Top » Piese de schimb » PIESE HITACHI » TBC260PF TBC260PF [TBC260PF] Click pentru a mari Imagini suplimentare Click pentru a mari Click pentru a mari Click pentru a mari Click pentru a mari Click pentru a mari Click pentru a mari Click pentru a mari Click pentru a mari Click pentru a mari LISTA DE COMPONENTE: Numar Versiune Buc. in schema Denumire Pret/buc (Tva inclus) Cumpara 1 1 1 6684894 (6684894) 3242 RON 2 1 1 SPARK PLUG CJ6 (OLD 018-02233-20) (6685052) 1564 RON 3 1 1 CYLINDER SET (OLD 001-07600-90) (6684897) 18789 RON 4 1 4 HEX. HOLE BOLT M5X18/S (OLD 994-61050-184) (6684586) 1229 RON 5 1 1 CYLINDER GASKET (OLD 017-07350-20) (6684896) 1229 RON 6 1 2 PISTON RING (OLD 041-01601-20) (6684588) 3242 RON 7 1 1 PISTON SET (OLD 030-07500-90) (6684898) 9282 RON 8 1 2 PISTON PIN CIRCLIP (OLD 039-00601-20) (6684590) 1229 RON 9 1 1 PISTON PIN (OLD 037-07045-20/6686010) (6684591) Indisponibil Indisponibil 10 1 1 CRANK SHAFT COMP. (OLD 046-07350-82) (6686219) 30645 RON 12 1 1 STOP CORD B 190M (OLD 178-01680-80) NEW (6687836) 2236 RON 13 1 1 EARTH CORDB 165M (OLD 274-01680-80) NEW (6688443) 1229 RON 15 1 2 HEX. HOLE BOLT M4X18/WS (OLD 994-64040-184) (6684599) 1229 RON 16 1 2 WASHER (OLD 182-0186A-20) (6684600) 1229 RON 17 1 1 IGNITION COIL ASSY (OLD 167-21012-90/6687683) (6687684) 13197 RON *31 1 1 GEAR SHAFT SHIM 0.20 (OLD 330-00200-23) (6684604) 1229 RON *31 1 1 GEAR SHAFT SHIM 0.30 (OLD 330-00200-24) (6684605) 1229 RON 32 1 1 6684905 (6684905) 13197 RON 33 1 2 OIL SEAL TB 12227 (OLD 999-66122-200/6695624) (6684607) Indisponibil Indisponibil 34 1 2 BALL BEARING 6001 C3 NSK (OLD 999-61600-115/6684608/6695530) (6695535) 3131 RON 35 1 1 CRANK CASE GASKET (OLD 090-07350-22) (6684904) 1229 RON 36 1 4 HEX. HOLE BOLT M5X16/S (OLD 994-61050-164/6695490) (6684903) 1229 RON 37 1 1 MAGNETO ROTOR COMP. (OLD 155-21012-81) (6687384) 8388 RON 38 1 1 WASHER M8 (OLD 992-01080-011) (6684611) 1229 RON 39 1 1 HEX.NUT M8 (OLD 991-01080-011) (6684612) 1229 RON 51 1 1 INLET MANIFOLD GASKET (OLD 403-07020-21) (6689895) 1229 RON 52 1 1 INSULATOR SET (OLD 404-07020-91) (6689972) 382 RON 53 1 2 HEX. HOLE BOLT 5X25/WS (OLD 994-64050-255) (6684617) 1229 RON 54 1 1 CARBURETOR GASKET (OLD 402-0656A-20) (6684616) 1229 RON 55 1 1 CHOKE PLATE 2.0 (OLD 528-0652N-22/6691275) (6691276) 1229 RON 56 1 1 CLEANER BODY COMP. (OLD 423-0652N-80) (6690120) 3242 RON 57 1 1 CLEANER SPONGE (OLD 446-0652N-20) (6690365) 1229 RON 58 1 1 6690402 (6690402) 6039 RON 59 1 1 COVER FIXING BOLT (OLD 450-07024-80) (6690384) 1564 RON 60 1 2 SCREW 5X55 (OLD 990-11050-552) (6694914) 1229 RON 61 1 2 S.WASHER 5 (OLD 992-10050-012/6695214) (6684662) 1229 RON 62 1 2 SMALL WASHER 5 (OLD 992-00050-011) (6684864) 1229 RON 63 1 1 CARBURETOR SET WYJ318 (OLD 455-03045-90) (6690465) 24717 RON 64 1 1 CHOKE CONTROL LEVER (OLD 523-0652N-20) (6691239) 1229 RON *65 1 1 TANK WHITE (OLD 591-07350-22/6691519/6691601/04) (6691602) 5480 RON *65 1 1 TANK (EVAPO) (OLD 591-0735F-20) NEW (6691605) 16888 RON 66 1 1 STAND (OLD 940-07350-20) (6694787) 2460 RON 67 1 3 COLLAR C (OLD 659-04300-20) (6684623) 1229 RON 68 1 1 RETURN GROMMET (OLD 534-32710-20) (6684627) 105 RON 69 1 1 FUEL PIPE 3X5X65 (OLD 700-03005-06/700-03005-065) (6684626) 1229 RON 70 1 1 PUMP FILTER BODY COMP. (OLD 675-04042-80) (6684620) 3242 RON 71 1 1 CLIP.6.3 DIA. (OLD 680-00731-20) (6684619) 1229 RON 72 1 1 6684618 (6684618) 2236 RON 73 1 1 HEX. HOLE BOLT 5X25/WS (OLD 994-64050-255) (6684617) 1229 RON 74 1 2 HEX. HOLE BOLT 5X20/PS (OLD 994-63050-204) (6684634) 1229 RON 75 1 1 6691748 (6691748) 4585 RON 76 1 1 TAP SCREW 4X14 P (OLD 993-49040-142/6695112) (6695280) 1229 RON 77 1 1 BOLT WASHER M4 (OLD 992-01040-011) (6685070) 1229 RON 91 1 1 CYLINDER COVER (BLK) (OLD 016-07500-20) (6685693) 3466 RON 92 1 2 HEX.HOLE BOLT 5X16/PS (OLD 994-63050-164) (6695504) 1229 RON 93 1 2 HEX.HOLE BOLT 6X65 (OLD 990-51060-653) NEW (6695067) 1229 RON 94 1 2 WASHER 6 (OLD 992-01060-011) (6684639) 1229 RON 95 1 1 MUFFLER COMP. (OLD 706-07500-80) (6692576) 29750 RON 96 1 1 TAIL PIPE GASKET (OLD 751-07250-20) (6692888) 1229 RON 97 1 1 TAIL PIPE SET (OLD 734-07255-90) (6692715) 2460 RON 98 1 2 SCREW M4X8/WS (OLD 994-36040-081) (6684651) 1229 RON 99 1 1 SPARK ARRESTER (OLD 732-07250-20) (6692701) 2236 RON 100 1 1 HEAT SHIELD (OLD 133-07500-20) (6687265) 3242 RON 101 1 1 MUFFLER PROTECTOR BLK (OLD 738-07500-20) (6692818) 6262 RON 102 1 2 HEX. HOLE BOLT 4X18WS (OLD 994-64040-185) NEW (6695508) 1229 RON 103 1 1 PLUG COVER (OLD 257-03045-20) (6688344) 2460 RON 104 1 2 CLUTCH WASHER B (OLD 359-02103-20) (6684642) 1229 RON 105 1 2 CLUTCH SHOE COMP. (OLD 290-01620-80) (6684643) 3578 RON 106 1 1 CLUTCH SPRING (OLD 342-0630B-20) (6684644) 1229 RON 107 1 2 CLUTCH PLATE A 0.5 (OLD 348-0630A-20/6689529) (6684645) 1229 RON 108 1 2 STEP BOLT (OLD 357-0075T-20) (6684646) 1229 RON 109 1 3 HEX. HOLE BOLT 5X20/PS (OLD 994-63050-204) (6684634) 1229 RON 110 1 2 BENT WASHER 8 (OLD 992-05080-030/6695204) (6684648) 1229 RON 111 1 1 TAPPING SCREW D4.5X16 (OLD 990-72045-164) (6684636) 1229 RON 131 1 1 6684938 (6684938) Indisponibil Indisponibil 132 1 1 RECOIL STARTER BODY COMP. (OLD 772-03045-80) (6684944) 5815 RON 133 1 1 STARTER ROPE REEL (OLD 774-03045-20) (6684941) 2460 RON 134 1 1 RECOIL SPRING (OLD 779-03045-20) (6684942) 3578 RON 135 1 1 SWING ARM (OLD 777-03045-20) (6684940) 1229 RON 136 1 1 SET SCREW (OLD 839-03045-20) (6684679) 1229 RON 137 1 1 PULLEY STAY (OLD 771-03045-20) (6684939) 1229 RON 138 1 1 ROPE 3.0X800 (OLD 783-03045-20) (6684943) 2236 RON 139 1 1 STARTER HANDLE (OLD 785-03045-20) (6684680) 1229 RON 140 1 1 STARTER PULLEY (OLD 798-03045-20) (6684937) 2460 RON 141 1 2 HEX. HOLE BOLT 4X18WS (OLD 994-64040-185) NEW (6695508) 1229 RON 142 1 1 SPECIAL NUT M5 (OLD 315-33340-20) NEW (6685000) 1229 RON 161 1 1 PUMP BODY COMP. (OLD 575-25153-80) (6684879) 15098 RON 162 1 1 PRIMING PUMP COMP. (OLD 442-25151-80) (6684687) 5591 RON 163 1 1 DIAPHRAGM COVER (OLD 476-25151-20) (6684688) 3242 RON 164 1 1 PRIMING BODY (OLD 447-25108-20) (6684689) 2460 RON 165 1 1 METERING DIAPHRAGM COMP. (OLD 474-25241-80) (6690830) 573 RON 166 1 1 DIAPHRAGM GASKET (OLD 475-25153-20) (6684691) 3242 RON 167 1 1 PUMP DIAPHRAGM (OLD 576-25100-20/6696325) (6684693) 3242 RON 168 1 1 PUMP GASKET (OLD 577-25100-20) (6691457) 4249 RON 169 1 1 MAIN JET #38.5 (OLD 599-200BW-38/6691874) (6696130) 3578 RON 170 1 1 O-RING (OLD 550-25100-20) (6684695) 2236 RON 171 1 1 STOP RING (OLD 489-25100-20) (6684696) 1229 RON 172 1 1 SWIVEL (OLD 539-25120-20) (6684697) 2460 RON 173 1 2 THROTTLE SET SCREW (OLD 514-25100-20) (6684870) 1229 RON 174 1 1 CABLE ADJUSTER STAY (OLD 544-25164-20) (6684873) 2460 RON 175 1 1 LOCK NUT M6 (OLD 991-01060-013/6692005) (6684872) 1229 RON 176 1 1 CABLE ADJUSTER (OLD 614-25137-20) (6684871) 2236 RON 177 1 1 CLEANER PACKING (OLD 431-0634C-20) (6684875) 2236 RON 178 1 4 SET SCREW (OLD 548-25151-20/6696324) (6684699) 1229 RON 179 1 1 THRUST WASHER (OLD 549-25165-20) (6684874) 1229 RON 180 1 1 INLET SCREEN (OLD 578-25007-20/6691460) (6684700) 2236 RON 201 1 1 CLUTCH DRUM COMP. (OLD 289-03070-80) (6688580) 6486 RON 202 1 1 STOP RING C-12 OUTER (OLD 993-50012-002) (6684664) 1229 RON 203 1 1 CUSHION RUBBER (OLD 599-00980-21) (6691823) 2460 RON 204 1 1 HEX. HOLE BOLT 5X16 (OLD 990-51050-163) (6695046) 1229 RON 205 1 1 HEX. HOLE BOLT M5X25/S (OLD 994-16050-252) (6684709) 1229 RON 206 1 1 FAN CASE COMP. (OLD 112-03045-80) (6686959) 7940 RON 207 1 1 PIPE HOLDER, TPE (OLD 360-00996-20/6689650) (6689651) 3578 RON 208 1 1 WASHER M5 (OLD 992-01050-061) (6684918) 1229 RON 209 1 1 GEAR CASE WASHER (OLD 324-37350-20/6689160) (6689159) 1229 RON 210 1 1 METAL FITTING (OLD 361-00990-20) (6689664) 2460 RON 231 1 1 DRIVE SHAFT 1487L (OLD 343-38170-20) (6689477) 7381 RON 232 1 1 DRIVE SHAFT PIPE COMP. (OLD 341-37623-82/6689385) (6689386) 15098 RON 233 1 5 6684831 (6684831) 1229 RON 234 1 2 HEX.NUT 6 (OLD 6684792/991-01060-041) (6684835) 1229 RON 235 1 1 LOOP HANDLE, 24 DIA.,BLACK (OLD 500-37286-20) (6691046) 3578 RON 236 1 1 HANDLE BRACKET A (OLD 506-37300-20) (6691134) 2236 RON 237 1 1 HANDLE GRIP (OLD 503-3738E-20) (6691098) 3914 RON 238 1 2 BOLT 6X43/P (BLACK) (OLD 994-23060-432) (6684838) 1229 RON 239 1 1 THROTTLE WIRE COMP., 4T (OLD 885-37394-80) (6693963) 2460 RON 240 1 1 TAPPING SCREW 5X20 (OLD 993-11052-012) (6695255) 1229 RON 241 1 1 BRAKE SHAFT WASHER (OLD 368-32350-20) (6689681) 1229 RON 242 1 1 6693736 (6693736) 8611 RON 243 1 1 STOP SWITCH (OLD 162-37101-20) (6687515) 2236 RON 244 1 3 TAPPING SCREW 3X8 (OLD 993-42030-081) (6695274) 1229 RON 245 1 1 STOP SWITCH BASE (OLD 259-37101-20) (6688374) 2236 RON 246 1 1 STOP SWITCH SPRING (OLD 262-37101-20) NEW (6688385) 2236 RON 247 1 1 EARTH TERMINAL B (OLD 177-37101-20) (6687805) 2236 RON 248 1 1 EARTH TERMINAL A (OLD 176-37101-20) NEW (6687801) 2236 RON 249 1 2 SPECIAL NUT M5 (OLD 315-33340-20) NEW (6685000) 1229 RON 250 1 1 STOP RING E-6 (OLD 993-55060-001) (6695311) 1229 RON 251 1 1 RETURN SPRING (OLD 832-37101-20) NEW (6693601) 1229 RON 252 1 1 THROTTLE ARM (OLD 880-37286-20) (6693804) 2460 RON 253 1 2 SCREW 5X20 (OLD 994-31050-201) NEW (6695453) 1229 RON 254 1 1 LOCK BUTTON SHAFT (OLD 853-37101-20) (6693653) 1229 RON 255 1 1 LOCK BUTTON SPRING (OLD 958-37101-20) NEW (6694834) 1229 RON 256 1 1 LOCK BUTTON (OLD 956-37101-20) NEW (6694829) 2236 RON 258 1 2 STOP CORD, B430M (OLD 178-37394-80) NEW (6687915) 2236 RON 259 1 1 PROTECTION TUBE 10X190L (OLD 164-10019-00) NEW (6687563) 1229 RON 260 1 1 SHAFT GRIP (OLD 504-37300-20) NEW (6691111) 3578 RON 281 1 1 GEAR CASE ASSY 24 (OLD 300-38159-91) NEW (6688812) 36461 RON 282 1 2 HEX. HOLE BOLT M5X25/S (OLD 994-16050-252) (6684709) 1229 RON 283 1 1 STOP RING C-22, INNER (OLD 993-51022-002) (6695293) 1229 RON 284 1 1 STOP RING OUTER 10 (OLD 993-57010-002) (6695315) 1229 RON 285 1 1 BALL BEARING (OLD 999-61690-002) (6695579) 3578 RON 286 1 1 BALL BEARING 6900, 22MM/OD (OLD 999-61690-000) (6695577) 4025 RON 287 1 1 GEAR CASE 24 (OLD 300-38150-21) (6688808) 8276 RON 288 1 1 HEX. HOLE BOLT M5X12/S (OLD 994-61050-124) (6684667) 1229 RON 289 1 1 OILING BOLT (OLD 316-38150-20) (6689109) 1229 RON 290 1 1 BALL BEARING 609 (OLD 999-61609-000) (6684734) 3242 RON 291 1 1 GEAR SHAFT (OLD 304-38150-20) (6688946) 9842 RON 292 1 1 BALL BEARING 6201D, 32MM/OD (OLD 999-61620-103) (6695554) 3578 RON 293 1 1 STOP RING C-32, INNER (OLD 993-51032-002) (6695295) 1229 RON 294 1 1 CUTTER HOLDER (OLD 310-38150-20) (6689032) 5591 RON 295 1 1 GEAR CASE WASHER (OLD 324-37350-20/6689160) (6689159) 1229 RON 296 1 2 HEX. HOLE BUTTON SCREW 6X25S (OLD 994-81060-254) (6684714) 1229 RON 297 1 1 SAFETY GUARD BRACKET (OLD 442-37417-20) (6685065) 2236 RON 298 1 1 SAFETY COVER, 24 DIA. (OLD 441-38150-20) NEW (6690272) 6374 RON 299 1 1 SAFETY GUARD HOLDER (OLD 445-38150-20) (6690343) 2460 RON 300 1 1 KNIFE (OLD 797-38150-20) NEW (6693388) 382 RON 301 1 1 TAPPING SCREW 5X20 (OLD 993-17052-002) (6684753) 1229 RON 302 1 1 GEAR PINION SET SPARE (OLD 301-38150-00) (6688882) 956 RON 303 1 2 HEX. HOLE BOLT M5X12/S (OLD 994-61050-124) (6684667) 1229 RON 341 1 1 NYLON HEAD SURE-TAP U2 BF5 (OLD 783-3383B-91) (6693214) 17894 RON 342 1 1 MOUNTING NUT L-M10X1.25 (OLD 356-3383B-20) (6684756) 3466 RON 343 1 1 CUTTING BODY (OLD 786-33830-20) (6684757) 6151 RON 344 1 1 SPECIAL NUT (OLD 315-33830-20) (6684758) 3578 RON 345 1 1 REEL SPRING (OLD 793-33830-20) (6684759) 2236 RON 346 1 1 SPOOL (OLD 787-33830-20) (6684760) 5368 RON 347 1 1 CUTTING BODY CAP (OLD 789-33830-20) (6684761) 9730 RON 348 1 2 EYELET (OLD 788-33830-20) (6684762) 2236 RON 349 1 1 BOLT WASHER M12 (OLD 992-01120-011) NEW (6685072) 1229 RON 350 1 1 MOUNTING NUT L-M8X1.25 (OLD 356-3383E-20) (6689624) 4697 RON 351 1 1 MANUAL SURE TAP (OLD 967-37820-21)NEW (6697612) 2236 RON 501 1 1 HEX. BAR WRENCH 4MM (OLD 813-20000-20) (6684813) 105 RON 502 1 1 BOX WRENCH (HEX. SOCKET 17/19) (OLD 826-20000-80) (6684764) 2460 RON
