Top » Piese de schimb » PIESE HITACHI » TBL7800R TBL7800R [TBL7800R] Click pentru a mari Imagini suplimentare Click pentru a mari Click pentru a mari Click pentru a mari Click pentru a mari Click pentru a mari Click pentru a mari Click pentru a mari Click pentru a mari LISTA DE COMPONENTE: Numar Versiune Buc. in schema Denumire Pret/buc (Tva inclus) Cumpara 1 1 1 CYLINDER SET (OLD 001-16005-90) (6685500) 101668 RON 2 1 1 CYLINDER GASKET (OLD 017-16005-20) (6685757) 3690 RON 3 1 4 CYLINDER BOLT 5X22 (OLD 026-16005-20) NEW (6685846) 1229 RON 4 1 1 CYLINDER COVER (OLD 016-16005-20) NEW (6685699) 5591 RON 5 1 2 SCREW A 5X8TORX (OLD 806-31905-20) NEW (6693472) 4025 RON 6 1 1 PORT COVER S (OLD 050-16005-20) (6686257) 573 RON 7 1 1 PORT COVER F (OLD 051-16005-20) (6686282) 573 RON 8 1 4 SCREW C 4X16TORX (OLD 808-31905-20) NEW (6693480) 1229 RON 9 1 2 PORT COVER GASKET (OLD 052-16005-20) NEW (6686317) 2460 RON 10 1 1 6686606 (6686606) 60173 RON 11 1 1 CRANK CASE GASKET (OLD 090-16005-20) NEW (6686730) 3242 RON 12 1 2 BALL BEARING 6302C828 (OLD 801-31905-20) NEW MAR (6693429) 12526 RON 13 1 1 OIL SEAL ISCD16278 (OLD 999-66162-775) (6695643) 6374 RON 14 1 1 OIL SEAL ISCD16428 (OLD 999-66164-275) NEW MAR (6695645) 8164 RON 15 1 2 STOP RING C-42, INNER (OLD 993-51042-002) NEW (6695299) 1229 RON 16 1 4 SCREW E 5X30 TORX (OLD 810-31905-20) NEW (6693500) 1229 RON 17 1 1 COIL COVER (OLD 195-16005-20) NEW (6687984) 3690 RON 18 1 1 SCREW C 4X16TORX (OLD 808-31905-20) NEW (6693480) 1229 RON 19 1 6 SCREW F 6X45 TORX (OLD 811-31905-20) NEW (6693507) 3242 RON 20 1 1 PISTON SET (OLD 030-16005-90) NEW (6685906) 12526 RON 21 1 2 PISTON RING (OLD 041-16005-20) (6686136) 6598 RON 22 1 1 PISTON PIN (OLD 037-16005-20) NEW (6686022) 7157 RON 23 1 2 CIRCLIP (OLD 039-16005-20) NEW (6686037) 5591 RON 24 1 1 NEEDLE BEARING (OLD 800-31905-20) NEW (6693415) 30645 RON 25 1 2 PISTON PIN COLLAR (OLD 036-16005-20) (6685996) 2460 RON 26 1 1 CRANK SHAFT COMP. (OLD 046-16005-80) (6686239) 105024 RON 27 1 1 FLYWHEEL NUT M10 (OLD 066-16005-20) NEW (6686446) 3578 RON 28 1 1 WOOD -RUFF KEY # (OLD 068-04093-20) NEW (6686458) 2236 RON 29 1 1 6687359 (6687359) 45856 RON 30 1 1 6687635 (6687635) 7376 RON 31 1 1 6687480 (6687480) 7045 RON 32 1 1 TUBE (OLD 250-16005-20) (6688321) 2460 RON 33 1 1 GROMMET (OLD 202-16005-20) NEW (6688042) 1229 RON 34 1 2 SCREW C 4X16TORX (OLD 808-31905-20) NEW (6693480) 1229 RON 35 1 1 STOP CORD COMP. (OLD 178-16005-80) NEW (6687882) 6710 RON 36 1 1 SPARK PLUG CMR7H (OLD 018-16005-20) (6685783) 15098 RON 37 1 1 6693412 (6693412) 12526 RON 51 1 1 INSULATOR SET (OLD 404-16005-90) (6689985) 5480 RON 52 1 4 SCREW B 5X20TORX (OLD 807-31905-20) NEW (6693475) 2460 RON 53 1 1 INSULATOR GASKET (OLD 403-16005-20) NEW (6689903) 6039 RON 54 1 1 CARBURETOR GASKET (OLD 402-16005-20) NEW (6689849) 2460 RON 55 1 1 6692538 (6692538) 42389 RON 56 1 1 SPARK ARRESTER (OLD 732-16005-80) NEW (6692704) 10513 RON 57 1 2 MUFFLER S,BOLT 6X70TO (OLD 750-16005-20) (6692882) 4025 RON 58 1 1 SCREW D 6X14TORX (OLD 809-31905-20) NEW (6693488) 4025 RON 59 1 1 MUFFLER GASKET (OLD 737-16005-20) (6692752) 6374 RON 60 1 1 CLEANER FIXING PLATE (OLD 436-16005-20) (6690204) 3578 RON 61 1 1 CARBURETOR SET WYA64 (OLD 455-16005-90) (6690526) 126163 RON 62 1 4 CHOKE BOLT 4X12 (OLD 451-16005-20) NEW (6690386) 1229 RON 63 1 1 CLEANER PACKING (OLD 457-16005-20) (6690676) 6374 RON 64 1 1 BLOW OVER CHECK BOARD A (OLD 476-16005-20) (6690851) 6933 RON 65 1 1 6690054 (6690054) 8388 RON 66 1 1 CLEANER BODY COMP (OLD 419-16005-90) (6690059) 21586 RON 67 1 1 COVER FIXING BOLT (OLD 450-16005-80) (6690385) 3242 RON 68 1 1 CLEANER ELEMENT A (OLD 444-16005-20) (6690329) 382 RON 69 1 1 CARB COVER (OLD 201-25268-20) NEW (6688034) 2460 RON 70 1 2 WASHER 5 (OLD 992-01050-011) (6684661) 1229 RON 71 1 1 6690052 (6690052) 20691 RON 72 1 2 SCREW H 5X62TORX (OLD 813-31905-20) NEW (6693525) 4025 RON 73 1 1 MUFFLER SET (OLD 704-16005-90) (6692505) 5016 RON 91 1 1 6692999 (6692999) 30645 RON 92 1 1 ROPE REEL (OLD 768-16005-20) (6693006) 6710 RON 93 1 1 RECOIL SPRING (OLD 779-16005-20) (6693127) 12526 RON 94 1 1 STARTER WASHER (OLD 786-16005-20) NEW (6693255) 4025 RON 95 1 1 FRICTION SPRING (OLD 836-16005-20) NEW (6693619) 3242 RON 96 1 1 FRICTION PLATE (OLD 837-16005-20) NEW (6693631) 10513 RON 97 1 1 WASHER (OLD 801-16005-20) NEW (6693427) 2460 RON 98 1 1 SET BOLT (OLD 839-16005-20) NEW (6693640) 3242 RON 99 1 1 ROPE (OLD 783-16005-20) NEW (6693181) 4585 RON 100 1 1 STARTER HANDLE (OLD 785-16005-20) NEW (6693245) 6039 RON 101 1 1 STARTER HANDLE CAP (OLD 833-16005-20) NEW (6693605) 3242 RON 102 1 4 SCREW G 5X16 (OLD 812-31905-20) NEW (6693522) 2236 RON 121 1 1 6691436 (6691436) 64423 RON 122 1 1 INLET SCREEN (OLD 578-25007-20/6691460) (6684700) 2236 RON 123 1 1 PRIMING PUMP COMP. (OLD 442-25151-80) (6684687) 5591 RON 124 1 1 DIAPHRAGM COVER (OLD 476-25151-20) (6684688) 3242 RON 125 1 1 PRIMING BODY (OLD 447-25108-20) (6684689) 2460 RON 126 1 1 THRUST WASHER (OLD 549-25165-20) (6684874) 1229 RON 127 1 1 SWIVEL (OLD 539-25120-20) (6684697) 2460 RON 128 1 1 STOP RING (OLD 489-25100-20) (6684696) 1229 RON 129 1 1 PUMP GASKET (OLD 577-25292-20/6696321) (6684692) 7940 RON 130 1 1 PUMP DIAPHRAGM (OLD 576-25100-20/6696325) (6684693) 3242 RON 131 1 1 DIAPHRAGM GASKET (OLD 475-25153-20) (6684691) 3242 RON 132 1 1 METERING DIAPHRAGM COMP. (OLD 474-25241-80) (6690830) 573 RON 133 1 2 THROTTLE SET SCREW (OLD 514-25100-20) (6684870) 1229 RON 134 1 1 CABLE ADJUSTER STAY (OLD 544-25164-20) (6684873) 2460 RON 135 1 1 LOCK NUT M6 (OLD 991-01060-013/6692005) (6684872) 1229 RON 136 1 1 CABLE ADJUSTER (OLD 614-25137-20) (6684871) 2236 RON 137 1 1 CLEANER GASKET (OLD 431-16005-20) NEW (6690186) 2460 RON 138 1 4 SET SCREW (OLD 548-25151-20/6696324) (6684699) 1229 RON 139 1 1 MAIN JET #58 (OLD 599-2000W-58) (6691857) 3242 RON 140 1 1 O-RING (OLD 550-25100-20) (6684695) 2236 RON 161 1 1 FAN CASE E,COMP (OLD 010-31905-80) NEW (6685604) 77957 RON 162 1 1 FAN CASE S COMP. (OLD 011-31905-80) NEW (6685636) 66995 RON 163 1 9 SCREW I 5X25TORX (OLD 814-31905-20) (6693532) 2236 RON 164 1 1 ELBOW PIPE (OLD 270-31905-20) NEW (6688426) 15098 RON 165 1 1 O-RING G-95 (OLD 999-67095-010) NEW (6695687) 2460 RON 166 1 2 FAN CASE LONG BOLT (OLD 137-16005-20) (6687291) 4025 RON 167 1 2 NYLON NUT M5 (OLD 991-78050-010) (305491) 1453 RON 168 1 1 INTAKE COVER (OLD 054-31905-80) (6686342) 12526 RON 169 1 3 SCREW I 5X25TORX (OLD 814-31905-20) (6693532) 2236 RON 170 1 1 CORD CLAMP (OLD 198-31905-80) NEW (6688014) 1229 RON 171 1 1 SCREW J 5X14TORX (OLD 815-31905-20) NEW (6693536) 4025 RON 172 1 1 TUBE (OLD 283-31905-20) NEW (6688545) 2460 RON 173 1 1 FAN (OLD 127-31905-80) NEW (6687175) 64423 RON 174 1 4 SCREW K 6X35TORX (OLD 816-31905-20) NEW (6693543) 3578 RON 175 1 1 MUFFLER PROTECTOR (OLD 738-16005-20) NEW (6692825) 35678 RON 176 1 4 SCREW I 5X25TORX (OLD 814-31905-20) (6693532) 2236 RON 177 1 1 6685805 (6685805) 61851 RON 178 1 1 CUSHION PAD (OLD 021-31905-20) NEW (6685814) 2550 RON 179 1 6 CUSHION PAD CLIP (OLD 046-31905-20) NEW (6686243) 2460 RON 180 1 2 SHOULDER BELT (OLD 022-31906-20) NEW (6685821) 15098 RON 181 1 1 DUST COVER (OLD 050-31905-80) NEW (6686265) 9842 RON 182 1 4 DUST COVER SCREW (OLD 025-31905-90) NEW (6685843) 3578 RON 183 1 1 CUSHION RUBBER (OLD 030-31905-80) NEW (6685910) 16888 RON 184 1 1 WASHER A 2.3 (OLD 761-37400-20) NEW (6692961) 1229 RON 185 1 1 SCREW L 5X40TORX (OLD 817-31905-20) NEW (6693549) 2460 RON 186 1 2 SCREW M 5X16TORX (OLD 825-31905-20) NEW (6693571) 4025 RON 187 1 2 CUSHION RUBBER (OLD 031-31905-80) NEW (6685960) 17895 RON 188 1 2 FRAME NUT M6 (OLD 032-31905-20) NEW (6685967) 2236 RON 189 1 1 6696103 (6696103) 56034 RON 190 1 1 6691773 (6691773) 7381 RON 191 1 1 TANK CAP CHAIN (OLD 626-16005-20) (6692054) 2236 RON 192 1 1 6688175 (6688175) 9170 RON 193 1 1 6692273 (6692273) 4249 RON 194 1 1 CLIP.6.3 DIA. (OLD 680-00731-20) (6684619) 1229 RON 195 1 2 TANK FIXING BOLT 5X12TROX (OLD 606-31905-20) NEW (6691980) 4025 RON 196 1 1 CLIP (OLD 680-31905-20) NEW (6692321) 2236 RON 197 1 1 CARRYING HANDLE (OLD 590-31905-20) (6691471) 17895 RON 198 1 4 SCREW N 5X20TORX (OLD 826-31905-20) NEW (6693576) 4025 RON 199 1 4 HANDLE NUT M5 (OLD 282-31905-20) NEW (6688542) 2236 RON 211 1 1 THROTTLE LEVER SET (OLD 871-31905-90) NEW (6693781) 63640 RON 212 1 1 6688389 (6688389) 27178 RON 213 1 1 NYLON NUT M5 (OLD 991-78050-010) (305491) 1453 RON 214 1 1 WASHER 5 (OLD 992-01050-011) (6684661) 1229 RON 215 1 1 THROTTLE LEVER ARM (OLD 250-31905-20) NEW (6688324) 18789 RON 216 1 1 THROTTLE LEVER BRACKET (OLD 040-31905-80) NEW (6686055) 9394 RON 217 1 1 SET BOLT (OLD 793-31905-20) NEW (6693367) 4585 RON 218 1 1 SPRING (OLD 892-16005-20) NEW (6694039) 5480 RON 219 1 1 CLUTCH WASHER B (OLD 359-02103-20) (6684642) 1229 RON 220 1 1 FLANGE NUT 6 (OLD 991-82060-001) (6695170) 1229 RON 221 1 2 WASHER M8 (OLD 992-01080-011) (6684611) 1229 RON 222 1 1 STOP BUTTON COMP. (OLD 170-16005-80) NEW (6687751) 8499 RON 223 1 1 STOP BUTTON COVER (OLD 266-16005-20) NEW (6688408) 2236 RON 224 1 1 THROTTLE WIRE COMP. (OLD 885-31905-80) NEW (6693937) 1232 RON 225 1 1 PROTECTION TUBE 7X300L (OLD 164-07030-00) NEW (6687533) 1229 RON 226 1 1 6688301 (6688301) 23822 RON 227 1 1 WING BOLT 6X65 (OLD 465-16005-20) NEW (6690782) 3578 RON 228 1 1 WING NUT 6 (OLD 991-61060-013/6695155) (6696285) 1229 RON 229 1 2 WASHER (OLD 513-32625-20) (6691213) 1229 RON 230 1 1 CAP NUT 6 (OLD 991-41060-022) NEW (6695146) 1229 RON 231 1 2 SCREW M 5X16TORX (OLD 825-31905-20) NEW (6693571) 4025 RON 251 1 1 THROTTLE LEVER SET (OLD 871-31906-90) (6693782) 69568 RON 252 1 1 GRIP (OLD 248-31906-20) NEW (6688302) 11519 RON 253 1 1 GRIP COMP. (OLD 262-31906-80) NEW (6688384) 11519 RON 254 1 5 SCREW A 4X14 (OLD 806-31906-20) NEW (6693473) 1229 RON 255 1 1 THROTTLE LEVER (OLD 263-31906-20) (6688390) 3578 RON 256 1 1 LEVER (OLD 249-31906-20) NEW (6688312) 3242 RON 257 1 1 LEVER SHAFT (OLD 339-31906-20) (6689297) 6710 RON 258 1 1 WASHER 6.5X25X1.2T (OLD 240-31906-20) NEW (6688256) 1229 RON 259 1 1 SPECIAL WASHER B (OLD 844-31906-20) NEW (6693646) 2236 RON 260 1 1 WASHER (OLD 513-32625-20) (6691213) 1229 RON 261 1 1 STOPPER RING 6 (OLD 993-54006-002) NEW (6695306) 1229 RON 262 1 1 STOP SWITCH (OLD 162-16005-20) (6687508) 3242 RON 263 1 1 STOP SWITCH SPRING (OLD 262-16005-20) NEW (6688382) 382 RON 264 1 1 SCREW B 4X10 (OLD 807-31906-20) NEW (6693476) 1229 RON 265 1 1 CORD W1150M (OLD 173-16005-80) (6687788) 3914 RON 266 1 1 CORD B 1100M (OLD 174-16005-80) (6687790) 3914 RON 267 1 1 THROTTLE WIRE COMP. (OLD 885-31906-80) (6693938) 10177 RON 268 1 1 PROTECTION TUBE 7X940L (OLD 164-07094-00) (6687548) 2236 RON 269 1 1 WING BOLT 6X50 (OLD 990-60060-501) (6695096) 2236 RON 270 1 1 CAP NUT 6 (OLD 991-41060-022) NEW (6695146) 1229 RON 271 1 1 CLAMP (OLD 229-31906-20) NEW (6688222) 7716 RON 295 1 1 FLEXIBLE PIPE (OLD 101-31905-20) (6686798) 8723 RON 296 1 1 SWIVEL PIPE (OLD 102-31905-20) (6686816) 15098 RON 297 1 1 STRAIGHT PIPE (OLD 103-31905-20) (6686821) 5927 RON 298 1 1 STRAIGHT PIPE (OLD 305-31905-21) NEW FEB (6688955) 11519 RON 299 1 1 PIPE BAND 96 (OLD 100-31905-20) (6686786) 3242 RON 300 1 1 PIPE BAND 115 (OLD 267-31905-20) NEW (6688416) 3242 RON 301 1 1 WRENCH 8X10 (OLD 801-20000-20) NEW (6684766) 1229 RON 302 1 1 COMBI BOX WRENCH 19X16 (OLD 853-31905-20) (6693652) 6374 RON
