Top » Piese de schimb » PIESE DEWALT » P3312 Type 1

P3312 RADIAL ARM SAW Type 1
[P3312 Type 1]
P3312 RADIAL ARM SAW Type 1
Click pentru a mari
Imagini suplimentare
P3312 RADIAL ARM SAW Type 1
Click pentru a mari
P3312 RADIAL ARM SAW Type 1
Click pentru a mari
P3312 RADIAL ARM SAW Type 1
Click pentru a mari
P3312 RADIAL ARM SAW Type 1
Click pentru a mari
P3312 RADIAL ARM SAW Type 1
Click pentru a mari
P3312 RADIAL ARM SAW Type 1
Click pentru a mari
LISTA DE COMPONENTE:
Numar Versiune Buc. in schema Denumire Pret/buc
(Tva inclus)		 Cumpara
1 1 1 HANDLE SA (860792-01) 4137 RON
2 1 1 SCREW (934401-00) 558 RON
3 1 2 SCREW SOCKET M.6X25 UNI 5931 (860093-06) 558 RON
4 1 1 WASHER FLAT 10 5X18 UNI 6592 (860073-06) 558 RON
5 1 1 CAP COLUMN DW1251 (860784-00) 3466 RON
6 1 4 SCREW FIL.HD B M4X10 DIN 7513 (860531-00) 781 RON
7 1 3 WASHER FLAT 4.3X9 UNI 6592 (860073-00) 558 RON
8 1 1 POINTER MITRE 7790 (860237-00) 1452 RON
10 1 1 CABLE SUPPORT D.13 1370-INDUS (863912-00) 7940 RON
11 1 2 SCREW CUP SQUARE M6X20UNI5732 (860301-00) 558 RON
12 1 1 SUPPORT FOR STOP ROD BLANK (860787-90) 3018 RON
13 1 2 WASHER SPRING CON.D8.2X18X1 (860074-03) 558 RON
14 1 2 SCREW SOCKET M.8X12 UNI 5931 (860093-14) 558 RON
15 1 2 KNOB (946469-01) 781 RON
16 1 2 WASHER FLAT 6.4X12.5 UNI 6592 (720959-00) 558 RON
17 1 1 ROD FOR STOP L.155 DW125BLANK (860852-90) 3466 RON
18 1 1 BUMPER FOR STOP D. 16X22 (860786-00) 781 RON
20 1 1 000000-00 - Indisponibil
22 1 1 METRIC BAR (863272-00) 3466 RON
23 1 1 000000-00 - Indisponibil
24 1 1 BUMPER D.16X10 BLACK (860429-00) 893 RON
25 1 1 WRENCH HEX 5 UNI 6753 (930574-00) 781 RON
26 1 2 SCREW SOCKET M.6X20 UNI 5931 (860093-05) 558 RON
27 1 1 000000-00 - Indisponibil
29 1 1 SA COLUMN D.69 5 L.490 DW1251 (860790-00) 25164 RON
30 1 1 SA SCREW ELEV.L.227+TUBE (860791-00) 5484 RON
31 1 10 NUT HEX THICK M.8 UNI 5587 (860083-04) 558 RON
32 1 2 WASHER FLAT 8.4X17 UNI6592 ZN (860073-03) 558 RON
33 1 4 SCREW HEX M.10X45 UNI 5739 (860085-05) 781 RON
34 1 4 WASHER FLAT 10.5X21 UNI6592 Z (860073-04) 558 RON
35 1 6 NUT HEX THICK M.10 UNI 5587 (860083-05) 558 RON
36 1 2 SCREW HEX M.8X70 UNI 5739 (860085-02) 781 RON
37 1 1 000000-00 - Indisponibil
38 1 1 SCREW HEX M.10X110 UNI 5737 (860086-00) 1788 RON
39 1 2 SPACER ELEVATING TUBE (860065-00) 1229 RON
40 1 1 PLATE LH BASE 25X8 BLACK OXID (860273-00) 3018 RON
41 1 1 PIN SPIRAL 5X28 UNI 6875 (860096-06) 558 RON
42 1 1 SLEEVE ELEV.SCREW DW1251BLANK (860831-90) 2347 RON
43 1 1 WRENCH 22-10 SPECIAL (860423-00) 4472 RON
44 1 2 NUT HEX 22X8 M.18X1.5 SPEC. (860232-00) 2124 RON
45 1 2 SCREW HD13 SET MTR LTCM18X1.5 (860231-00) 4137 RON
46 1 1 000000-00 - Indisponibil
47 1 1 PLATE RH BASE 25X8 BLACK OXID (860273-02) 3466 RON
48 1 1 000000-00 - Indisponibil
49 1 1 SA LEVER CLAMP ARM DW1251 ORG (860795-00) 6821 RON
50 1 1 WASHER SPRING CON.10.2X22X1.2 (860074-04) 558 RON
51 1 1 000000-00 - Indisponibil
52 1 1 STRAP CABLE N6 3/8 NYLON (860843-02) 558 RON
53 1 2 SCREW SET M.8X35-UNI5925 BRASS (949853-11) 10512 RON
55 1 3 WASHER-SHIM 12X26X0.3 SPECIAL (860226-01) 781 RON
56 1 1 WASHER WITH TAB D.10 5X1 BLNK (860802-90) 105 RON
76 1 1 000000-00 - Indisponibil
77 1 1 000000-00 - Indisponibil
78 1 17 WASHER FLAT 8.4X17 UNI6592 ZN (860073-03) 558 RON
79 1 1 ELEMENT (55235) 7940 RON
80 1 1 ELEMENT (55234) 7940 RON
81 1 1 000000-00 - Indisponibil
82 1 2 WASHER FLAT 8.4X17 UNI6592 ZN (860073-03) 558 RON
83 1 1 000000-00 - Indisponibil
84 1 6 NUT HEX THICK M.8 UNI 5587 (860083-04) 558 RON
85 1 6 WASHER SPRING CON.D8.2X18X1 (860074-03) 558 RON
86 1 1 BAR MITRE RH L.750 BLACK (860221-00) 5591 RON
87 1 17 WASHER SPRING CON.D8.2X18X1 (860074-03) 558 RON
88 1 17 NUT HEX THICK M.8 UNI 5587 (860083-04) 558 RON
89 1 2 NUT HEX THICK M.8 UNI 5587 (860083-04) 558 RON
90 1 1 FRAME (860216-06) 107597 RON
91 1 1 BAR MITRE LH L.750 BLACK (860222-00) 20467 RON
92 1 2 SLIDE CLAMP TABLE (860069-00) 893 RON
93 1 2 NUT HEX THICK M.6 UNI 5587 (860083-03) 558 RON
94 1 2 BRACKET CLAMP TABLE (860070-00) 1452 RON
95 1 2 WING KNOB+SCREW M6X50 (863310-00) 1117 RON
96 1 17 000000-00 - Indisponibil
97 1 2 BRACKET (863130-04) 3466 RON
99 1 6 SCREW HEX M.8X16 UNI 5739 (860085-04) 558 RON
100 1 2 STUD SET M.8X47 (860010-00) 9282 RON
120 1 2 SCREW CONCENTRIC BEARING 1712 (760421-00) 3466 RON
121 1 1 PIVOT M.18X1.5 L.50 (860123-00) 5031 RON
122 1 3 BEARING SPECIAL SKF 614432-B (860154-00) 25164 RON
123 1 1 BEARING SHAFT-ECCENTRIC DW125- (760417-00) 4137 RON
124 1 2 FILLISTER HEAD SCREW (949894-06) 558 RON
125 1 1 000000-00 - Indisponibil
126 1 1 KNOB D.40X16-M8X23-BLACK (862427-00) 781 RON
127 1 1 RIP LOCK (SLEEVE) (860121-00) 5031 RON
128 1 1 LOCK (PISTON) (860122-00) 893 RON
129 1 1 WRENCH HEX 3 UNI 6753 (938539-00) 781 RON
130 1 1 SCREW SET M.6X6 UNI 5929 (860088-27) 558 RON
131 1 5 WASHER SPRING CON.D8.2X18X1 (860074-03) 558 RON
132 1 3 NUT HEX THICK M.8X1 UNI 5587 (860083-08) 558 RON
133 1 1 CAP FOR ROLLERHEAD (860817-01) 1229 RON
134 1 1 WRENCH (949882-01) 781 RON
135 1 1 LOCATING PLUG (863977-00) 14315 RON
136 1 2 SPRING PUSHER D13XD1 2X39 (860112-11) 1788 RON
137 1 1 SUPPORT FOR INDEX PIN YOKE (860835-00) 9282 RON
138 1 1 WRENCH HEX 6 UNI 6753 (860098-04) 781 RON
139 1 1 KNOB (946469-01) 781 RON
140 1 1 SCREW SOCKET M.8X30 UNI 5931 (860093-00) 558 RON
141 1 1 HUB FRONT YOKE D.54 BLANK (860119-01) 6821 RON
142 1 2 PLATE FOR HUBE (860120-00) 105 RON
143 1 3 SCREW SOCKET M.8X35 UNI 5931 (860093-18) 781 RON
144 1 2 SCREW PAN PH/TT M.4X10UNI8112 (860094-03) 558 RON
145 1 1 POINTER CIRC. (862721-01) 190 RON
146 1 1 PLATE INDEX YOKE-MOTOR DW1251 (860830-00) 2347 RON
147 1 1 GASKET FOR YOKE HUBE DW1251 (860827-00) 2124 RON
148 1 1 BRACKET FRONT YOKE-MOT.DW1251 (860828-00) 190 RON
149 1 1 HANDLE D.20X67XD.10 BLACK (860796-01) 1229 RON
150 1 1 PLATE 13X55-3 HOLES M8 DW1251 (860809-00) 2347 RON
151 1 1 CLAMP YOKE/ROLLER HEAD (864057-01) 10512 RON
152 1 1 ADJUSTER SPRING WASHER (860113-00) 3018 RON
153 1 1 SCREW HEX M.8X75 UNI 5737 (860086-11) 893 RON
154 1 2 NUT ELAST.STOP M.6 UNI 7474 (860092-00) 558 RON
155 1 2 WASHER FLAT 6.4X12.5 UNI 6592 (720959-00) 558 RON
156 1 1 BUSHING REAR MOT.YOKE DW1251 (860822-00) 190 RON
157 1 1 WASHER D.8 4X24X2 (941602-00) 558 RON
158 1 1 SCREW SOCKET M.8X30 UNI 5931 (860093-00) 558 RON
159 1 1 GRAY YOKE DW1251 (860823-02) 3124 RON
160 1 1 THRUST RING + SCREWS (863157-00) 5591 RON
161 1 1 CATCH (860818-04) 6821 RON
162 1 1 SCREW HEX M.5X16 UNI 5739 (860085-06) 558 RON
163 1 1 CAP BLUE (760427-01) 190 RON
164 1 1 INSERT ROLLERHEAD ADJUSTMENT (860816-00) 781 RON
165 1 1 WASHER FLAT 5.3X10 UNI 6592 (860073-01) 558 RON
166 1 1 NUT M5 (860092-03) 558 RON
167 1 1 WASHER SPRING CON.D8.2X18X1 (860074-03) 558 RON
168 1 1 HANDLE M.8 LOCKING ARM-YOKE (860825-00) 3466 RON
169 1 1 SCALE BEVEL DW1251 (860829-00) 190 RON
170 1 2 SCREW TSPPH (860205-06) 558 RON
171 1 1 000000-00 - Indisponibil
176 1 1 MOTOR FIXING PLATE-DW320 (863010-00) 190 RON
186 1 1 000000-00 - Indisponibil
187 1 1 BUSHING CABLE MOTOR DW 320 (860447-00) 4137 RON
188 1 1 PLATE RETAINING SCREWS M8 (860807-00) 893 RON
189 1 2 WASHER FLAT 8.4X17 UNI6592 ZN (860073-03) 558 RON
190 1 1 NUT END HANDLE M.8X22 (860143-00) 1788 RON
191 1 1 SCREW HEX M.8X25 UNI 5739 (860085-19) 558 RON
192 1 1 KEY WOODRUFF 4X5 UNI 6606 (860318-01) 781 RON
193 1 1 BEARING 6202 (868768-07) 4137 RON
194 1 1 RING AXIAL LOAD 34.5X28X0.5 (860080-02) 781 RON
195 1 4 ROD THREADED HEX M.5X145 (860446-00) 558 RON
196 1 1 BELL REAR END MOTOR DW 250 (860443-00) 4472 RON
197 1 1 STATOR+HOUSING V.220 DW1251 86 (868413-00) 165534 RON
198 1 1 ROTOR 1 PH (197302) 62298 RON
199 1 1 RING SPRING S.LOCK HOLE ZJ-40 (860806-00) 893 RON
200 1 1 BEARING 6203 2RS ISB (861721-12) 2347 RON
201 1 1 BELL FRONT END MTR DW320 CAST (860808-00) 1891 RON
202 1 1 INNER FLANGE DW320 (863266-00) 9282 RON
203 1 1 FLANGE DW320 (861241-00) 190 RON
204 1 1 NUT ARBOR M.16X1.5 LH (860126-01) 5591 RON
205 1 1 WRENCH HEX 8 UNI 6753 (860098-05) 190 RON
206 1 1 000000-00 - Indisponibil
207 1 1 FAN MOTOR D.106XD.15 DW 250 (860444-00) 2347 RON
208 1 1 COVER FAN MOTOR DW 250 (860445-00) 3466 RON
230 1 7 SELF TAPPING SCREW 4 2X16 (930076-00) 558 RON
231 1 1 KIT HANDLE DW720 (868649-00) 15993 RON
233 1 3 SCREW SOCKET M.8X30 UNI 5931 (860093-00) 558 RON
234 1 2 NUT HEX THICK M.5 UNI 5587 (860083-02) 558 RON
235 1 1 RIGHT ADAPTOR HANDLE (863318-00) 4472 RON
236 1 1 CAPACITOR MF.20/400V. (949772-28) 5591 RON
237 1 1 PLATE FOR SWITCH CAP-DW320 (863198-00) 781 RON
238 1 1 CAP FOR SWITCH-DW320 (863849-00) 781 RON
239 1 1 NUT HEX THICK M.6 UNI 5587 (860083-03) 558 RON
240 1 2 SOCKET HEAD SCREW (949886-10) 893 RON
241 1 1 LEFT ADAPTOR HANDLE (863319-00) 4472 RON
242 1 1 SOCKET HEAD SCREW (860093-20) 558 RON
243 1 1 NUT HEX THICK M.8 UNI 5587 (860083-04) 558 RON
244 1 1 CABLE CLIP DW320 (863116-00) 2124 RON
245 1 2 CABLE BLOCKING DW320 (863111-00) 1452 RON
246 1 2 BUSHING CABLE D.10XD.14X5 (944590-00) 781 RON
247 1 1 SCREW PAN PH A M5X16 DIN 7516 (860238-03) 781 RON
248 1 1 SCREW PAN PHAB 3.9X9 5UNI6954 (860084-20) 558 RON
249 1 1 STRAP CABLE N5 5/16 NYLON (860843-01) 558 RON
250 1 1 STRAP CABLE N6 3/8 NYLON (860843-02) 558 RON
251 1 1 CONNECTOR MAMMUT -DW320 (949784-06) 558 RON
252 1 1 WEBER SWITCH (861385-04) 62298 RON
253 1 1 CABLE (949863-23) 1891 RON
270 1 1 KNOB (946469-01) 781 RON
271 1 4 WASHER FLAT SPEC. 6.4X16X1.5 (860075-00) 558 RON
272 1 1 KICK-UP SUPPORT FOR EUROGUARD (863709-00) 2795 RON
273 1 1 SPACER / DUST PROTECTOR EUROGU (863703-00) 1452 RON
274 1 1 DUST SPOUT EUROG.D.250-300-350 (864095-00) 3466 RON
275 1 1 ROTATING SQUARE (863708-00) 1788 RON
276 1 4 WASHER SPRING CON.D5.2X12X0.8 (860074-01) 558 RON
277 1 1 KNOB (861842-01) 1229 RON
279 1 3 SCREW FILL.HD M.5X8 UNI6107 (760273-00) 558 RON
281 1 2 SCREW M5X10 (760998-00) 558 RON
282 1 2 SCREW M5X10 (249412-20) 558 RON
283 1 4 WASHER FOR LEVER EUROG.250-300 (864053-00) 2124 RON
284 1 3 SCREW CUP SQUARE M6X20UNI5732 (860301-00) 558 RON
285 1 2 30/10 RIVING KNIFE PLATE (864086-00) 105 RON
286 1 1 WASHER SPRING CON.D6.2X14X0.9 (860074-02) 558 RON
287 1 2 NUT HEX THICK M.6 UNI 5587 (860083-03) 558 RON
288 1 1 000000-00 - Indisponibil
290 1 1 SCREW FLAT FILL.HD.M6X20 UNI61 (941518-00) 558 RON
292 1 1 FRONT PROTECT.GUIDE BUSHING (863705-00) 1117 RON
293 1 2 SLIDING ROLLER EUROG.D.250-300 (864054-00) 1229 RON
296 1 1 COMPLETE KICK-UP ASSEMBLY EURO (864814-01) 20467 RON
297 1 1 SOCKET HEAD SCREW (760219-00) 558 RON
299 1 1 DISTANCIAL (863599-02) 105 RON
300 1 1 SPRING (760483-00) 558 RON
301 1 1 CAP FOR LOCKING LEVER (863073-00) 781 RON
302 1 1 LOCKING LEVER M8 1712USA (863320-00) 1229 RON
303 1 1 SQUARE HEAD BUTTON SCREW M8X50 (949891-03) 781 RON
307 1 1 WASHER FLAT 8.4X17 UNI6592 ZN (860073-03) 558 RON
309 1 1 000000-00 - Indisponibil
311 1 1 OUTER PROTECTION EUROG.DW1250 (862417-00) 4137 RON
320 1 2 WASHER FLAT 5.3X10 UNI 6592 (860073-01) 558 RON
322 1 1 SPANNER 10/13 DW50-55 (949751-07) 190 RON
