| 1 |
1 |
1 |
BASE DW712N/TTMS SERVICE (869349-00)
|
49771 RON |
|
| 2 |
1 |
4 |
RUBBER FEET (153612-00)
|
781 RON |
|
| 3 |
1 |
1 |
SCALE DW712 (397041-00)
|
12861 RON |
|
| 4 |
1 |
4 |
SHOULDER SCREW (604987-00)
|
781 RON |
|
| 5 |
1 |
1 |
TOP TABLE TTMS SERVICE (N114229)
|
53015 RON |
|
| 6 |
1 |
10 |
SCREW (98093-76)
|
558 RON |
|
| 7 |
1 |
1 |
HOLDER (391358-01)
|
1117 RON |
|
| 8 |
1 |
1 |
SCREW PAN PH/TT M.4X8 UNI8112 (860094-02)
|
558 RON |
|
| 9 |
1 |
1 |
PUSH STICK (860610-01)
|
3466 RON |
|
| 10 |
1 |
1 |
SA TABLE DW712N/TTMS EURO SERVICE (869350-00)
|
74937 RON |
|
| 11 |
1 |
1 |
SCREW HEX 10x80 DIN 933 LH (638875-00)
|
1117 RON |
|
| 12 |
1 |
1 |
LOCK PLATE (397062-00)
|
1452 RON |
|
| 13 |
1 |
4 |
SCREW (330045-55)
|
558 RON |
|
| 14 |
1 |
1 |
BLOCK SPRING (397070-00)
|
2795 RON |
|
| 15 |
1 |
1 |
LEVER (397073-00)
|
781 RON |
|
| 16 |
1 |
1 |
LEVER LOCK PLATE (397075-00)
|
558 RON |
|
| 17 |
1 |
1 |
LOCK LEVER (397065-00)
|
190 RON |
|
| 18 |
1 |
1 |
TABLE PROTECTION D27111 (635045-00)
|
4472 RON |
|
| 19 |
1 |
1 |
KIT MITER LOCK DW712 (629395-00)
|
5591 RON |
|
| 20 |
1 |
1 |
Buttom Push D27111 (638835-00)
|
558 RON |
|
| 21 |
1 |
1 |
DRIVE PIN (397063-00)
|
1117 RON |
|
| 22 |
1 |
2 |
SCREW M8X30 (153576-03)
|
105 RON |
|
| 23 |
1 |
1 |
MITER POINTER (397048-00)
|
105 RON |
|
| 24 |
1 |
1 |
BEVEL INDEX (397090-00)
|
105 RON |
|
| 25 |
1 |
4 |
SCREW (98093-76)
|
558 RON |
|
| 26 |
1 |
2 |
WASHER (249233-00)
|
558 RON |
|
| 27 |
1 |
1 |
SCREW (612008-00)
|
781 RON |
|
| 28 |
1 |
1 |
NUT SELF LOCKING M.8 (860092-05)
|
558 RON |
|
| 29 |
1 |
2 |
LAP WASHER (153781-00)
|
781 RON |
|
| 30 |
1 |
1 |
WASHER (613270-00)
|
781 RON |
|
| 31 |
1 |
2 |
INSERT (397046-00)
|
2347 RON |
|
| 32 |
1 |
1 |
FIXED FENCE D27111 (641363-00)
|
43731 RON |
|
| 33 |
1 |
4 |
SCREW TRIL (330045-33)
|
781 RON |
|
| 34 |
1 |
1 |
SA KIT GUARD+KNIFE TTMS SERVICE (N102812)
|
26730 RON |
|
| 35 |
1 |
2 |
SCREW (330045-32)
|
781 RON |
|
| 36 |
1 |
2 |
WASHER FLAT 8.4X17 UNI6592 ZN (860073-03)
|
558 RON |
|
| 37 |
1 |
2 |
NUT HEX THICK M.8 UNI 5587 (860083-04)
|
558 RON |
|
| 38 |
1 |
1 |
SLIDING RIPPING FENCE D27111 (637806-00)
|
17335 RON |
|
| 39 |
1 |
1 |
Nut Fence Guide D27111 (637805-00)
|
4137 RON |
|
| 40 |
1 |
1 |
BRACKET FENCE D27111 (634738-00)
|
3466 RON |
|
| 41 |
1 |
2 |
WASHER FLAT 8.4X17 UNI6592 ZN (860073-03)
|
558 RON |
|
| 42 |
1 |
1 |
SCREW (612008-00)
|
781 RON |
|
| 43 |
1 |
1 |
WASHER CLAMP (392948-00)
|
558 RON |
|
| 44 |
1 |
1 |
LEVA BLOCC.BATTUTA REFIL.FN (605794-00)
|
3018 RON |
|
| 45 |
1 |
1 |
SCREW PAN PH/TT M.4X8 UNI8112 (860094-02)
|
558 RON |
|
| 47 |
1 |
1 |
SPINA CILINDR.D6X50 (605795-00)
|
893 RON |
|
| 48 |
1 |
1 |
SQUADRETTA BLOCCAGGIO BATT.REF (605796-00)
|
781 RON |
|
| 49 |
1 |
1 |
TABLE SUPPORT D27111 (636091-00)
|
6821 RON |
|
| 50 |
1 |
1 |
LAP WASHER (153781-00)
|
781 RON |
|
| 52 |
1 |
1 |
NUT SELF LOCKING M.8 (860092-05)
|
558 RON |
|
| 53 |
1 |
1 |
SPACER BEVEL D27111 (606362-01)
|
893 RON |
|
| 54 |
1 |
1 |
WING NUT M8 (941756-00)
|
1229 RON |
|
| 55 |
1 |
1 |
WRENCH HEX 5 UNI 6753 (930574-00)
|
781 RON |
|
| 55 |
1 |
1 |
WRENCH TORX T30 (385567-01)
|
2347 RON |
|
| 57 |
1 |
1 |
SLIDING FENCE D27111 (640349-00)
|
14315 RON |
|
| 58 |
1 |
1 |
CLAMP LEVER PUSH (637338-00)
|
1452 RON |
|
| 59 |
1 |
4 |
SCREW TCBPH5 5X38 6954ZP (860084-24)
|
558 RON |
|
| 60 |
1 |
1 |
SCREW (150075-00)
|
781 RON |
|
| 61 |
1 |
1 |
SCREW TRIL (330045-34)
|
105 RON |
|
| 62 |
1 |
2 |
SCREW PAN PH/TT M.4X8 UNI8112 (860094-02)
|
558 RON |
|
| 63 |
1 |
1 |
TORSIONAL SPRING (637289-00)
|
781 RON |
|
| 64 |
1 |
1 |
UNLOCKING HEAD BAR D27111 (637193-00)
|
2795 RON |
|
| 65 |
1 |
1 |
SHOULDER SCREW (153639-00)
|
781 RON |
|
| 66 |
1 |
1 |
HEXAGONAL HEAD SCREW (949702-19)
|
893 RON |
|
| 67 |
1 |
1 |
ARM D27111 (634719-00)
|
46863 RON |
|
| 68 |
1 |
1 |
PIN LOCKING (649653-00)
|
3018 RON |
|
| 69 |
1 |
1 |
RING SPRING S.LOCK HOLE ZJ-40 (860806-00)
|
893 RON |
|
| 70 |
1 |
1 |
SA KIT GUARD+KNIFE TTMS SERVICE (N102812)
|
26730 RON |
|
| 71 |
1 |
1 |
BUSH (385756-01)
|
1229 RON |
|
| 72 |
1 |
1 |
SCREW TRIL (330045-33)
|
781 RON |
|
| 73 |
1 |
1 |
BLADE SPACER (641029-00)
|
3018 RON |
|
| 74 |
1 |
1 |
BEARING 6202 (868768-07)
|
4137 RON |
|
| 75 |
1 |
1 |
CORD HOLDER (640248-00)
|
558 RON |
|
| 76 |
1 |
1 |
Bracket Handle Mounting D27111 (637550-00)
|
781 RON |
|
| 77 |
1 |
1 |
WOUND STATOR+HOUSING V.220/230 (868412-07)
|
102451 RON |
|
| 78 |
1 |
1 |
FAN (945841-00)
|
2347 RON |
|
| 79 |
1 |
1 |
COVER FAN MOTOR D27111 (642100-00)
|
3018 RON |
|
| 80 |
1 |
1 |
ARMATURE D27111+SPRING+RING (868411-03)
|
86681 RON |
|
| 80 |
1 |
1 |
ARMATURE D27111+SPRING+RING (868411-03)
|
86681 RON |
|
| 81 |
1 |
1 |
RING AXIAL LOAD 34.5X28X0.5 (860080-02)
|
781 RON |
|
| 82 |
1 |
1 |
BEARING BALL (330003-13)
|
4137 RON |
|
| 83 |
1 |
1 |
CIRCLIP (861349-00)
|
558 RON |
|
| 84 |
1 |
1 |
SPRING (648132-00)
|
781 RON |
|
| 84 |
1 |
1 |
SPRING (640614-00)
|
781 RON |
|
| 85 |
1 |
1 |
CAP D.50+BUSHING (861336-02)
|
3018 RON |
|
| 86 |
1 |
1 |
SPRING (861338-00)
|
781 RON |
|
| 87 |
1 |
1 |
ROD THREADED HEX M.5X135 (860446-01)
|
781 RON |
|
| 88 |
1 |
1 |
CABLE INLET RING (637486-00)
|
558 RON |
|
| 89 |
1 |
1 |
KIT SA HANDLE+KEY D27111 SERVICE (869283-00)
|
12861 RON |
|
| 90 |
1 |
6 |
SCREW M4 55X19 (330013-13)
|
558 RON |
|
| 91 |
1 |
1 |
SWITCH (640985-00)
|
11519 RON |
|
| 92 |
1 |
1 |
SWITCH COVER (868320-00)
|
2347 RON |
|
| 93 |
1 |
2 |
SCREW M4 55X19 (330013-13)
|
558 RON |
|
| 94 |
1 |
1 |
TERMINAL BLOCK [RATED 25A 600V] (326057-00)
|
893 RON |
|
| 95 |
1 |
1 |
CORD SUPPLY D27111-GB (868313-14)
|
15993 RON |
|
| 96 |
1 |
1 |
CAPACITOR (641082-00)
|
5031 RON |
|
| 97 |
1 |
1 |
INSULATED BUSHING [POLYONE LM-318-G001] (615851-00)
|
2795 RON |
|
| 98 |
1 |
1 |
Cap End Mach D27111 (618142-00)
|
9282 RON |
|
| 99 |
1 |
3 |
SLIDE ROLLER (640146-00)
|
893 RON |
|
| 100 |
1 |
4 |
SCREW SOCKET M.6X20 UNI 5931 (860093-05)
|
558 RON |
|
| 101 |
1 |
1 |
SCREW M8X10 (153576-04)
|
190 RON |
|
| 102 |
1 |
1 |
END CAP (861345-00)
|
9282 RON |
|
| 104 |
1 |
1 |
SCREW ST M8X10 (330022-17)
|
558 RON |
|
| 107 |
1 |
2 |
PLASTIC WASHER (639554-00)
|
1229 RON |
|
| 108 |
1 |
1 |
SPACER (639383-00)
|
1229 RON |
|
| 109 |
1 |
1 |
SPRING (633290-04)
|
10512 RON |
|
| 110 |
1 |
1 |
SPACER (146732-00)
|
781 RON |
|
| 111 |
1 |
1 |
JOINT AXLE (397128-00)
|
2795 RON |
|
| 112 |
1 |
1 |
GASKET DW250-DW252 (949746-02)
|
558 RON |
|
| 113 |
1 |
1 |
KNOB (147107-06)
|
2124 RON |
|
| 114 |
1 |
1 |
COMPRESSION SPRING (606014-00)
|
558 RON |
|
| 115 |
1 |
1 |
SCREW M5X16 (395382-01)
|
558 RON |
|
| 116 |
1 |
1 |
BEVEL NUT (397089-00)
|
2124 RON |
|
| 117 |
1 |
1 |
SCREW (612008-00)
|
781 RON |
|
| 118 |
1 |
1 |
LAP WASHER (153781-00)
|
781 RON |
|
| 119 |
1 |
1 |
SCALE D27111 (637807-00)
|
190 RON |
|
| 120 |
1 |
1 |
INDICE BATTUTA REFIL.D27105 (605798-00)
|
781 RON |
|
| 121 |
1 |
1 |
WASHER (613270-00)
|
781 RON |
|
| 123 |
1 |
2 |
WEAR GUIDE (397118-00)
|
1452 RON |
|
| 125 |
1 |
4 |
WIPER (397117-00)
|
893 RON |
|
| 126 |
1 |
1 |
LOCK LEVER (397080-00)
|
1452 RON |
|
| 127 |
1 |
1 |
PIN BEVEL STOP (637332-00)
|
3466 RON |
|
| 128 |
1 |
1 |
BEVEL SCALE (637334-00)
|
1788 RON |
|
| 130 |
1 |
2 |
RUBBER WASHER (153586-00)
|
781 RON |
|
| 131 |
1 |
2 |
VITE TRIL.TCB M5X12 D6 1 (616001-00)
|
558 RON |
|
| 132 |
1 |
1 |
FRICTION DISC (613497-00)
|
558 RON |
|
| 134 |
1 |
4 |
SCREW SOCKET M.6X20 UNI 5931 (860093-05)
|
558 RON |
|
| 135 |
1 |
1 |
WING NUT M8 (941756-00)
|
1229 RON |
|
| 137 |
1 |
3 |
Screw Metal (330045-15)
|
781 RON |
|
| 138 |
1 |
1 |
WARNING LABEL (621135-00)
|
1117 RON |
|
| 139 |
1 |
1 |
BLADE PROTECTION (635047-00)
|
6821 RON |
|
| 140 |
1 |
1 |
SPRING TORSION (SX) D27111 (637288-00)
|
781 RON |
|
| 141 |
1 |
1 |
CLAMP D23700 (625857-00)
|
1117 RON |
|
| 142 |
1 |
2 |
SCREW PAN PH/TT M.4X12UNI8112 (860094-05)
|
558 RON |
|
| 143 |
1 |
1 |
SHOULDER SCREW (153639-00)
|
781 RON |
|
| 144 |
1 |
2 |
SEAL RING (604728-00)
|
558 RON |
|
| 145 |
1 |
2 |
ROLLER (146774-00)
|
1117 RON |
|
| 146 |
1 |
1 |
S/A PROTECTION (637998-00)
|
23598 RON |
|
| 147 |
1 |
1 |
BLADE BOLT (647776-00)
|
781 RON |
|
| 148 |
1 |
1 |
CLAMP OUTER (604765-00)
|
3466 RON |
|
| 149 |
1 |
1 |
FLANGIA INTERNA D27201 (616319-00)
|
5031 RON |
|
| 150 |
1 |
1 |
NUT (861340-00)
|
558 RON |
|
| 151 |
1 |
1 |
BEARING D10-M4 D27111 (605040-51)
|
2347 RON |
|
| 152 |
1 |
1 |
SCREW M4 X 16 (330024-49)
|
558 RON |
|
| 153 |
1 |
1 |
SCREW (330045-23)
|
781 RON |
|
| 154 |
1 |
2 |
SYNT. BUSHING (146740-02)
|
558 RON |
|
| 155 |
1 |
5 |
SHOULDER SCREW (153639-00)
|
781 RON |
|
| 156 |
1 |
1 |
LINK BAR D27111 (637192-00)
|
2795 RON |
|
| 157 |
1 |
1 |
RETAINING RING (629745-00)
|
893 RON |
|
| 158 |
1 |
1 |
SCREW (98093-76)
|
558 RON |
|
| 159 |
1 |
1 |
EXTENSION SPRING (640503-00)
|
893 RON |
|
| 160 |
1 |
1 |
GUARD BOTTOM MAIN D27111 (634726-00)
|
17335 RON |
|
| 161 |
1 |
1 |
GUARD BOTTOM AUXILIARY D27111 (635046-00)
|
5591 RON |
|
| 162 |
1 |
1 |
KNOB M6 UNI5448 ZN (720929-00)
|
558 RON |
|
| 163 |
1 |
1 |
SCREW SPECIAL FENCE CLAMP D27111 (640959-00)
|
1452 RON |
|
| 164 |
1 |
1 |
FENCE SLIDING RH D27111 (634736-00)
|
4472 RON |
|
| 165 |
1 |
1 |
LABEL WARNING TABLE D27111 (645156-00)
|
190 RON |
|
| 166 |
1 |
1 |
SCREW PAN PH/TT M.4X8 UNI8112 (860094-02)
|
558 RON |
|
| 168 |
1 |
1 |
KNOB M6 UNI5448 ZN (720929-00)
|
558 RON |
|
| 169 |
1 |
1 |
TOOTHED WASHER (931429-00)
|
558 RON |
|
| 170 |
1 |
1 |
WASHER FLAT 6.4X12.5 UNI 6592 (720959-00)
|
558 RON |
|
| 171 |
1 |
1 |
SCREW (931997-00)
|
558 RON |
|
| 172 |
1 |
1 |
KNOB D.40X16-M8X23-BLACK (862427-00)
|
781 RON |
|
| 173 |
1 |
1 |
BRACKET ARM PIN D27111 (634734-00)
|
2124 RON |
|
| 174 |
1 |
1 |
SCREW PAN PH/TT M.4X8 UNI8112 (860094-02)
|
558 RON |
|
| 175 |
1 |
1 |
WRENCH TORX T40 (385567-04)
|
1452 RON |
|
| 175 |
1 |
1 |
WRENCH HEX 6 UNI 6753 (860098-04)
|
781 RON |
|
| 176 |
1 |
2 |
BUSHING NYLINER 10L7-5/8 D27111 (645746-00)
|
1229 RON |
|
| 200 |
1 |
1 |
S/A FENCE D27111 (869231-04)
|
3124 RON |
|
| 250 |
1 |
1 |
SA BEVEL SLIDE MECHANISM D27111 SERVICE (N176001)
|
271790 RON |
|
| 350 |
1 |
1 |
S/A DUST MOUTH D27112 (654313-00)
|
7940 RON |
|
| 351 |
1 |
1 |
RING (654787-00)
|
558 RON |
|
| 352 |
1 |
2 |
SCREW (330045-23)
|
781 RON |
|
| 356 |
1 |
1 |
NUT M6 (860083-12)
|
558 RON |
|
| 357 |
1 |
1 |
FLAPPER D27112 (654312-00)
|
5591 RON |
|
| 358 |
1 |
2 |
PUSH RIVET (607491-00)
|
558 RON |
|
| 359 |
1 |
4 |
SCREW PLASTITE (330013-02)
|
558 RON |
|
| 800 |
1 |
1 |
GREASE (790206-00)
|
34336 RON |
|
| 800 |
1 |
1 |
GREASE DW704 TYPE 3 (93488-00)
|
7940 RON |
|
| 821 |
1 |
1 |
NAMEPLATE D27111-GB T.1 (N049782)
|
4137 RON |
|
In cos:
