229 RON 316 1 2 BALL BEARING 6002Z, 32MM/OD (OLD 999-61600-202) (6695538) 4025 RON 317 1 1 STOP RING C-15, OUTER (OLD 993-50015-002) (6695285) 1229 RON 318 1 1 GEAR CASE A COMP. (OLD 002-32250-81/6685581) (6696365) 8227 RON 319 1 4 S.WASHER 6 (OLD 992-10060-012/6695217) (6695219) 1229 RON 320 1 4 HEX. HOLE BOLT 6X18 (OLD 990-51060-183) (6695059) 1229 RON 321 1 1 GREASE NIPPLE COMP. (OLD 300-32250-80) (6688643) 1229 RON 322 1 1 LOCK COMP. (OLD 404-32250-80) (6689987) 9059 RON 323 1 1 LOCK PIN SPRING (OLD 403-32250-20) (6689905) 2236 RON 324 1 1 WASHER (OLD 760-32250-20) NEW JAN (6692944) 1229 RON 325 1 1 O-RING P-7 (OLD 999-67007-000) (6695665) 1229 RON 326 1 2 SCREW 5X16/WS (OLD 994-16050-161) (6695417) 1229 RON 327 1 1 GEAR 1 (OLD 010-32201-20) (6685606) 10513 RON 328 1 1 STOP RING C-10.OUTER (OLD 993-50010-002) (6684821) 1229 RON 329 1 1 STOP RING C-22, OUTER (OLD 993-50022-002) (6695288) 1229 RON 330 1 1 GEAR 4 (OLD 018-32250-20) (6685789) 27178 RON 331 1 1 6695557 - Indisponibil 332 1 1 GEAR 2 (OLD 012-32250-20) (6685658) 27178 RON 333 1 1 GEAR 3 (OLD 016-32201-20) (6685704) 9170 RON 334 1 1 WOOD-RUFF KEY 4X16X5 (OLD 068-12101-20) (6686460) 1229 RON 335 1 1 BALL BEARING #6200, 30MM/OD (OLD 999-61620-000) (6695551) 3578 RON 336 1 1 GEAR CASE B (OLD 006-32250-20) (6685594) 23487 RON 337 1 6 S.WASHER 6 (OLD 992-10060-012/6695217) (6695219) 1229 RON 338 1 6 PLUS BOLT 6X22 (OLD 990-23060-221) (6695021) 1229 RON 339 1 1 ROLLER BRG 30205J 6.5X10.5 (OLD 999-61302-050) (6695523) 7045 RON 340 1 1 BEARING STOPPER (OLD 040-32250-20) (6686066) 4585 RON 341 1 1 BALL BEARING #6205Z, 52MM/OD (OLD 999-61620-502) (6695565) 5591 RON 342 1 1 WAVE WASHER B.B. (OLD 992-09520-030) (6695208) 1229 RON 343 1 1 STOP RING C-52, INNER (OLD 993-51052-002) (6695300) 2236 RON 344 1 1 DRIVE SHAFT (OLD 022-32250-20) (6685825) 21586 RON 345 1 2 PIN (OLD 820-32250-20) (6693554) 3690 RON 346 1 2 SNAP PIN 8 (OLD 821-32203-20) (6693558) 1229 RON 361 1 2 HANDLE (OLD 256-32250-20) (6688342) 3315 RON 362 1 4 HANDLE GRIP (OLD 055-32250-20) (6686351) 4025 RON 364 1 2 HANDLE BRACKET (OLD 266-32250-21/6688409) (6696373) 19684 RON 365 1 4 NUT 10 (OLD 991-01100-013) NEW (6695132) 1229 RON 366 1 4 KNOB COMP. (OLD 267-32250-80) (6688417) 4025 RON 367 1 1 THROTTLE WIRE COMP. (OLD 885-10244-80) (6693930) 7716 RON 368 1 1 STOP CORD COMP. (OLD 178-10244-80) (6687880) 3242 RON 369 1 4 BOLT 6X35 (OLD 990-21060-351) NEW JAN (6694992) 1229 RON 370 1 6 WASHER 6 (OLD 992-01060-011) (6684639) 1229 RON 371 1 2 THROTTLE LEVER COMP. (OLD 101-32250-80) (6686801) 8164 RON 372 1 4 U-NUT 6 (OLD 991-74060-010) (6695159) 1229 RON 373 1 1 PUSH PIN COMP. (OLD 064-33225-80) (6686434) 2236 RON 374 1 2 STOP SWITCH BRACKET (OLD 163-32250-20) (6696370) 3914 RON 375 1 2 6687502 (6687502) 3242 RON 376 1 2 SWITCH NAME PLATE (OLD 183-01300-20) (6687949) 1229 RON 377 1 1 ANTI-VIBE RUBBER (OLD 599-00601-20) (6691822) 1229 RON 378 1 3 CORD CLAMP (OLD 198-33576-20) (6688022) 1229 RON 380 1 1 PROTECTION TUBE 13X680L (OLD 164-13068-00) (6687616) 2460 RON 381 1 1 PROTECTION TUBE 13X500L (OLD 164-13050-00) (6687614) 2236 RON 401 1 1 COMBI BOX SPANNER 10/19MM (OLD 013-29323-50/6685667) (6685257) 2460 RON 402 1 1 SPANNER 10X13 (OLD 808-20000-20) NEW (6693479) 2236 RON 403 1 1 PLUS DRIVER 4 (OLD 862-20000-20) NEW (6693665) 2460 RON 404 1 1 SPANNER 13X17 (OLD 810-20000-20) NEW (6693498) 3242 RON
