Top » Piese de schimb » PIESE DEWALT » DW503-----B Type 1

DW503-----B CHIP COLLECTOR Type 1
[DW503-----B Type 1]
DW503-----B CHIP COLLECTOR Type 1
Click pentru a mari
LISTA DE COMPONENTE:
Numar Versiune Buc. in schema Denumire Pret/buc
(Tva inclus)		 Cumpara
1 1 1 COVER FAN MOTOR DW 250 (860445-00) 3466 RON
2 1 2 TIE ROD......................D (863119-00) 893 RON
3 1 1 FAN MOTOR D.106XD.15 DW 250 (860444-00) 2347 RON
4 1 1 BELL REAR END MOTOR DW 250 (860443-00) 4472 RON
5 1 1 RING AXIAL LOAD 34.5X28X0.5 (860080-02) 781 RON
6 1 1 BEARING 6202 (868768-07) 4137 RON
7 1 1 000000-00 - Indisponibil
9 1 1 SWITCH 3PH. DW125-111-1370-DW3 (949780-07) 9282 RON
10 1 1 000000-00 - Indisponibil
11 1 1 000000-00 - Indisponibil
13 1 1 000000-00 - Indisponibil
14 1 2 SCREW M4X20 (860094-10) 558 RON
15 1 1 000000-00 - Indisponibil
16 1 2 000000-00 - Indisponibil
17 1 2 SCREW PAN.PHAB 3.9X19 UNI6954 (860084-13) 558 RON
18 1 1 000000-00 - Indisponibil
19 1 1 000000-00 - Indisponibil
20 1 1 FILLISTER HEAD SCREW (949894-06) 558 RON
21 1 1 CABLE LINE H07RN-F 4X1 L.3000 (860618-00) 12861 RON
22 1 1 000000-00 - Indisponibil
23 1 2 SCREW HEX M.8X25 UNI 5739 (860085-19) 558 RON
24 1 1 000000-00 - Indisponibil
25 1 3 NUT HEX THICK M.8 UNI 5587 (860083-04) 558 RON
26 1 3 WASHER SPRING CON.D8.2X18X1 (860074-03) 558 RON
27 1 1 000000-00 - Indisponibil
28 1 1 BEARING (930566) 3466 RON
29 1 1 000000-00 - Indisponibil
31 1 1 000000-00 - Indisponibil
33 1 1 000000-00 - Indisponibil
