Top » Piese de schimb » PIESE HITACHI » TBC255PF TBC255PF [TBC255PF] Click pentru a mari Imagini suplimentare Click pentru a mari Click pentru a mari Click pentru a mari Click pentru a mari Click pentru a mari Click pentru a mari Click pentru a mari Click pentru a mari Click pentru a mari LISTA DE COMPONENTE: Numar Versiune Buc. in schema Denumire Pret/buc (Tva inclus) Cumpara 1 1 1 6684894 (6684894) 3242 RON 2 1 1 SPARK PLUG CJ6 (OLD 018-02233-20) (6685052) 1564 RON 3 1 1 CYLINDER SET (OLD 001-07600-90) (6684897) 18789 RON 4 1 4 HEX. HOLE BOLT M5X18/S (OLD 994-61050-184) (6684586) 1229 RON 5 1 1 CYLINDER GASKET (OLD 017-07350-20) (6684896) 1229 RON 6 1 2 PISTON RING (OLD 041-01601-20) (6684588) 3242 RON 7 1 1 PISTON SET (OLD 030-07500-90) (6684898) 9282 RON 8 1 2 PISTON PIN CIRCLIP (OLD 039-00601-20) (6684590) 1229 RON 9 1 1 PISTON PIN (OLD 037-07045-20/6686010) (6684591) Indisponibil Indisponibil 10 1 1 CRANK SHAFT COMP. (OLD 046-07350-82) (6686219) 30645 RON 12 1 1 STOP CORD B 190M (OLD 178-01680-80) NEW (6687836) 2236 RON 13 1 1 EARTH CORDB 165M (OLD 274-01680-80) NEW (6688443) 1229 RON 15 1 2 HEX. HOLE BOLT M4X18/WS (OLD 994-64040-184) (6684599) 1229 RON 16 1 2 WASHER (OLD 182-0186A-20) (6684600) 1229 RON 17 1 1 IGNITION COIL ASSY (OLD 167-21012-90/6687683) (6687684) 13197 RON *31 1 1 GEAR SHAFT SHIM 0.20 (OLD 330-00200-23) (6684604) 1229 RON *31 1 1 GEAR SHAFT SHIM 0.30 (OLD 330-00200-24) (6684605) 1229 RON 32 1 1 6684905 (6684905) 13197 RON 33 1 2 OIL SEAL TB 12227 (OLD 999-66122-200/6695624) (6684607) Indisponibil Indisponibil 34 1 2 BALL BEARING 6001 C3 NSK (OLD 999-61600-115/6684608/6695530) (6695535) 3131 RON 35 1 1 CRANK CASE GASKET (OLD 090-07350-22) (6684904) 1229 RON 36 1 4 HEX. HOLE BOLT M5X16/S (OLD 994-61050-164/6695490) (6684903) 1229 RON 37 1 1 MAGNETO ROTOR COMP. (OLD 155-21012-81) (6687384) 8388 RON 38 1 1 WASHER M8 (OLD 992-01080-011) (6684611) 1229 RON 39 1 1 HEX.NUT M8 (OLD 991-01080-011) (6684612) 1229 RON 51 1 1 INLET MANIFOLD GASKET (OLD 403-07020-21) (6689895) 1229 RON 52 1 1 INSULATOR SET (OLD 404-07020-91) (6689972) 382 RON 53 1 2 HEX. HOLE BOLT 5X25/WS (OLD 994-64050-255) (6684617) 1229 RON 54 1 1 SWIVEL CAP (OLD 560-07120-20) (6684628) 105 RON 55 1 1 CARBURETOR GASKET (OLD 402-0656A-20) (6684616) 1229 RON 56 1 1 THROTTLE WIRE FIXING PLATE (OLD 878-06620-20) (6684629) 2236 RON 57 1 1 CABLE ADJUSTER (OLD 614-25137-20) (6684871) 2236 RON 58 1 1 LOCK NUT M6 (OLD 991-01060-013/6692005) (6684872) 1229 RON 59 1 1 CARBURETOR GASKET (OLD 402-0602K-21/6689836) (6684615) 1229 RON 60 1 1 O-RING P-15 (OLD 999-67015-000) (6695670) 105 RON 61 1 2 6684660 - Indisponibil 62 1 2 S.WASHER 5 (OLD 992-10050-012/6695214) (6684662) 1229 RON 63 1 2 WASHER 5 (OLD 992-01050-011) (6684661) 1229 RON 64 1 1 CARBURETOR SET WYL222 (OLD 455-03070-90) NEW (6690466) 26395 RON *65 1 1 TANK WHITE (OLD 591-07350-22/6691519/6691601/04) (6691602) 5480 RON *65 1 1 TANK (EVAPO) (OLD 591-0735F-20) NEW (6691605) 16888 RON 66 1 1 STAND (OLD 940-07350-20) (6694787) 2460 RON 67 1 3 COLLAR C (OLD 659-04300-20) (6684623) 1229 RON 68 1 1 RETURN GROMMET (OLD 534-32710-20) (6684627) 105 RON 69 1 1 FUEL PIPE 3X5X65 (OLD 700-03005-06/700-03005-065) (6684626) 1229 RON 70 1 1 PUMP FILTER BODY COMP. (OLD 675-04042-80) (6684620) 3242 RON 71 1 1 CLIP.6.3 DIA. (OLD 680-00731-20) (6684619) 1229 RON 72 1 1 6684618 (6684618) 2236 RON 73 1 1 HEX. HOLE BOLT 5X25/WS (OLD 994-64050-255) (6684617) 1229 RON 74 1 2 HEX. HOLE BOLT 5X20/PS (OLD 994-63050-204) (6684634) 1229 RON 75 1 1 6691748 (6691748) 4585 RON 91 1 1 CYLINDER COVER (BLK) (OLD 016-07500-20) (6685693) 3466 RON 92 1 2 HEX.HOLE BOLT 5X16/PS (OLD 994-63050-164) (6695504) 1229 RON 93 1 2 HEX.HOLE BOLT 6X65 (OLD 990-51060-653) NEW (6695067) 1229 RON 94 1 2 WASHER 6 (OLD 992-01060-011) (6684639) 1229 RON 95 1 1 MUFFLER COMP. (OLD 706-07500-80) (6692576) 29750 RON 96 1 1 TAIL PIPE GASKET (OLD 751-07250-20) (6692888) 1229 RON 97 1 1 TAIL PIPE SET (OLD 734-07255-90) (6692715) 2460 RON 98 1 2 SCREW M4X8/WS (OLD 994-36040-081) (6684651) 1229 RON 99 1 1 SPARK ARRESTER (OLD 732-07250-20) (6692701) 2236 RON 100 1 1 HEAT SHIELD (OLD 133-07500-20) (6687265) 3242 RON 101 1 1 MUFFLER PROTECTOR BLK (OLD 738-07500-20) (6692818) 6262 RON 102 1 2 HEX. HOLE BOLT 4X18WS (OLD 994-64040-185) NEW (6695508) 1229 RON 103 1 1 PLUG COVER (OLD 257-03045-20) (6688344) 2460 RON 104 1 2 CLUTCH WASHER B (OLD 359-02103-20) (6684642) 1229 RON 105 1 2 CLUTCH SHOE COMP. (OLD 290-01620-80) (6684643) 3578 RON 106 1 1 CLUTCH SPRING (OLD 342-0630B-20) (6684644) 1229 RON 107 1 2 CLUTCH PLATE A 0.5 (OLD 348-0630A-20/6689529) (6684645) 1229 RON 108 1 2 STEP BOLT (OLD 357-0075T-20) (6684646) 1229 RON 109 1 3 HEX. HOLE BOLT 5X20/PS (OLD 994-63050-204) (6684634) 1229 RON 110 1 1 CORD CLAMP COMP. (OLD 198-11600-80) NEW FEB (6688011) 1229 RON 111 1 2 BENT WASHER 8 (OLD 992-05080-030/6695204) (6684648) 1229 RON 112 1 1 TAPPING SCREW D4.5X16 (OLD 990-72045-164) (6684636) 1229 RON 131 1 1 6684938 (6684938) Indisponibil Indisponibil 132 1 1 RECOIL STARTER BODY COMP. (OLD 772-03045-80) (6684944) 5815 RON 133 1 1 STARTER ROPE REEL (OLD 774-03045-20) (6684941) 2460 RON 134 1 1 RECOIL SPRING (OLD 779-03045-20) (6684942) 3578 RON 135 1 1 SWING ARM (OLD 777-03045-20) (6684940) 1229 RON 136 1 1 SET SCREW (OLD 839-03045-20) (6684679) 1229 RON 137 1 1 PULLEY STAY (OLD 771-03045-20) (6684939) 1229 RON 138 1 1 ROPE 3.0X800 (OLD 783-03045-20) (6684943) 2236 RON 139 1 1 STARTER HANDLE (OLD 785-03045-20) (6684680) 1229 RON 140 1 1 STARTER PULLEY (OLD 798-03045-20) (6684937) 2460 RON 141 1 2 HEX. HOLE BOLT 4X18WS (OLD 994-64040-185) NEW (6695508) 1229 RON 151 1 1 6690005 (6690005) 573 RON 152 1 1 AIR CLEANER CAP (OLD 424-00025-20) (6690139) 3242 RON 153 1 1 CLEANER ELEMENT (OLD 446-00025-20) (6690347) 3242 RON 154 1 2 COLLAR (OLD 470-00025-20) (6690801) 2236 RON 155 1 1 CLEANER BODY COMP. (OLD 423-00025-80) (6690085) 5368 RON 171 1 1 PUMP BODY COMP. (OLD 575-25153-80) (6684879) 15098 RON 172 1 1 PRIMING PUMP COMP. (OLD 442-25151-80) (6684687) 5591 RON 173 1 1 DIAPHRAGM COVER (OLD 476-25151-20) (6684688) 3242 RON 174 1 1 PRIMING BODY (OLD 447-25108-20) (6684689) 2460 RON 175 1 1 METERING DIAPHRAGM COMP. (OLD 474-25241-80) (6690830) 573 RON 176 1 1 DIAPHRAGM GASKET (OLD 475-25153-20) (6684691) 3242 RON 177 1 1 PUMP DIAPHRAGM (OLD 576-25100-20/6696325) (6684693) 3242 RON 178 1 1 PUMP GASKET (OLD 577-25100-20) (6691457) 4249 RON 179 1 1 LONG MAIN JET #33.5 (OLD 599-200BW-33) NEW (6691887) 3914 RON 180 1 1 O-RING (OLD 550-25100-20) (6684695) 2236 RON 181 1 1 STOP RING (OLD 489-25100-20) (6684696) 1229 RON 182 1 1 SWIVEL (OLD 539-25120-20) (6684697) 2460 RON 183 1 2 THROTTLE SET SCREW (OLD 548-25140-20) (6684698) 2236 RON 184 1 4 SET SCREW (OLD 548-25151-20/6696324) (6684699) 1229 RON 185 1 1 INLET SCREEN (OLD 578-25007-20/6691460) (6684700) 2236 RON 201 1 1 CLUTCH DRUM COMP. (OLD 289-03070-80) (6688580) 6486 RON 202 1 1 STOP RING C-12 OUTER (OLD 993-50012-002) (6684664) 1229 RON 203 1 1 CUSHION RUBBER (OLD 599-00980-21) (6691823) 2460 RON 204 1 1 HEX. HOLE BOLT 5X16 (OLD 990-51050-163) (6695046) 1229 RON 205 1 1 HEX. HOLE BOLT M5X25/S (OLD 994-16050-252) (6684709) 1229 RON 206 1 1 FAN CASE COMP. (OLD 112-03045-80) (6686959) 7940 RON 207 1 1 PIPE HOLDER, TPE (OLD 360-00996-20/6689650) (6689651) 3578 RON 208 1 1 WASHER M5 (OLD 992-01050-061) (6684918) 1229 RON 209 1 1 GEAR CASE WASHER (OLD 324-37350-20/6689160) (6689159) 1229 RON 210 1 1 METAL FITTING (OLD 361-00990-20) (6689664) 2460 RON 221 1 1 DRIVE SHAFT 1480L (OLD 343-38379-20/6689479) (6696009) 6486 RON 222 1 1 DRIVE SHAFT PIPE COMP.1450L (OLD 341-38360-81/6689383) (6689410) 12526 RON 223 1 5 6684831 (6684831) 1229 RON 224 1 3 NUT M5 (BLACK) (OLD 991-01050-041) (6685075) 1229 RON 225 1 1 FRONT HANDLE 24 (OLD 500-38451-20) NEW (6691057) 5032 RON 226 1 3 HEX.HOLE BOLT 5X30S (OLD 994-16050-301) NEW (6695426) 1229 RON 227 1 1 THROTTLE WIRE 335+70 (OLD 885-38230-80) NEW (6693977) 4025 RON 228 1 1 6693770 (6693770) 9730 RON 229 1 1 THROTTLE LEVER (OLD 880-38451-20) NEW (6685006) 1229 RON 230 1 1 RETURN SPRING (OLD 832-38451-20) NEW (6684998) 1229 RON 231 1 1 STOP SWITCH (OLD 162-38451-20) NEW (6685009) 2236 RON 232 1 1 SWITCH MARK (OLD 925-38451-20) NEW (6685003) 1229 RON 233 1 1 STOP SWITCH COMP. (OLD 156-38451-80) NEW (6687462) 5591 RON 234 1 3 MACHINE SCREW M5X30 (OLD 990-11050-301) (6685076) 1229 RON 235 1 3 HEX. NUT 5 (OLD 991-01050-011) (6684965) 1229 RON 236 1 1 PROTECTION TUBE D7X170 (OLD 164-07017-01) NEW (6685007) 2236 RON 237 1 1 SHAFT GRIP (OLD 509-38453-21) NEW (6691183) 3242 RON 251 1 1 6688819 (6688819) 28967 RON 252 1 1 HEX. HOLE BOLT M5X25/S (OLD 994-16050-252) (6684709) 1229 RON 253 1 1 STOP RING C-24.INNER (OLD 993-51024-002) (6684732) 1229 RON 254 1 1 STOP RING C-9, OUTER (OLD 993-50009-002) (6695281) 1229 RON 255 1 1 BALL BEARING 609Z ST (OLD 999-61609-002) (6684735) 3242 RON 256 1 1 GEAR CASE 24 (OLD 300-38360-21) NEW DEC (6688815) 5927 RON 257 1 2 HEX. HOLE BOLT M5X12/S (OLD 994-61050-124) (6684667) 1229 RON 258 1 1 OILING BOLT (OLD 316-38150-20) (6689109) 1229 RON 259 1 1 BALL BEARING 626 , 19MM/OD (OLD 999-61626-000) (6695567) 3242 RON 260 1 1 GEAR SHAFT (OLD 304-38451-20) NEW (6688949) 6822 RON 261 1 1 BALL BEARING 6000D 26MM/OD (OLD 999-61600-003) NEW (6695527) 4025 RON 262 1 1 STOP RING C-26, INNER (OLD 993-51026-002) NEW (6695294) 1229 RON 263 1 1 CUTTER HOLDER (OLD 310-38360-20) (6689033) 3914 RON 264 1 2 HEX. SOCKET HD. BOLT (W/BUTTON) M6X20 (OLD 990-53060-203) NE (6685064) 1229 RON 265 1 2 S.WASHER 6 (OLD 992-10060-062) (6684826) 1229 RON 266 1 2 SAFETY GUARD BRACKET (OLD 442-37417-20) (6685065) 2236 RON 267 1 1 SAFETY COVER COMP. (OLD 441-37820-80) (6685066) 6933 RON 268 1 1 KNIFE (OLD 797-37820-20) NEW (6685067) 382 RON 269 1 2 MACHINE SCREW (W/SP. WASHER) M4X12 (OLD 994-14040-121) (6685068) 1229 RON 270 1 1 GEAR/PINION SET (OLD 301-38360-00) (6688883) 7269 RON 271 1 2 NUT M4 (OLD 991-01040-011) (6685069) 1229 RON 272 1 2 BOLT WASHER M4 (OLD 992-01040-011) (6685070) 1229 RON 273 1 1 GEAR CASE COVER (OLD 303-38360-20) (6688917) 2236 RON 311 1 1 NYLON HEAD/SURE TAP,M8-NUT (OLD 783-37820-90) NEW (6693221) 15993 RON 312 1 1 MOUNTING NUT L-M8X1.25 (OLD 356-3383E-20) (6689624) 4697 RON 313 1 1 CUTTING BODY (OLD 786-33830-20) (6684757) 6151 RON 314 1 1 SPECIAL NUT (OLD 315-33830-20) (6684758) 3578 RON 315 1 1 REEL SPRING (OLD 793-33830-20) (6684759) 2236 RON 316 1 1 SPOOL (OLD 787-33830-20) (6684760) 5368 RON 317 1 1 CUTTING BODY CAP (OLD 789-33830-20) (6684761) 9730 RON 318 1 2 EYELET (OLD 788-33830-20) (6684762) 2236 RON 501 1 1 HEX. BAR WRENCH 4MM (OLD 813-20000-20) (6684813) 105 RON 502 1 1 COMBI BOX SPANNER 13X19 (OLD 829-29005-2H) NEW (6693588) 2460 RON
