Top » Piese de schimb » PIESE HITACHI » ECV-5601 ECV-5601 [ECV-5601] Click pentru a mari Imagini suplimentare Click pentru a mari Click pentru a mari Click pentru a mari Click pentru a mari Click pentru a mari Click pentru a mari Click pentru a mari Click pentru a mari Click pentru a mari LISTA DE COMPONENTE: Numar Versiune Buc. in schema Denumire Pret/buc (Tva inclus) Cumpara 1 1 1 CYLINDER SET # (OLD 001-04093-90) (6685469) 10672 RON 2 1 1 CYLINDER GASKET# (OLD 017-04093-20) (6685735) 3466 RON 3 1 4 SPECIAL SCREW M5X20 (OLD 684-32625-20) (6692328) 1229 RON 4 1 1 DECOMPRESSION COMP.# (OLD 004-04093-80) NEW (6685590) 57712 RON 5 1 1 DECOMP COVER (OLD 020-04093-20) NEW (6685801) 2236 RON 6 1 2 PISTON PIN CIRCLIP (OLD 039-04093-20) (6686031) 894 RON 7 1 2 PISTONRING # (OLD 041-04093-20) (6686127) 8947 RON 8 1 1 PISTON SET # (OLD 030-04093-90) (6685886) 12526 RON 9 1 1 PISTON PIN # (OLD 037-04093-20) (6686013) 4025 RON 10 1 2 PISTON PIN COLLAR# (OLD 036-04093-20) (6685994) 4361 RON 11 1 1 NEEDLE BEARING (OLD 999-62111-581) (6695607) 6262 RON 12 1 1 CRANK SHAFT COMP.# (OLD 046-04093-80) (6686187) 77174 RON 13 1 1 WOOD -RUFF KEY # (OLD 068-04093-20) NEW (6686458) 2236 RON 31 1 2 BAR TIGHTENING BOLT# (OLD 101-32625-20) (6686806) 3242 RON 32 1 1 OIL SEAL ISD15284.5# (OLD 999-66152-874) (6695640) 4137 RON 33 1 1 FLY WHEEL WASHER (OLD 065-04093-20) NEW (6686439) 1229 RON 34 1 1 FLY WHEEL NUT (OLD 066-04093-20) NEW (6686444) 1229 RON 35 1 5 SPECIAL SCREW M5X25 (OLD 685-32625-20) NEW (6692329) 2236 RON 36 1 1 OIL SEAL ISCD 15354.5# (OLD 999-66153-572) (6695642) 5256 RON 37 1 1 STOPPER A# (OLD 285-32625-20) NEW (6688547) 4137 RON 38 1 1 STOPPER B# (OLD 286-32625-20) NEW (6688557) 3242 RON 39 1 3 DAMPER CAP A (OLD 224-32625-20) NEW (6688183) 2236 RON 40 1 3 SPECIAL SCREW M5X16 (OLD 688-32625-20) NEW (6692334) 1229 RON 41 1 3 FRONT DAMPER COMP. # (OLD 219-32625-80) NEW (6688114) 6262 RON 42 1 1 6692156 (6692156) 6598 RON 43 1 1 6686545 (6686545) 78851 RON 44 1 3 PIN (OLD 081-04093-20) NEW (6686630) 1229 RON 45 1 1 OIL TANK CAP PACKING (OLD 523-32625-20) NEW (6691244) 2236 RON 46 1 1 STOP RING C,INNER (OLD 029-32625-20) (6685866) 2236 RON 47 1 2 BEARING# (OLD 089-04093-80) (6686682) 8052 RON 48 1 1 H.L GROMMET# (OLD 192-32625-20) NEW (6687981) 382 RON 49 1 1 CRANK CASE GASKET# (OLD 090-04093-20) (6686711) 3578 RON 50 1 1 PLATE (OLD 466-32625-20) NEW (6690788) 3578 RON 51 1 1 6687356 (6687356) 65318 RON 52 1 2 STOP RING E (OLD 859-32625-20) (6693660) 1229 RON 53 1 2 PAWL SPRING# (OLD 790-04093-20) (6693349) 3242 RON 54 1 2 STARTER PAWL (OLD 788-04093-20) (6693306) 2460 RON 55 1 2 MACHINE SCREW (W/WASHERS) M4X10 (OLD 994-16040-101) (986662) 1453 RON 71 1 1 6687348 (6687348) 93168 RON 72 1 1 CORD # (OLD 178-04093-20) (6687844) 10513 RON 73 1 1 6687471 (6687471) 3242 RON 74 1 1 SPARK PLUG RCJ6Y (OLD 018-04221-20/6685774/791156) (6685775) 2012 RON 75 1 1 SPARK PLUG COVER # (OLD 255-04093-20) NEW (6688335) 3242 RON 76 1 1 RUBBER CAP # (OLD 485-04093-20) NEW (6690892) 4025 RON 77 1 1 STOP CORD# (OLD 179-04093-80) NEW (6687930) 6262 RON 78 1 1 STOP SWITCH COMP.# (OLD 170-04093-80) (6687742) 8276 RON 79 1 1 STOP BUTTON COVER (OLD 266-04093-20) NEW (6688406) 2460 RON 80 1 1 STOP BUTTON STAY # (OLD 640-04093-20) NEW (6692131) 3690 RON 81 1 1 SPECIAL SCREW M5X10 (OLD 691-32625-20) NEW (6692337) 1229 RON 82 1 1 INSULATOR TUBE # (OLD 250-04093-20) NEW (6688318) 3242 RON 83 1 1 6687507 (6687507) 11519 RON 84 1 1 AIR DEFLECTOR# (OLD 145-04093-80) (6687330) 6262 RON 85 1 1 DAMPER SEAT# (OLD 240-32625-20) NEW (6688258) 3242 RON 86 1 2 SPECIAL SCREW M5X20 (OLD 690-32625-20) NEW (6692336) 2236 RON 101 1 1 AIR VENT VALVE B (OLD 562-04093-20) NEW (6691378) 2460 RON 102 1 1 AIR VENT SPONGE (OLD 567-04093-20) NEW (6691402) 1229 RON 103 1 1 CLIP (OLD 680-32625-20) NEW (6692322) 1229 RON 104 1 1 OIL PIPE # (OLD 480-32625-20) NEW (6690882) 6039 RON 105 1 1 OIL FILTER BODY COMP (OLD 486-32628-80) NEW (6690916) 5256 RON 106 1 1 OIL PIPE A # (OLD 515-32625-20) NEW (6691222) 4025 RON 107 1 5 SPECIAL BOLT M4X14 (OLD 689-32625-20) NEW (6692335) 1229 RON 108 1 1 OIL PUMP ASSY (OLD 144-32625-91/6686642/6695921) (6687323) 35678 RON 109 1 1 OIL SPONGE (OLD 094-32625-20) (6686744) 1229 RON 110 1 1 6688483 (6688483) 17895 RON 111 1 1 CLUTCH HOUSING # (OLD 318-32625-20) (6689115) 32211 RON 112 1 1 NEEDLE BEARING # (OLD 350-32625-20) (6689536) 8388 RON 113 1 1 OIL PUMP COVER # (OLD 097-32625-20) (6686760) 4137 RON 114 1 2 CHAIN BAR CLAMP NUT (OLD 121-32625-20) (6687106) 2236 RON 115 1 1 RIM SPROCKET # (OLD 329-32625-20) (6689176) 15098 RON 116 1 1 GUIDE PLATE A# (OLD 461-32625-20) NEW (6690732) 4025 RON 117 1 1 SPECIAL SCREW M4X10 (OLD 686-32625-20) NEW (6692330) 1229 RON 118 1 1 6690884 (6690884) 4025 RON 119 1 1 CLUCH SPRING (OLD 342-04093-20) (6689427) 2460 RON 120 1 1 CLUTCH WASHER B (OLD 359-04093-20) (6689644) 4025 RON 121 1 1 GUIDE (OLD 467-32625-20) (6690797) 2460 RON 122 1 1 CHAIN CATCHER (OLD 125-32625-80) NEW JAN (6687166) 5480 RON 123 1 1 SPECIAL SCREW M5X14 (OLD 683-32625-20) (6692327) 1229 RON 124 1 2 SPECIAL SCREW M5X14 (OLD 683-32625-20) (6692327) 1229 RON 125 1 1 SPIKE (OLD 460-32625-20) (6690706) 8611 RON 126 1 1 DAMPER A # (OLD 234-32625-20) (6688248) 7493 RON 127 1 1 DAMPER COLLAR A (OLD 275-32625-20) (6688479) 2460 RON 128 1 1 SPECIAL SCREW M5X16 (OLD 688-32625-20) NEW (6692334) 1229 RON 141 1 1 HEAT SHIELD# (OLD 133-04093-20) NEW (6687239) 6262 RON 142 1 1 CARB.INSULATOR COMP. # (OLD 404-04093-80) NEW (6689942) 9394 RON 143 1 2 SPECIAL SCREW M5X14 (OLD 683-32625-20) (6692327) 1229 RON 144 1 1 ELBOW JOINT# (OLD 495-32625-20) NEW (6691006) 4361 RON 145 1 1 CLIP A (OLD 425-32625-20) NEW (6690171) 1229 RON 146 1 1 RUBBER PIPE (OLD 678-32625-20) NEW (6692302) 4025 RON 147 1 1 CARBURETOR GASKET (OLD 402-04093-20) (6689830) 2460 RON 148 1 1 SPACER # (OLD 249-04093-20) (6688308) 3578 RON 149 1 1 SPRING (OLD 067-32625-20) NEW (6686451) 3242 RON 150 1 1 INLET MANIFOLD # (OLD 393-04093-20) (6689798) 9282 RON 151 1 2 MUFFLER SPECIAL BOLT (OLD 750-04093-20) (6692880) 382 RON 152 1 1 INLET MANIFOLD RING# (OLD 401-32625-20) (6689821) 3242 RON 153 1 1 MUFFLER GASKET (OLD 737-04093-20) NEW (6692740) 2460 RON 154 1 1 MUFFLER SET (OLD 704-04095-90) NEW (6692462) 64423 RON 155 1 1 MUFFLER COVER (OLD 735-04095-20) NEW (6692721) 16888 RON 156 1 1 SPECIAL SCREW M5X10 (OLD 691-32625-20) NEW (6692337) 1229 RON 157 1 2 MUFFLER NUT (OLD 726-04093-20) NEW (6692684) 2460 RON 158 1 1 SPECIAL SCREW M4X10 (OLD 686-32625-20) NEW (6692330) 1229 RON 159 1 1 SPECIAL SCREW M5X20 (OLD 690-32625-20) NEW (6692336) 2236 RON 160 1 1 SPARK ARRESTER (OLD 732-04095-80) NEW (6692695) 2460 RON 161 1 1 SPACER,MUFFLER COVER (OLD 741-04095-20) NEW (6692845) 10513 RON 181 1 1 6692920 (6692920) 40711 RON 182 1 1 FAN CASE COMP.# (OLD 112-04093-80) (6686967) 22144 RON 183 1 1 ROPE GUIDE (OLD 780-04093-20) (6693134) 2460 RON 184 1 1 STARTER ROPE # (OLD 783-04093-20) (6693163) 4585 RON 185 1 1 STARTER HANDLE # (OLD 785-04093-20) (6693231) 5591 RON 186 1 1 ROPE STOPPER (OLD 795-04093-20) NEW JAN (6693382) 1229 RON 187 1 1 6693097 (6693097) 6151 RON 188 1 1 H.L GUIDE# (OLD 193-32625-20) NEW (6687982) 3466 RON 189 1 1 STARTER ROPE REEL# (OLD 774-04093-20) (6693064) 1041 RON 190 1 1 STARTERBOSS# (OLD 787-04093-20) (6693278) 13197 RON 191 1 1 STARTER WASHER (OLD 786-04093-20) NEW (6693251) 1229 RON 192 1 1 SPECIAL SCREW M5X20 (OLD 690-32625-20) NEW (6692336) 2236 RON 193 1 4 SPECIAL SCREW M5X14 (OLD 683-32625-20) (6692327) 1229 RON *211 1 1 6690655 (6690655) 118558 RON *211 1 1 6690656 (6690656) 118558 RON 212 1 1 INLET SCREEN (OLD 578-25007-20/6691460) (6684700) 2236 RON 213 1 1 PUMP BODY# (OLD 575-25330-80) NEW (6691439) 14092 RON 214 1 1 SCREW (OLD 514-25001-20) (6685210) 1229 RON 215 1 1 PUMP GASKET (OLD 577-25007-20) (6685212) 2236 RON 216 1 1 PUMP DIAPHRAGM # (OLD 576-25330-20) (6691448) 6822 RON 217 1 1 NEEDLE VALVE (OLD 603-25012-20) (6685215) 382 RON 218 1 1 DIAPHRAGM GASKET (OLD 475-25001-20) (6690837) 2236 RON 219 1 1 METERING DIAPHRAGM COMP. (OLD 474-25241-80) (6690830) 573 RON 220 1 1 DIAPHRAGM COVER (OLD 476-25004-20) (6685222) 3242 RON 221 1 1 VALVE SPRING (OLD 477-25080-20) (6690872) 2236 RON 222 1 1 HINGE PIN SET SCREW (OLD 546-25001-20) (6685218) 2236 RON 223 1 1 HINGE PIN (OLD 605-25001-20) (6685219) 1229 RON 224 1 1 CHOKE SPRING (OLD 496-25032-20) NEW (6691012) 1229 RON 225 1 1 STEEL BALL (OLD 567-25032-20) NEW MAR (6691405) 1229 RON 226 1 1 CONTROL LEVER (OLD 473-25001-20) (6685217) 2460 RON 227 1 1 IDLE ADJUST SPRING (OLD 463-25006-20) (6685297) 2236 RON 228 1 1 IDLE ADUST SCREW # (OLD 462-25330-20) NEW (6690742) 7828 RON 229 1 4 SET SCREW (OLD 548-25012-20) (6685223) 1229 RON 241 1 1 6690405 (6690405) 22144 RON 242 1 1 CLEANER KNOB # (OLD 175-32625-20) (6687797) 382 RON 243 1 1 CLEANER PACKING (OLD 418-04093-20) (6690057) 2236 RON 244 1 1 FILTER SCREEN# (OLD 428-04093-80) NEW (6690175) 3466 RON 245 1 1 CLEANER ELEMENT A (OLD 444-04093-20) NEW (6690326) 1229 RON 246 1 1 TAPPING SCREW 4X10 (OLD 993-11041-012) (6695245) 1229 RON 247 1 1 RUBBER CAP (OLD 486-04093-20) NEW (6690902) 2460 RON 248 1 1 6685685 (6685685) 21586 RON 249 1 5 SPECIAL SCREW M5X14 (OLD 683-32625-20) (6692327) 1229 RON 250 1 1 HANDLE DAMPER COMP.# (OLD 213-32625-80) (6688102) 6262 RON 251 1 1 SPECIAL NUT# (OLD 381-04093-20) NEW (6689752) 4361 RON 252 1 1 GROMMET (OLD 191-32625-20) NEW (6687975) 3242 RON 253 1 1 CLEANER ELEMENT COMP.# (OLD 420-04093-80) (6690069) 15098 RON 271 1 1 SIDE CASE ASSY (OLD 040-32628-91) NEW (6686079) 113524 RON 272 1 1 HAND GUARD SHAFT # (OLD 803-32625-20) (6693444) 3242 RON 273 1 1 SIDE CASE COMP.# (OLD 039-32625-80) (6686041) 28967 RON 274 1 1 STOPPER C# (OLD 287-32625-20) NEW (6688566) 4137 RON 275 1 1 CHAIN TENSION BOLT (OLD 116-32625-20) (6687070) 1232 RON 276 1 1 TENSION ADJUSTING BOSS # (OLD 115-32625-20) (6687058) 6822 RON 277 1 1 GUIDE PLATE B# (OLD 462-32625-20) NEW (6690753) 7828 RON 278 1 1 GEAR # (OLD 300-32625-20) (6688657) 15098 RON 279 1 1 GUIDE (OLD 467-32625-20) (6690797) 2460 RON 280 1 1 CHAIN PROTECTOR (OLD 325-32625-20) NEW (6689162) 5815 RON 281 1 1 FRONT HAND GUARD ASSY (OLD 805-32628-91/6696210) (6693459) 3400 RON 282 1 1 SPRING PIN (OLD 499-32626-20) NEW (6691022) 1229 RON 283 1 1 STOP RING E (OLD 860-32625-20) NEW (6693662) 1229 RON 284 1 1 WEIGHT SPRING (OLD 809-32625-20) (6693489) 2460 RON 285 1 1 HAND GUARD WE/GHT# (OLD 808-32625-20) NEW (6693482) 6598 RON 286 1 1 HAND GUARD SPRING# (OLD 804-32625-20) NEW (6693448) 3242 RON 287 1 1 WASHER (OLD 513-32625-20) (6691213) 1229 RON 288 1 2 STOP RING E (OLD 859-32625-20) (6693660) 1229 RON 289 1 1 SPACER (OLD 802-32625-20) (6693432) 2236 RON 290 1 1 PIN (OLD 811-32625-20) NEW (6693508) 382 RON 291 1 1 BRAKE ARM# (OLD 373-32625-20) NEW (6689693) 4920 RON 292 1 1 BRAKE SPRING # (OLD 374-32625-20) NEW (6689703) 488 RON 293 1 1 BRAKE SPRING # (OLD 374-32626-20) (6689704) 3242 RON 294 1 1 BRAKE LINK SUPPORT # (OLD 386-32625-20) NEW (6689778) 8164 RON 295 1 1 COLLAR (OLD 384-32625-20) NEW (6689773) 1229 RON 296 1 1 SHIELD (OLD 187-32628-20) NEW (6687951) 2460 RON 297 1 1 BRAKE LINK COMP. # (OLD 379-32625-80) NEW JAN (6689731) 7381 RON 298 1 1 BRAKE LINK COVER # (OLD 375-32625-20) (6689710) 5256 RON 299 1 1 BRAKE BAND HOLDER (OLD 376-32625-20) NEW (6689716) 1229 RON 300 1 1 BRAKE BAND # (OLD 378-32625-20) (6689726) 7828 RON 301 1 5 SPECIAL SCREW M4X12 (OLD 695-32625-20) (6692341) 1229 RON 331 1 1 SPECIAL SCREW M5X19 (OLD 687-32625-20) (6692331) 1229 RON 332 1 1 REAR HANDLE GRIP # (OLD 227-32625-20) (6688216) 5368 RON 333 1 1 SAFTY LEVER (OLD 257-32625-20) (6688356) 2236 RON 334 1 1 GROMMET (OLD 493-32625-20) NEW (6690997) 2460 RON 335 1 1 THROTTLE ROD # (OLD 490-32625-20) NEW (6690970) 3242 RON 336 1 1 FRONT HANDLE COMP. # (OLD 209-32625-80) (6688074) 56817 RON 337 1 1 SPECIAL BOLT (OLD 693-32625-20) NEW (6692339) 1229 RON 338 1 1 SPECIAL SCREW M5X19 (OLD 687-32625-20) (6692331) 1229 RON 339 1 1 AIR CLEANER BASE COMP. # (OLD 436-04093-80) NEW (6690199) 10513 RON 340 1 2 REAR DAMPER COMP.# (OLD 223-32625-80) (6688180) 6262 RON 341 1 2 DAMPER SET BOLT A# (OLD 295-32625-20) (6688631) 3578 RON 342 1 2 DAMPER CAP B (OLD 265-32625-20) NEW (6688403) 2460 RON 343 1 1 CLIP.6.3 DIA. (OLD 680-00731-20) (6684619) 1229 RON 344 1 1 AIR VENT PIPE (OLD 565-04093-20) NEW (6691392) 1229 RON 345 1 1 6692342 (6692342) 13197 RON 346 1 1 6684618 (6684618) 2236 RON 347 1 1 COLLAR # (OLD 478-32625-20) NEW (6690878) 3242 RON 348 1 1 6692273 (6692273) 4249 RON 349 1 1 CUSHION RUBBER # (OLD 599-04093-20) NEW (6691826) 3466 RON 350 1 2 SPECIAL SCREW M5X52 (OLD 692-32625-20) NEW (6692338) 2460 RON 351 1 1 6692116 (6692116) 5143 RON 352 1 1 TANK CAP PACKING (OLD 630-32625-20) NEW (6692099) 2460 RON 353 1 1 GUIDE (OLD 715-32625-20) NEW (6692601) 2460 RON 354 1 1 CHOKE ROD COMP. (OLD 706-32625-80) NEW (6692585) 2460 RON *355 1 1 CHOKE ROD RUBBER (OLD 707-32625-20) NEW (6696172) 2236 RON *355 1 1 CHOKE ROD RUBBER (OLD 707-32625-21) NEW (6692589) 2236 RON 356 1 1 6692173 (6692173) 6262 RON 357 1 1 6685660 (6685660) 84779 RON 358 1 1 PUSH PIN (OLD 064-32625-20) NEW (6686432) 2236 RON 359 1 1 PUSH PIN SPRING (OLD 066-32625-20) NEW (6686448) 2236 RON 360 1 1 PUSH PIN CAP (OLD 725-32625-20) NEW (6692682) 1229 RON 361 1 1 FRONT DAMPER (OLD 232-32625-20) NEW (6688242) 3242 RON 362 1 1 SPECIAL SCREW M4X16 (OLD 694-32625-20) NEW (6692340) 1229 RON 363 1 1 PACKING (OLD 423-32625-20) (6690137) 2460 RON 364 1 1 THROTTLE LEVER (OLD 060-32625-20) NEW (6686385) 2460 RON 365 1 1 THROTTLE LEVER SPRING (OLD 061-32625-20) NEW (6686415) 2236 RON 366 1 1 SPRING PIN (OLD 499-32625-20) (6691021) 1229 RON 367 1 1 6685661 (6685661) 84779 RON 368 1 1 GROMMET A (OLD 052-32626-20) (6686326) 2460 RON 401 1 1 CHAIN COVER 20 (OLD 945-3254D-21) (6694804) 4137 RON 501 1 1 DRIVER # (OLD 880-32625-20) (6693802) 4585 RON 502 1 1 COMBI SPANNER (OLD 883-32625-20) (6693810) 6822 RON
