Top » Piese de schimb » PIESE HITACHI » TBC430PF TBC430PF [TBC430PF] Click pentru a mari Imagini suplimentare Click pentru a mari Click pentru a mari Click pentru a mari Click pentru a mari Click pentru a mari Click pentru a mari Click pentru a mari Click pentru a mari Click pentru a mari LISTA DE COMPONENTE: Numar Versiune Buc. in schema Denumire Pret/buc (Tva inclus) Cumpara 1 1 1 SPARK PLUG RUBBER COVER (OLD 255-04200-20) (6688336) 2460 RON 2 1 1 6687479 (6687479) 2236 RON 3 1 1 SPARK PLUG BPM6A FOR USA (OLD 018-11660-21) (6685085) 2459 RON *4 1 1 CYLINDER SET (OLD 001-04405-90) (6685476) 24717 RON *4 1 1 CYLINDER SET PN (OLD 001-04413-90) (6685477) 24717 RON 5 1 4 HEX. HOLE BOLT M5X20/S (OLD 994-61050-204) (6684668) 1229 RON 6 1 1 CYLINDER GASKET (OLD 017-04400-20) (6685741) 2236 RON 7 1 2 PISTON RING (OLD 041-04050-20) (6686123) 3242 RON *8 1 1 PISTON SET (OLD 030-04400-90) (6685889) 15098 RON *8 1 1 PISTON SET (OLD 030-0423Z-90) (6685888) 1232 RON 9 1 1 PISTON PIN 10X30 (OLD 037-01000-20) (6686007) 2236 RON 10 1 2 PISTON PIN CIRCLIP (OLD 039-05004-20) (6686032) 1229 RON 11 1 1 CRANK SHAFT COMP. (OLD 046-04400-80) (6686192) 35678 RON 13 1 1 WOOD-RUFF KEY 3X13X5 (OLD 068-02000-20) (6686457) 1229 RON 14 1 1 IGNITION COIL COMP. (OLD 167-20543-80) NEW (6687655) 16888 RON 15 1 1 RUBBER CAP (OLD 560-20517-20) (6684602) 1229 RON 16 1 1 HIGHT TENSION CORD (OLD 178-20543-22) (6687885) 1229 RON 17 1 1 6687657 (6687657) 14092 RON 18 1 1 6687970 (6687970) 3242 RON 19 1 2 SCREW 4X18/WS (OLD 994-16040-183) (6695406) 1229 RON 20 1 2 WASHER (OLD 182-0186A-20) (6684600) 1229 RON 21 1 1 CORD CLAMP COMP. (OLD 198-11600-80) NEW FEB (6688011) 1229 RON 41 1 1 PROTECTOR (OLD 257-04400-20) (6688348) 3242 RON 42 1 1 HEX. HOLE BOLT 5X20/PS (OLD 994-63050-204) (6684634) 1229 RON 43 1 1 STARTER PAWL (OLD 788-0162V-20) (6693302) 2236 RON 44 1 1 STOP RING E-5 (OLD 993-55050-000) (6684683) 1229 RON 45 1 1 SMALL NUT 10 (OLD 991-11100-013/6695138) (6695139) 1229 RON 46 1 1 STARTER PAWL SPRING (OLD 790-0162V-20) (6693345) 2236 RON 47 1 1 STARTER PULLEY (OLD 798-04220-90) (6693395) 6598 RON *48 1 1 6686558 (6686558) 23487 RON *48 1 1 6686559 (6686559) 23487 RON 49 1 1 CRANK CASE GASKET (OLD 090-04400-20) (6686715) 1229 RON 50 1 2 OIL SEAL UD15257 (OLD 999-66152-564/6695635) (6695637) 2460 RON 51 1 2 6695557 - Indisponibil *52 1 1 CRANK SHAFT SHIM 0.10 (OLD 071-02007-21) (6686470) 1229 RON *52 1 1 CRANK SHAFT SHIM 0.15 (OLD 071-02007-22) (6686471) 1229 RON *52 1 1 CRANK SHAFT SHIM 0.20 (OLD 071-02007-23) (6686472) 1229 RON *52 1 1 CRANK SHAFT SHIM 0.30 (OLD 071-02007-24) (6686473) 1229 RON 53 1 4 HEX. SOCKET HD. BOLT M5X30 S (OLD 994-61050-304) (6684786) 1229 RON 54 1 1 MAGNETO ROTOR COMP. (OLD 155-20538-80) (6687372) 1041 RON 55 1 1 WASHER 10 x 22 x 1.6 (OLD 992-01100-011) (6695198) 1229 RON 56 1 1 SMALL NUT 10 (OLD 991-11100-013/6695138) (6695139) 1229 RON 57 1 1 SCREW 5X10/S (OLD 994-14050-101) (6695333) 1229 RON 58 1 1 AIR DEFLECTOR (OLD 132-04400-20) NEW (6687208) 1229 RON 59 1 1 FAN CASE (OLD 112-04400-21/6686977) (6686982) 11519 RON 60 1 4 HEX. HOLE BOLT M5X20/S (OLD 994-61050-204) (6684668) 1229 RON 61 1 1 PRIMARY CORD GROMMET (OLD 203-11660-20) (6688057) 1229 RON 81 1 1 INLET MANIFOLD GASKET (OLD 403-04300-20) (6689885) 2236 RON 82 1 1 CARB.INSULATOR SET, SPARE (OLD 404-04300-90) (6689955) 5368 RON 83 1 1 CARBURETOR GASKET (OLD 402-04300-20) (6689833) 1229 RON 84 1 1 COLLAR (OLD 453-0637C-20) (6690430) 1229 RON 85 1 1 COLLAR (OLD 470-01380-20) (6690802) 2236 RON 86 1 1 CLEANER BODY COMP. (OLD 423-01380-82) (6690099) 382 RON 87 1 1 CHOKE VALVE (OLD 528-01380-21) NEW (6691258) 1229 RON 88 1 1 BLOW OVER CHECK BOARD (OLD 476-01700-20) (6690843) 1229 RON *89 1 1 CLEANER SPONGE (OLD 446-01380-00/6690351) (6696045) 2236 RON *89 1 2 CLEANER ELEMENT 6T (OLD 446-01380-21) (6690352) 1229 RON 90 1 1 WAVE WASHER 8 (OLD 992-04080-031) (6684658) 1229 RON 91 1 1 6690397 (6690397) 2460 RON 92 1 1 SPECIAL SCREW (OLD 380-0637C-20) (6689737) 1229 RON 93 1 2 6684660 - Indisponibil 94 1 2 S.WASHER 5 (OLD 992-10050-012/6695214) (6684662) 1229 RON 95 1 1 CARBURETOR SET, PN (OLD 455-04400-90) (6690476) 36461 RON 96 1 2 STARTER PAWL WASHER (OLD 786-00601-20) (6693248) 1229 RON 97 1 2 6695425 - Indisponibil 98 1 1 TANK FIXING COLLAR (OLD 649-01680-20) (6692182) 2236 RON 99 1 1 6684618 (6684618) 2236 RON 100 1 1 CLIP.6.3 DIA. (OLD 680-00731-20) (6684619) 1229 RON 101 1 1 6692273 (6692273) 4249 RON *102 1 1 TANK WHITE (OLD 591-04413-22/6691536) (6691539) 573 RON *102 1 1 TANK (EVAPO) (OLD 591-0440F-20) NEW (6691537) 19684 RON 103 1 3 COLLAR C (OLD 659-04300-20) (6684623) 1229 RON 104 1 1 6691768 (6691768) 2236 RON 105 1 1 AIR VENT RUBBER CAP (OLD 561-00070-20) (6691369) 2236 RON 106 1 1 6692171 (6692171) 3578 RON 107 1 1 AIR VENT PIPE (OLD 565-04410-20) (6691395) 3578 RON 108 1 1 6691389 (6691389) 6039 RON *109 1 3 HEX. HOLE BOLT 5X20/PS (OLD 994-63050-204) (6684634) 1229 RON *109 1 2 HEX. HOLE BOLT 5X20/PS (OLD 994-63050-204) (6684634) 1229 RON 110 1 1 ENGINE BED (OLD 940-04300-20) (6694785) 3578 RON 111 1 1 FUEL PIPE 3X5X80 (OLD 700-03005-08) (6684880) 1229 RON 112 1 1 CLIP 5.5 (OLD 680-00206-20) (6692305) 1229 RON 113 1 1 FUEL PIPE GROMMET (OLD 222-06300-20) (6688156) 1229 RON 114 1 1 HEX. SOCKET HD. BOLT M5X30 S (OLD 994-61050-304) (6684786) 1229 RON 115 1 1 WASHER M5 (OLD 992-01050-061) (6684918) 1229 RON 116 1 1 AIR VENT PIPE (OLD 565-04400-21) NEW (6691394) 2460 RON 131 1 1 MUFFLER PROTECTOR (OLD 738-0440A-21) (6692783) 6151 RON 132 1 1 HEX. HOLE BOLT M5X12/S (OLD 994-61050-124) (6684667) 1229 RON 133 1 1 HEX. HOLE BOLT M5X16/S (OLD 994-61050-164/6695490) (6684903) 1229 RON 134 1 2 HEX.HOLE BOLT 6X65 (OLD 990-51060-653) NEW (6695067) 1229 RON 135 1 2 WASHER 6 (OLD 992-01060-011) (6684639) 1229 RON 136 1 1 MUFFLER SET, PN (OLD 704-04400-90) (6692472) 15098 RON *137 1 2 WASHER M5 (OLD 992-01050-061) (6684918) 1229 RON *137 1 1 WASHER M5 (OLD 992-01050-061) (6684918) 1229 RON 138 1 1 TAIL PIPE (OLD 721-04400-20) (6692652) 2460 RON 139 1 1 MACHINE SCREW (W/SP. WASHER) M4X8 (OLD 994-34040-081) NEW NO (6685109) 1229 RON 140 1 1 MUFFLER ARRESTOR (OLD 732-04400-20) NEW (6692696) 2236 RON 141 1 1 MUFFLER GASKET (OLD 737-04230-20) (6692741) 1229 RON 142 1 1 HEAT SHIELD (OLD 133-04400-21) (OLD 6687245) (6687246) 573 RON *143 1 4 HEX. HOLE BOLT 5X20/PS (OLD 994-63050-204) (6684634) 1229 RON *143 1 2 HEX. HOLE BOLT 5X20/PS (OLD 994-63050-204) (6684634) 1229 RON 144 1 1 PRIMARY CORD GROMMET (OLD 203-10000-20) (6688055) 1229 RON 145 1 2 HEX. HOLE BOLT M5X25/S (OLD 994-16050-252) (6684709) 1229 RON 146 1 2 WASHER M5 (OLD 992-01050-061) (6684918) 1229 RON 147 1 2 CLUTCH WASHER B (OLD 359-10112-20) (6689645) 1229 RON 148 1 2 CLUTCH ARM COMP. (OLD 290-04200-81/6688613) (6688614) 488 RON 149 1 1 CLUTCH SPRING (OLD 342-04200-20) (6689428) 2236 RON 150 1 2 WAVE WASHER 10 (OLD 992-04100-030) (6695203) 1229 RON 151 1 2 CLUTCH STEP BOLT (OLD 357-04201-20) (6689632) 2460 RON 171 1 1 6692970 (6692970) 1232 RON 172 1 1 RECOIL STARTER BODY COMP. (OLD 772-04220-80) (6693025) 6822 RON 173 1 1 STARTER ROPE REEL (OLD 769-04220-20) (6693007) 3578 RON 174 1 1 RECOIL SPRING (OLD 779-04220-20) (6693114) 5480 RON 175 1 1 STARTER ROPE (OLD 783-04270-20/6693164) (6693165) 2460 RON 176 1 1 STARTER HANDLE CAP (OLD 835-04220-20) (6693607) 2236 RON 177 1 1 STARTER HANDLE (OLD 785-04220-20) (6693232) 2460 RON 178 1 1 SET SCREW (OLD 839-04220-20) (6693634) 1229 RON 191 1 2 THROTTLE SET SCREW (OLD 514-25100-20) (6684870) 1229 RON 192 1 1 CABLE ADJUSTER STAY (OLD 544-25164-20) (6684873) 2460 RON 193 1 1 SWIVEL (OLD 539-25120-20) (6684697) 2460 RON 194 1 1 THRUST WASHER (OLD 549-25165-20) (6684874) 1229 RON 195 1 1 STOP RING (OLD 489-25100-20) (6684696) 1229 RON 196 1 1 CABLE ADJUSTER (OLD 614-25137-20) (6684871) 2236 RON 197 1 1 O-RING (OLD 550-25100-20) (6684695) 2236 RON 198 1 1 MAIN JET, #44.5 (OLD 599-200BW-44) NEW (6696131) 3914 RON 199 1 1 LOCK NUT M6 (OLD 991-01060-013/6692005) (6684872) 1229 RON 200 1 1 PUMP GASKET (OLD 577-25100-20) (6691457) 4249 RON 201 1 1 PUMP DIAPHRAGM (OLD 576-25100-20/6696325) (6684693) 3242 RON 202 1 1 INLET SCREEN (OLD 578-25007-20/6691460) (6684700) 2236 RON 203 1 1 PUMP BODY COMP. (OLD 575-25153-80) (6684879) 15098 RON 204 1 1 DIAPHRAGM GASKET (OLD 475-25153-20) (6684691) 3242 RON 205 1 1 METERING DIAPHRAGM COMP. (OLD 474-25001-80/6690826) (6690827) 5591 RON 206 1 1 DIAPHRAGM COVER (OLD 476-25151-20) (6684688) 3242 RON 207 1 4 SET SCREW (OLD 548-25151-20/6696324) (6684699) 1229 RON 208 1 1 CLEANER PACKING (OLD 431-0634C-20) (6684875) 2236 RON 209 1 1 PRIMING PUMP COMP. (OLD 442-25151-80) (6684687) 5591 RON 210 1 1 PRIMING BODY (OLD 447-25108-20) (6684689) 2460 RON 231 1 1 CLUTCH SHAFT COMP. (OLD 289-04300-80) (6688584) 765 RON 232 1 2 BALL BEARING 6202Z 35MM/OD (OLD 999-61620-202) (6695559) Indisponibil Indisponibil 233 1 1 STOP RING C-15, OUTER (OLD 993-50015-002) (6695285) 1229 RON 234 1 1 CLUTCH CASE (OLD 331-04300-20) (6689194) 6933 RON 235 1 1 SQUARE NUT 5 (OLD 991-91050-001) (6695176) 1229 RON 236 1 1 CUSHION RUBBER (OLD 599-04300-20) (6691829) 3242 RON 238 1 1 HEX. HOLE BOLT 5X16 (OLD 990-51050-163) (6695046) 1229 RON 239 1 4 HEX. SOCKET HD. BOLT (W/BUTTON) M6X20 (OLD 990-53060-203) NE (6685064) 1229 RON 240 1 1 HEX HOLE BOLT 5 X 25 (OLD 990-54050-253) NEW (6695091) 1229 RON 241 1 1 - Indisponibil 242 1 1 PIPE HOLDER (OLD 360-04300-21) (6689655) 2460 RON 243 1 1 COLLAR 6.3 X 18 (OLD 096-04300-20) (6686746) 1229 RON 244 1 1 WASHER M5 (OLD 992-01050-061) (6684918) 1229 RON 245 1 1 METAL FITTING (OLD 361-00990-20) (6689664) 2460 RON 261 1 1 DRIVE SHAFT (OLD 343-37850-20) (6689471) 8611 RON 262 1 1 DRIVE SHAFT COMP. (OLD 341-37850-80/6689405) (6689400) 15098 RON 263 1 5 6689522 (6689522) 2236 RON 264 1 1 LIFTING METAL, 90 DGR SWIVEL (OLD 335-37307-20) (6689274) 2236 RON 265 1 2 LIFTING METAL COLLAR 26 (OLD 334-37352-21) (6689258) 2236 RON 266 1 2 HEX. HOLE BOLT 5X30.P (OLD 994-62050-304) (6695501) 1229 RON 267 1 1 SPECIAL NUT (OLD 315-37304-20) (6689100) 1229 RON 268 1 1 HANDLE GRIP (OLD 165-37590-20) (6684708) 2460 RON 269 1 4 HEX. HOLE BOLT M5X25/S (OLD 994-16050-252) (6684709) 1229 RON *270 1 1 HANDLE BRACKET A (OLD 506-37623-20) (6684710) 4137 RON *270 1 1 HANDLE BRACKET A (OLD 506-37304-21) (6691136) 4585 RON *271 1 1 HANDLE BRACKET B (OLD 507-37623-20) (6684711) 6039 RON *271 1 1 HANDLE BRACKET B, 26 DIA. (OLD 507-38100-20) NEW (6691161) 3130 RON 272 1 1 CUSHION RUBBER (OLD 510-37352-20) (6691187) 2236 RON *273 1 1 HANDLE BRACKET C (OLD 508-37623-20) (6684713) 3914 RON *273 1 1 HANDLE BRACKET C, 26 DIA. (OLD 508-37587-20) (6691173) 4025 RON 274 1 2 HEX. HOLE BUTTON SCREW 6X25S (OLD 994-81060-254) (6684714) 1229 RON 275 1 1 CUSHION PAD COMP. (OLD 336-33411-82) (6689285) 3242 RON 276 1 1 CLAMP B. (OLD 460-33111-20) (6684715) 1229 RON 277 1 1 LEFT HANDLE SK (OLD 502-33674-21) (6691087) 765 RON 278 1 1 PROTECTION TUBE (OLD 164-07086-50) NEW (6687546) 2236 RON 279 1 1 6696184 (6696184) 9394 RON 280 1 1 HANDLE RIGHT, BLACK (OLD 501-38101-20/6691071) (6696091) 9170 RON 281 1 1 6693765 (6693765) 17895 RON 282 1 1 SAFETY LEVER (OLD 253-38400-20) (6684721) 2460 RON 283 1 1 RETURN SPRING (OLD 832-38400-20) (6684722) 1229 RON 284 1 1 THROTTLE LEVER (OLD 880-38401-20) (6684723) 382 RON 285 1 1 BLIND PLUG (OLD 322-38400-20) (6684724) 1229 RON 286 1 2 SCREW M4X20 (BLACK) (OLD 993-46040-202) NEW (6684725) 1229 RON 287 1 1 SCREW 5X30 (BLACK) (OLD 994-31050-303) (6684726) 1229 RON 288 1 1 CONTAL NUT 5 (OLD 991-01050-043) (6684727) 1229 RON 289 1 1 STOP SWITCH (OLD 156-38401-80) (6687460) 6710 RON 290 1 1 THROTTLE WIRE (OLD 887-38401-80) (6694023) 6039 RON 291 1 1 THROTTLE WIRE COMP. (OLD 885-38401-80) (6693979) 13197 RON 311 1 1 DRIVE SHAFT (OLD 343-37850-20) (6689471) 8611 RON 312 1 1 DRIVE SHAFT COMP. (OLD 341-37850-80/6689405) (6689400) 15098 RON 313 1 5 6689522 (6689522) 2236 RON 314 1 1 LIFTING METAL, 90 DGR SWIVEL (OLD 335-37307-20) (6689274) 2236 RON 315 1 2 LIFTING METAL COLLAR 26 (OLD 334-37352-21) (6689258) 2236 RON 316 1 2 HEX. HOLE BOLT 5X30.P (OLD 994-62050-304) (6695501) 1229 RON 317 1 1 SPECIAL NUT (OLD 315-37304-20) (6689100) 1229 RON 318 1 1 HANDLE GRIP (OLD 165-37590-20) (6684708) 2460 RON 319 1 4 HEX. HOLE BOLT M5X25/S (OLD 994-16050-252) (6684709) 1229 RON 320 1 1 HANDLE BRACKET A (OLD 506-37623-20) (6684710) 4137 RON 321 1 1 HANDLE BRACKET (OLD 507-37850-20) NEW (6691158) 382 RON 322 1 1 HANDLE BRACKET C, 26 DIA. (OLD 508-37589-20) NEW (6691174) 2460 RON 323 1 2 HEX. HOLE BUTTON SCREW 6X25S (OLD 994-81060-254) (6684714) 1229 RON 324 1 1 HIP PAD (OLD 336-37857-80) (6689291) 5256 RON 325 1 1 CLAMP B. (OLD 460-33111-20) (6684715) 1229 RON 326 1 1 LEFT HANDLE (OLD 502-37415-21) (6684716) 7940 RON 327 1 1 PROTECTION TUBE (OLD 164-07086-50) NEW (6687546) 2236 RON 328 1 1 6696184 (6696184) 9394 RON 329 1 1 RIGHT HANDLE (OLD 501-38401-20/6684719) (6696092) 9170 RON 330 1 1 6693766 (6693766) 19684 RON 331 1 1 SAFETY LEVER (OLD 253-38400-20) (6684721) 2460 RON 332 1 1 RETURN SPRING (OLD 832-38400-20) (6684722) 1229 RON 333 1 1 THROTTLE LEVER (OLD 880-38401-20) (6684723) 382 RON 334 1 1 BLIND PLUG (OLD 322-38400-20) (6684724) 1229 RON 335 1 2 SCREW M4X20 (BLACK) (OLD 993-46040-202) NEW (6684725) 1229 RON 336 1 1 SCREW 5X30 (BLACK) (OLD 994-31050-303) (6684726) 1229 RON 337 1 1 CONTAL NUT 5 (OLD 991-01050-043) (6684727) 1229 RON *338 1 1 STOP SWITCH (OLD 156-38401-80) (6687460) 6710 RON *338 1 1 STOP SWITCH (OLD 156-38401-81) (6687461) 6710 RON 339 1 1 THROTTLE WIRE (OLD 887-38401-80) (6694023) 6039 RON *340 1 1 THROTTLE WIRE COMP. (OLD 885-38401-80) (6693979) 13197 RON *340 1 1 THROTTLE WIRE COMP. (OLD 885-38401-81) (6693980) 13197 RON 361 1 1 6688737 (6688737) 29750 RON 362 1 1 GEAR CASE ASSY, 26 DIA. (OLD 300-37587-90) (6688784) 36461 RON 363 1 2 HEX. HOLE BOLT M5X25/S (OLD 994-16050-252) (6684709) 1229 RON 364 1 1 STOP RING C-24.INNER (OLD 993-51024-002) (6684732) 1229 RON 365 1 1 STOP RING C-9, OUTER (OLD 993-50009-002) (6695281) 1229 RON 366 1 1 BALL BEARING 609Z ST (OLD 999-61609-002) (6684735) 3242 RON 367 1 1 BALL BEARING 609 (OLD 999-61609-000) (6684734) 3242 RON 368 1 1 GEAR CASE, SILVER (OLD 300-3330B-20) (6688685) 6710 RON 369 1 1 HEX. HOLE BOLT 5X10 (OLD 990-51050-103) (6695042) 1229 RON 370 1 1 PLUS HEAD BOLT 8X10 (OLD 994-23080-100/6694968) (6695437) 1229 RON 371 1 1 BALL BEARING 628 ST (OLD 999-61628-000) (6695569) 3242 RON 372 1 1 GEAR SHAFT (OLD 304-37134-20) (6688932) 5927 RON 373 1 1 GEAR SHAFT (OLD 304-38100-20) (6688945) 8164 RON 374 1 1 BALL BEARING 6201D, 32MM/OD (OLD 999-61620-103) (6695554) 3578 RON 375 1 1 STOP RING C-32, INNER (OLD 993-51032-002) (6695295) 1229 RON 376 1 1 CUTTER HOLDER, 12X10X1 (OLD 310-38100-20/6689017) (6689031) 5480 RON 377 1 1 CUTTER HOLDER CAP, 12X10X1 (OLD 311-37850-20) (6689050) 3242 RON 378 1 1 PROTECTION COVER B (OLD 308-33410-20) (6688990) 2236 RON 379 1 1 PROTECTION COVER B (OLD 308-37861-20) (6688994) 2236 RON 380 1 1 FIXING BOLT, L.H. (OLD 312-33386-20/6689063) (6689062) 2236 RON 381 1 1 CUTTER FIXING NUT,L/H (OLD 313-38100-20) (6689072) 2236 RON 382 1 1 GEAR CASE WASHER (OLD 324-37350-20/6689160) (6689159) 1229 RON 383 1 1 SPECIAL WASHER 1.0 (OLD 067-37134-20) NEW (6686453) 2236 RON 384 1 2 HEX. HOLE BUTTON SCREW 6X25S (OLD 994-81060-254) (6684714) 1229 RON 385 1 1 COVER BRACKET 26 (OLD 442-38331-20) (6690315) 3242 RON *386 1 1 SAFETY COVER, CE (OLD 441-38100-20) (6690270) 6710 RON *386 1 1 BLADE GUARD 26 CE (OLD 441-37380-21/6690241) (6690242) 8611 RON 387 1 1 SAFETY COVER HOLDER (OLD 445-37380-20) (6684748) 2236 RON *388 1 1 COVER GUARD (OLD 447-37380-20) (6690372) 573 RON 389 1 1 KNIFE (OLD 797-37380-21/6693385) (6693386) 3242 RON 390 1 1 SCREW 5X12/S (OLD 994-14050-121) (6695334) 1229 RON 391 1 1 GEAR-PINION SET, SPARE (OLD 301-37134-00) (6688868) 12526 RON 392 1 1 HEX. NUT 5 (OLD 991-01050-011) (6684965) 1229 RON 393 1 1 WINDING PROTECTOR COVER (OLD 307-38100-20) (6688986) 2460 RON 394 1 1 SPLIT PIN SET(10 PCS/PACK) (OLD 327-37180-90) (6689168) 1229 RON 395 1 1 BLADE GUARD 26CE (OLD 441-38331-20) (6690276) 9170 RON 396 1 1 BLADE GUARD (OLD 447-38331-20) (6690376) 5591 RON 397 1 1 KNIFE (OLD 797-37714-20) (6684750) 2236 RON 398 1 1 TAPPING SCREW 4X14 (OLD 993-48040-142) (6684751) 1229 RON *431 1 1 NYLON HEAD TH97L (OLD 6693215) (6697146) 23822 RON *431 1 1 NYLON HEAD TH97LM (OLD 783-33842-91/6693216) (6693217) 28967 RON 432 1 1 6693271 (6693271) 8499 RON 433 1 2 EYELET (OLD 788-33670-21) (6693328) 3578 RON 434 1 1 ADJUSTMENT BASE (OLD 785-33840-20) (6693247) 1229 RON 435 1 1 SPRING (SILVER) (OLD 793-33910-20/6693376) (6693377) 1229 RON 436 1 1 ADJUSTMENT WASHER (OLD 792-33004-20) (6693362) 1229 RON 437 1 1 CORD REEL BK (OLD 787-33840-21/6693291) (6693292) 6710 RON 438 1 3 STEEL BALL (OLD 673-35600-20) (6692271) 1229 RON 439 1 1 REEL SLIDER (OLD 790-33810-20) (6693358) 1229 RON 440 1 1 CUTTING BODY CAP (OLD 789-33840-20) (6693338) 6598 RON 441 1 1 MOUNTING BOLT,L-M8X1.25 (OLD 314-33670-20) (6689081) 3242 RON 442 1 1 MOUNTING NUT, L-M10X1.25 (OLD 315-33970-20) (6689098) 3914 RON 501 1 1 CUTTING BLADE 4TX255 TYPE M (OLD 802-33398-20/6696209) (6693434) 9059 RON 502 1 1 BLADE 80 TEETH 255 (OLD 809-37383-20) (6693492) 9394 RON 503 1 1 HEX. BAR WRENCH 4MM (OLD 813-20000-20) (6684813) 105 RON 504 1 1 BOX WRENCH (HEX. SOCKET 17/19) (OLD 826-20000-80) (6684764) 2460 RON 505 1 2 CUTTER COVER (OLD 615-37224-20/790290) (6684768) 1229 RON
