Top » Piese de schimb » PIESE DEWALT » DCG4610T2 Type 1

POLIZOR UNGHIULAR DEWALT DCG4610T2 Type 1
[DCG4610T2 Type 1]
POLIZOR UNGHIULAR DEWALT DCG4610T2 Type 1
Click pentru a mari
Imagini suplimentare
POLIZOR UNGHIULAR DEWALT DCG4610T2 Type 1
Click pentru a mari
POLIZOR UNGHIULAR DEWALT DCG4610T2 Type 1
Click pentru a mari
POLIZOR UNGHIULAR DEWALT DCG4610T2 Type 1
Click pentru a mari
POLIZOR UNGHIULAR DEWALT DCG4610T2 Type 1
Click pentru a mari
LISTA DE COMPONENTE:
Numar Versiune Buc. in schema Denumire Pret/buc
(Tva inclus)		 Cumpara
1 1 1 CLAMSHELL SET (N575277) 15469 RON
2 1 1 GEARCASE SA (N508013) 11337 RON
3 1 1 INNER FLANGE (N654478) 3268 RON
4 1 1 OUTER FLANGE (N666474) 3954 RON
5 1 1 MOTOR AND SWITCH SA (N599252) 96047 RON
6 1 1 ARMATURE (N548535) 28836 RON
7 1 1 GEARCASE COVER SA (N508009) 20216 RON
11 1 1 NUT M7 (N372039) 588 RON
12 1 1 ROLL PIN 2.5 X 10.9 (N071836) 558 RON
13 1 4 SCREW (N412210) 588 RON
14 1 1 SCREW (N575500) 588 RON
15 1 1 Screw M3.5X16 T15 (330019-03) 558 RON
16 1 2 VENT (N436965) 2182 RON
17 1 1 SCREW (N130031) 558 RON
18 1 5 SCREW METAL THD FRM M4X16 T20 (330045-06) 558 RON
19 1 2 NUT (330015-00) 588 RON
20 1 1 MOUNT TERM BLOCK SPRING (MOULD) (N122099) 558 RON
21 1 1 INSERT (N728013) 588 RON
22 1 1 INSERT (N728012) 588 RON
23 1 7 SCREW (90611830) 588 RON
24 1 1 STRIKE PLATE (N467560) 588 RON
25 1 1 Gear (N449470) 16689 RON
26 1 1 RETAINING RING (444793-00) 558 RON
27 1 1 O RING 1.5X40 (N307625) 588 RON
28 1 1 RETAINER RING (N481950) 588 RON
29 1 1 SPACER (N390307) 1318 RON
30 1 1 Bearing Ball CWMFG (605040-24) 190 RON
31 1 1 WASHER SPRING (N390308) 82 RON
32 1 1 WASHER SPRING (N542715) 82 RON
33 1 1 WASHER (N448927) 2182 RON
34 1 1 SPINDLE (N449565) 4355 RON
35 1 1 THOR SPINDLE LOCK O-RING (N263699) 588 RON
36 1 1 SPINDLE LOCK BUTTON (N278899) 588 RON
37 1 1 THOR SPINDLE LOCK SPRING (N263579) 588 RON
38 1 1 LOCK PIN (N481683) 944 RON
39 1 1 O RING (N119639) 558 RON
40 1 1 PINION (N461411) 3268 RON
41 1 1 BEARING (N175104) 1788 RON
42 1 1 RET RING w FINGERS (N453031) 588 RON
43 1 1 DEFLECTOR (N401958) 668 RON
44 1 1 BRAND LABEL (N456830) 588 RON
45 1 1 LABEL (N456232) 588 RON
46 1 1 RATING PLATE (N819748) 588 RON
47 1 1 BRAND LABEL (N456831) 588 RON
48 1 1 BRAND LABEL (N456832) 588 RON
49 1 1 LABEL (N456231) 588 RON
50 1 1 HEX KEY 6 MM (N107295) 781 RON
51 1 1 SIDE HANDLE (N382311) 6688 RON
52 1 1 TERMINAL BLOCK SPRING (N461735) 588 RON
53 1 1 POTTING BOX, AK61 (N532926) 668 RON
101 1 1 DUST PORT (N645894) 3268 RON
102 1 1 COVER (N651615) 1318 RON
103 1 1 CLAMSHELL HALF (N645891) 6688 RON
104 1 1 CLAMSHELL HALF (N645890) 5370 RON
105 1 1 SPRING (N646433) 668 RON
106 1 1 PIN (N645896) 1933 RON
107 1 1 WASHER (N743974) 588 RON
108 1 1 Washer Lock (098197-10) 558 RON
109 1 1 Mach screw (153778-01) 2347 RON
110 1 1 BACKPLATE (N646437) 2556 RON
111 1 1 STRAP (N646443) 4355 RON
112 1 1 SCREW (631609-03) 558 RON
113 1 10 SCREW (90611830) 588 RON
114 1 2 SCREW (N530541) 588 RON
114 1 10 N813648 - Indisponibil
115 1 3 SCREW PLASTIC THREAD FORM M3.5*16 T15 (330019-66) 558 RON
116 1 8 PLASTIC SCREW (N760650) 588 RON
117 1 1 CLAMSHELL HALF (N659081) 3268 RON
118 1 1 CLAMSHELL HALF (N645892) 3954 RON
119 1 2 NUT (N116219) 588 RON
120 1 1 WINDOW (N647700) 944 RON
121 1 2 SCREW (478455-00) 588 RON
122 1 1 SPRING (N646434) 588 RON
123 1 1 LATCH BUTTON (N645899) 668 RON
124 1 1 PIN (N646432) 588 RON
125 1 1 SPRING (N770509) 588 RON
126 1 1 LOCK HOOK (N645897) 4355 RON
127 1 1 STRAP (N646427) 3954 RON
128 1 1 LATCH (N646444) 5370 RON
129 1 1 BRACKET (N646430) 944 RON
130 1 1 KNOB (N646428) 668 RON
131 1 1 SHOE (N645902) 4355 RON
132 1 4 CLIP (386957-00) 558 RON
133 1 4 WHEEL (N703486) 668 RON
134 1 4 WASHER (N774538) 588 RON
135 1 2 AXLE (N703485) 944 RON
136 1 1 INNER FLANGE (N654478) 3268 RON
137 1 1 OUTER FLANGE (N666474) 3954 RON
138 1 1 INNER FLANGE (N665586) 3268 RON
139 1 1 OUTER FLANGE (N665610) 3268 RON
141 1 1 LABEL (N456231) 588 RON
142 1 3 SCREW (388405-00) 558 RON
800 1 1 GREASE TUBE (583534-00) 29862 RON
862 1 1 BAG (629053-00) 12361 RON
862 1 1 BAG (NA705140) 9012 RON
866 1 1 BATTERY 3 X18V-6.0AH-108WH (N473851) 148269 RON
867 1 1 SAFETY CAP (N462141) 5370 RON
871 1 1 CHARGER QW (N473860) 73079 RON
