Top » Piese de schimb » PIESE DEWALT » DW717XPS Type 1

DW717XPS MITRE SAW Type 1
[DW717XPS Type 1]
DW717XPS MITRE SAW Type 1
Click pentru a mari
Imagini suplimentare
DW717XPS MITRE SAW Type 1
Click pentru a mari
LISTA DE COMPONENTE:
Numar Versiune Buc. in schema Denumire Pret/buc
(Tva inclus)		 Cumpara
1 1 1 ARM (641494-01) 51337 RON
1 1 1 ARM (641494-01) 51337 RON
2 1 1 BELT COVER (641445-00) 6821 RON
3 1 9 SCREW (330045-14) 558 RON
4 1 1 SHAFT (146751-00) 2124 RON
5 1 2 SPACER (146732-00) 781 RON
6 1 1 SPRING (N039404) 9282 RON
7 1 2 SCREW (150075-00) 781 RON
8 1 2 PLASTIC WASHER (148296-00) 781 RON
9 1 1 PIN LOCKING (387130-00) 2347 RON
10 1 1 GASKET (34158-00) 558 RON
12 1 5 SCREW (330045-23) 781 RON
13 1 1 STOP PAWL (153603-01) 1117 RON
14 1 1 SHOULDER SCREW (153639-00) 781 RON
15 1 1 WAVY WASHER (153655-00) 558 RON
16 1 1 SCREW (618197-00) 893 RON
17 1 1 NUT WING (150718-00) 558 RON
19 1 4 SCREW (385915-02) 558 RON
20 1 1 SCREW (618198-00) 781 RON
22 1 1 INSULATED BUSHING [POLYONE LM-318-G001] (615851-00) 2795 RON
23 1 1 LOCKING SCREW BLADE (145344-01) 781 RON
24 1 1 CLAMP OUTER (151962-01) 1452 RON
24 1 1 CLAMP OUTER (151962-01) 1452 RON
25 1 1 ADAPTOR (604770-00) 2347 RON
25 1 1 ADAPTOR (604770-00) 2347 RON
26 1 1 BUSHING ARBOR (644999-00) 2795 RON
26 1 1 BUSHING ARBOR (644999-00) 2795 RON
28 1 1 GEAR & SPINDLE SA (641465-00SV) 3124 RON
28 1 1 GEAR & SPINDLE SA (641465-00SV) 3124 RON
29 1 1 BEARING BALL (330003-66) 5591 RON
30 1 1 BEARING NEEDLE (391616-00) 190 RON
33 1 1 BEARING (605040-69) 3018 RON
34 1 1 PINION (641454-00) 10512 RON
35 1 2 153752-00 - Indisponibil
36 1 1 RETAINING PLATE (618244-01) 781 RON
37 1 4 SCREW (330045-49) 558 RON
40 1 1 PULLEY (641477-00) 3466 RON
41 1 2 SCREW (153778-00) 558 RON
42 1 2 WASHER (98198-05) 558 RON
43 1 2 WASHER (153782-00) 558 RON
44 1 1 641495-00SV - Indisponibil
45 1 1 GASKET (641459-00) 1788 RON
47 1 1 BELT (641463-00) 7940 RON
48 1 1 DRIVE PULLEY (153554-00) 4137 RON
49 1 1 LOCKING PIN (153561-00) 105 RON
50 1 1 SPRING (448176-00) 558 RON
51 1 1 PLATE (393071-00) 558 RON
52 1 5 SCREW TAPTITE M4x12 SLT/T20 (330045-45) 558 RON
53 1 1 WASHER (153559-00) 558 RON
54 1 3 KEY (153638-00) 781 RON
56 1 2 SLEEVE (146740-00) 781 RON
57 1 1 SCREW (641470-00) 781 RON
57 1 1 SCREW (641470-00) 781 RON
60 1 8 Screw Metal (330045-15) 781 RON
62 1 1 LOCK KNOB (618156-00) 190 RON
63 1 1 SUPPORT PLATE (641455-00) 2347 RON
64 1 2 BUSHING (618145-00) 2124 RON
65 1 2 WASHER THRUST (153769-01) 893 RON
66 1 1 BEARING THRUST (153451-00) 781 RON
67 1 1 LOCK NUT (625393-00) 558 RON
68 1 1 POINTER (641425-00) 781 RON
70 1 1 HANDLE (618236-00) 2347 RON
71 1 3 WASHER PLAIN. STEEL 8*16*1.6 THICK (330016-03) 558 RON
72 1 1 ROD (618148-00) 2347 RON
73 1 1 WASHER THRUST (603636-00) 781 RON
74 1 11 SCREW METAL THD FRM M4X16 T20 (330045-06) 558 RON
75 1 1 BLOCK (618160-00) 1452 RON
76 1 1 SECTOR BEVEL (626440-00) 2347 RON
77 1 4 SCREW (98103-18) 558 RON
78 1 4 SCREW (98104-17) 558 RON
79 1 1 SPRING (641466-00) 3018 RON
80 1 1 PAWL (641467-00) 2347 RON
81 1 2 PLATE knob keeper (641484-00) 781 RON
81 1 2 PLATE knob keeper (641484-00) 781 RON
83 1 2 LEVER (N019349) 105 RON
84 1 1 ROD (618153-00) 190 RON
85 1 1 SPRING TORSION (618259-00) 558 RON
86 1 1 CAM (618232-00) 781 RON
88 1 2 PLATE (641471-00) 893 RON
89 1 1 PLATE (641468-00) 1229 RON
90 1 3 CARRIAGE BOLT (98130-25) 781 RON
91 1 4 NUT HEX (330015-03) 558 RON
92 1 2 SCREW (391346-00) 781 RON
93 1 1 641486-00SV - Indisponibil
94 1 3 PLATE (641416-00) 1117 RON
95 1 2 PLATE (641453-00) 3018 RON
96 1 1 TABLE SA (641498-01) 165534 RON
96 1 1 TABLE SA (641498-01) 165534 RON
97 1 2 SA BEVEL KNOB (147107-07) 2347 RON
97 1 2 SA BEVEL KNOB (147107-07) 2347 RON
98 1 12 SCREW.TEMP (330045-05) 558 RON
99 1 1 RING (49787-00) 558 RON
100 1 1 SCREW TE M8X35 (98025-35) 781 RON
101 1 1 LOCK NUT (641449-00) 558 RON
102 1 2 LAP WASHER (153792-00) 558 RON
103 1 1 DETENT PLATE DW717 (641443-00) 11519 RON
104 1 4 SCREW (604410-00) 558 RON
105 1 1 HOLDER (391358-01) 1117 RON
106 1 1 WRENCH (608563-01) 3018 RON
107 1 1 POINTER (641452-00) 781 RON
108 1 1 ACTUATOR (641446-00) 190 RON
110 1 4 SCREW METAL THD FORM M4X8 T20 (330045-44) 558 RON
112 1 1 BLOCK SPRING (397070-00) 2795 RON
115 1 1 RETAINER (641448-00) 558 RON
116 1 1 LEVER (641456-00) 3018 RON
117 1 1 PIN (659090-00) 1788 RON
118 1 1 PIN (624460-00) 893 RON
119 1 1 SLEEVE (624461-00) 781 RON
120 1 1 ROD (641447-00) 2124 RON
121 1 1 BLOCK (641424-00) 2795 RON
123 1 1 SPRING COMPRESSION (618253-00) 558 RON
124 1 1 HANDLE SA (624730-00) 7940 RON
124 1 1 HANDLE SA (624730-00) 7940 RON
125 1 4 SCREW (330045-18) 558 RON
126 1 5 SCREW PLASTITE (330019-32) 558 RON
127 1 1 SA SUPPLY POWER WRKLITE/LASR (N017897) 15993 RON
127 1 1 SA SUPPLY POWER WRKLITE/LASR (N017897) 15993 RON
127 1 1 SA SUPPLY POWER WRKLITE/LASR (N017897) 15993 RON
127 1 1 SA SUPPLY POWER WRKLITE/LASR (N017897) 15993 RON
128 1 1 SWITCH 1269.1402-02 1269R164 R.22A cod vechi 606056-00 (N548978V) 7940 RON
129 1 4 SCREW MACHINE PAN HD (384127-01) 558 RON
130 1 3 SCREW (330045-23) 781 RON
131 1 1 MOTOR CABLE (618276-00) 5591 RON
132 1 1 CORDSET GB (330060-91) 28296 RON
132 1 1 CORDSET LX (330061-28) 4825 RON
133 1 1 HANDLE CARRYING (641438-00) 3018 RON
134 1 1 SCREW (CARRY HANDLE) (330019-22) 558 RON
135 1 1 CABLE CLAMP (659008-00) 781 RON
136 1 1 CABLE SA (618213-00) 2795 RON
137 1 1 COVER (641430-00) 781 RON
138 1 1 FENCE (641411-01) 28296 RON
138 1 1 FENCE (641411-01) 28296 RON
139 1 1 FENCE LH (641474-01) 17335 RON
139 1 1 FENCE LH (641474-01) 17335 RON
140 1 1 FENCE RH (641475-01SV) 40599 RON
140 1 1 FENCE RH (641475-01SV) 40599 RON
141 1 3 KNOB LOWER (147107-02) 1117 RON
142 1 5 SCREW (98105-03) 558 RON
143 1 1 FIELDCASE (391317-00) 7940 RON
143 1 1 FIELDCASE (391317-00) 7940 RON
144 1 1 ARMATURE SA (N065988SV) 46863 RON
144 1 1 ARMATURE & FAN (396004-02SV) 42277 RON
145 1 1 FIELD (391318-01SV) 32770 RON
145 1 1 FIELD 115V (391318-00SV) 29862 RON
146 1 1 PLATE (394036-00) 7940 RON
147 1 1 SCREW (394034-00) 893 RON
148 1 1 BEARING cod vechi 605040-32 (N127530) 3466 RON
149 1 1 BEARING BALL (330003-60) 190 RON
150 1 1 SEAL RING (144803-00) 781 RON
151 1 1 RUBBER PLUG (145312-00) 558 RON
152 1 4 SCREW (98094-55) 558 RON
153 1 1 END CAP [BASF_TERLURAN_GP-22] (391933-00) 2124 RON
154 1 4 SCREW PLSTC THD FORM M4X19 T20 (330019-13) 558 RON
155 1 2 SCREW PLASTITE (330019-19) 781 RON
156 1 1 BAFFLE (391375-00) 1788 RON
157 1 1 BRUSH HOLDER NYLON 6-ULTRAMID A3X2G5 (389512-01) 10512 RON
158 1 1 IDENTITY LABEL (391325-00) 558 RON
159 1 1 RATING PLATE (662589-00) 781 RON
159 1 1 RATING PLATE (662590-00) 781 RON
160 1 1 153783-00 - Indisponibil
162 1 3 SCREW (330045-13) 558 RON
163 1 1 screw dw744 (330019-12) 558 RON
170 1 1 SA SUPP.HOUSING+RAILS DW717 (641496-00) 202891 RON
171 1 8 SCREW (603390-00) 558 RON
172 1 3 WEAR GUIDE (397118-00) 1452 RON
173 1 1 SCREW M8X10 (153576-04) 190 RON
174 1 1 FRICTION DISC (613497-00) 558 RON
175 1 2 RUBBER WASHER (153586-00) 781 RON
176 1 1 CABLE CLIP D.9-11 5 (863259-00) 2124 RON
176 1 1 CABLE CLIP D.9-11 5 (863259-00) 2124 RON
178 1 1 SLEEVE (641444-00) 893 RON
179 1 2 SCREW (330045-24) 558 RON
180 1 2 SCREW (385915-04) 558 RON
183 1 1 SPRING (659919-00) 893 RON
193 1 2 BUSHING NYLINER 10L7-5/8 D27111 (645746-00) 1229 RON
200 1 1 LABEL (395021-00) 190 RON
202 1 2 INSERT (148608-03) 1452 RON
202 1 2 INSERT (148608-03) 1452 RON
203 1 2 BEARING DW704 TYPE 3 (386780-00) 190 RON
204 1 1 GUARD LOWER (641434-01) 15993 RON
204 1 1 GUARD LOWER (641434-01) 15993 RON
205 1 1 GUARD PLATE (641433-00) 5591 RON
206 1 4 SCREW (385915-04) 558 RON
207 1 1 PIVOT BLOCK (641432-00) 4137 RON
208 1 1 BUMPER (146768-00) 781 RON
209 1 1 LINK (641436-00) 2347 RON
212 1 1 RETAINING PLATE (146750-03) 1788 RON
213 1 1 SPRING (661454-00) 1117 RON
214 1 1 SLEEVE (148295-00) 105 RON
215 1 2 ROLLER (625825-00) 781 RON
216 1 5 RING (142273-00) 558 RON
217 1 2 LABEL (394976-00) 1229 RON
218 1 1 STUD (618234-00) 2795 RON
219 1 4 SCREW (153666-00) 558 RON
221 1 4 CONTACT (145332-00) 558 RON
222 1 1 TERMINAL (450212-00) 781 RON
223 1 2 LABEL (395301-00) 781 RON
223 1 2 LABEL (395301-00) 781 RON
224 1 2 BRUSH-LEAD (381028-08) 4137 RON
224 1 2 BRUSH-LEAD (381028-08) 4137 RON
225 1 3 TERMINAL (395716-00) 558 RON
226 1 2 CORD CLAMP (660029-00) 781 RON
228 1 1 BUSHING STR.RLF (682149-00) 2347 RON
230 1 1 UNLOCKING LEVER SCREW (152852-00) 893 RON
230 1 1 UNLOCKING LEVER SCREW (152852-00) 893 RON
231 1 1 SPRING (386196-00) 105 RON
231 1 1 SPRING (386196-00) 105 RON
236 1 1 LEAD SA (618159-01) 6821 RON
236 1 1 LEAD SA (618159-01) 6821 RON
237 1 1 BLOCK TERMINAL (393520-00) 2795 RON
238 1 1 FERRITE BEAD (388414-01) 1452 RON
238 1 1 BUSH (N045491) 3466 RON
239 1 1 DUST BAG DW708 (147734-06) 3466 RON
240 1 1 CLAMP SA (630065-00) 7940 RON
241 1 2 SCREW (641442-00) 1117 RON
242 1 1 BEVEL SCALE (641426-00) 2124 RON
243 1 1 LABEL PIVOT (618277-00) 893 RON
244 1 1 LABEL PIVOT (618278-00) 893 RON
245 1 1 LINK (641427-00) 1452 RON
247 1 2 VITE TRIL.TCB M5X12 D6 1 (616001-00) 558 RON
248 1 1 DEFLECTOR (641482-00) 781 RON
249 1 1 DEFLECTOR (641481-00) 781 RON
250 1 1 LABEL (641483-00) 1117 RON
255 1 1 Duct Dust (N175841) 5591 RON
256 1 3 SCREW PLSTC THD FORM M3.5X13 T15 (330019-02) 558 RON
259 1 2 SCREW (330019-05) 558 RON
260 1 1 WARNING LABEL (N174417) 781 RON
260 1 1 WARNING LABEL (N174417) 781 RON
261 1 1 PADDLE (661663-00) 2347 RON
262 1 1 GUARD (661662-00) 190 RON
263 1 2 SCREW PLSTC THD FORM M4.55X13 T20 (330019-11) 558 RON
265 1 1 LED & POWER SUPPLY KIT (5140117-90) 3124 RON
265 1 1 LED & POWER SUPPLY KIT (5140117-90) 3124 RON
265 1 1 LED & POWER SUPPLY KIT (5140117-90) 3124 RON
265 1 1 LED & POWER SUPPLY KIT (5140117-90) 3124 RON
266 1 1 SWITCH LOCK OFF (627271-00) 781 RON
266 1 1 SWITCH LOCK OFF (627271-00) 781 RON
267 1 1 HEX KEY 2.5 MM (604407-01) 893 RON
267 1 1 HEX KEY 2.5 MM (604407-01) 893 RON
800 1 1 GREASE (790206-00) 34336 RON
800 1 1 GREASE DW704 TYPE 3 (93488-00) 7940 RON
837 1 1 559626-99 - Indisponibil
